BSN20BK datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> The transistor> BSN20BK

BSN20BK: DescriptionSmall Signal Field-Effect Transistor, 0.265A I(D), 60V, 1-Element, N-Channel, Silicon, Metal-oxide Semiconductor FET, TO-236AB; CategoryDiscrete semiconductor The transistor; File Size275KB，16 Pages; ManufacturerNexperia; Websitehttps://www.nexperia.com; Environmental Compliance

Download Datasheet Parametric Compare View All

BSN20BK Overview

Small Signal Field-Effect Transistor, 0.265A I(D), 60V, 1-Element, N-Channel, Silicon, Metal-oxide Semiconductor FET, TO-236AB

BSN20BK Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Nexperia
package instruction	PLASTIC PACKAGE-3
Reach Compliance Code	compliant
ECCN code	EAR99
Other features	LOGIC LEVEL COMPATIBLE
Configuration	SINGLE WITH BUILT-IN DIODE
Minimum drain-source breakdown voltage	60 V
Maximum drain current (ID)	0.265 A
Maximum drain-source on-resistance	3.2 Ω
FET technology	METAL-OXIDE SEMICONDUCTOR
Maximum feedback capacitance (Crss)	7 pF
JEDEC-95 code	TO-236AB
JESD-30 code	R-PDSO-G3
JESD-609 code	e3
Humidity sensitivity level	1
Number of components	1
Number of terminals	3
Operating mode	ENHANCEMENT MODE
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260
Polarity/channel type	N-CHANNEL
Guideline	IEC-60134
surface mount	YES
Terminal surface	Tin (Sn)
Terminal form	GULL WING
Terminal location	DUAL
Maximum time at peak reflow temperature	30
transistor applications	SWITCHING
Transistor component materials	SILICON

Preview

Download Datasheet

View All

BSN20BK

18 December 2014

60 V, N-channel Trench MOSFET

Product data sheet

1. General description

N-channel enhancement mode Field-Effect Transistor (FET) in a small SOT23

(TO-236AB) Surface-Mounted Device (SMD) plastic package using Trench MOSFET

technology.

2. Features and benefits

•

Logic-level compatible

Very fast switching

Trench MOSFET technology

ElectroStatic Discharge (ESD) protection: 2 kV HBM

3. Applications

•

Relay driver

High-speed line driver

Low-side loadswitch

Switching circuits

4. Quick reference data

Table 1.

Symbol

Quick reference data

Parameter

drain-source voltage

gate-source voltage

drain current

= 10 V; T

amb

= 25 °C

= 10 V; T

= 25 °C

Static characteristics

DSon

drain-source on-state

resistance

[1]

Conditions

= 25 °C

Min

-20

Typ

Max

265

330

Unit

= 10 V; I

= 200 mA; T

= 25 °C

2.1

2.8

Device mounted on an FR4 PCB, single-sided copper, tin-plated and mounting pad for drain 1 cm .
