DAC0801LCN

Description
PARALLEL, 8 BITS INPUT LOADING, 0.1 us SETTLING TIME, 8-BIT DAC, PDIP16, PLASTIC, DIP-16
CategoryAnalog mixed-signal IC    converter
File Size896KB,13 Pages
ManufacturerRochester Electronics
Websitehttps://www.rocelec.com/
Download Datasheet Parametric Compare View All

DAC0801LCN Overview

PARALLEL, 8 BITS INPUT LOADING, 0.1 us SETTLING TIME, 8-BIT DAC, PDIP16, PLASTIC, DIP-16

DAC0801LCN Parametric

Parameter NameAttribute value
Is it lead-free?Contains lead
Is it Rohs certified?incompatible
MakerRochester Electronics
Parts packaging codeDIP
package instructionDIP,
Contacts16
Reach Compliance Codeunknown
Converter typeD/A CONVERTER
Enter bit codeOFFSET BINARY
Input formatPARALLEL, 8 BITS
JESD-30 codeR-PDIP-T16
JESD-609 codee0
length21.755 mm
Maximum linear error (EL)0.39%
Humidity sensitivity levelNOT SPECIFIED
Nominal negative supply voltage-15 V
Number of digits8
Number of functions1
Number of terminals16
Maximum operating temperature70 °C
Minimum operating temperature
Package body materialPLASTIC/EPOXY
encapsulated codeDIP
Package shapeRECTANGULAR
Package formIN-LINE
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Certification statusCOMMERCIAL
Maximum seat height5.08 mm
Nominal settling time (tstl)0.1 µs
Nominal supply voltage15 V
surface mountNO
technologyBIPOLAR
Temperature levelCOMMERCIAL
Terminal surfaceTIN LEAD
Terminal formTHROUGH-HOLE
Terminal pitch2.54 mm
Terminal locationDUAL
Maximum time at peak reflow temperatureNOT SPECIFIED
width7.62 mm
