Intel
®
Xeon
™
Processor with 512-KB L2 Cache
at 1.80 GHz to 3 GHz
Datasheet
Product Features
•
•
•
•
•
•
•
•
•
•
Available at 1.80, 2, 2.20, 2.40, 2.60, 2.80, and
3 GHz
Dual processing server/workstation support
Binary compatible with applications running on
previous members of Intel’s IA32
microprocessor line
Intel
®
NetBurst™ micro-architecture
Hyper-Threading Technology
— Hardware support for multithreaded
applications
400 MHz Front Side Bus
— Bandwidth up to 3.2 GB/second
Rapid Execution Engine: Arithmetic Logic
Units (ALUs) run at twice the processor core
frequency
Hyper Pipelined Technology
Advance Dynamic Execution
— Very deep out-of-order execution
— Enhanced branch prediction
Level 1 Execution Trace Cache stores 12 K
micro-ops and removes decoder latency from
main execution loops
— Includes 8 KB Level 1 data cache
•
•
•
•
•
•
512 KB Advanced Transfer L2 Cache (on-die,
full speed Level 2 cache) with 8-way
associativity and Error Correcting Code (ECC)
Enables system support of up to 64 GB of
physical memory
Streaming SIMD Extensions 2 (SSE2)
— 144 new instructions for double-precision
floating point operations, media/video
streaming, and secure transactions
Enhanced floating point and multimedia unit for
enhanced video, audio, encryption, and 3D
performance
Power Management capabilities
— System Management mode
— Multiple low-power states
Advanced System Management Features
— System Management Bus
— Processor Information ROM (PIROM)
— OEM Scratch EEPROM
— Thermal Monitor
— Machine Check Architecture (MCA)
The Intel
®
Xeon™ processor with 512 KB L2 cache is designed for high-performance dual-
processor workstation and server applications. Based on the Intel
®
NetBurst™ micro-
architecture and the new Hyper-Threading Technology, it is binary compatible with previous
Intel Architecture (IA-32) processors. The Intel Xeon processor with 512 KB L2 cache is
scalable to two processors in a multiprocessor system providing exceptional performance for
applications running on advanced operating systems such as Windows XP*, Windows* 2000,
Linux*, and UNIX*. The Intel Xeon processor with 512 KB L2 cache delivers compute power at
unparalleled value and flexibility for powerful workstations, internet infrastructure, and
departmental server applications. The Intel
®
NetBurst™ micro-architecture and Hyper-
Threading Technology deliver outstanding performance and headroom for peak internet server
workloads, resulting in faster response times, support for more users, and improved scalability.
Order Number: 298642-006
March
2003
INFORMATION IN THIS DOCUMENT IS PROVIDED IN CONNECTION WITH INTEL® PRODUCTS. NO LICENSE, EXPRESS
OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO ANY INTELLECTUAL PROPERTY RIGHTS IS GRANTED BY THIS
DOCUMENT. EXCEPT AS PROVIDED IN INTEL'S TERMS AND CONDITIONS OF SALE FOR SUCH PRODUCTS, INTEL
ASSUMES NO LIABILITY WHATSOEVER, AND INTEL DISCLAIMS ANY EXPRESS OR IMPLIED WARRANTY, RELATING TO
SALE AND/OR USE OF INTEL PRODUCTS INCLUDING LIABILITY OR WARRANTIES RELATING TO FITNESS FOR A
PARTICULAR PURPOSE, MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT, COPYRIGHT OR OTHER
INTELLECTUAL PROPERTY RIGHT. Intel products are not intended for use in medical, life saving, life sustaining applications.
Intel may make changes to specifications and product descriptions at any time, without notice.
Designers must not rely on the absence or characteristics of any features or instructions marked "reserved" or "undefined." Intel
reserves these for future definition and shall have no responsibility whatsoever for conflicts or incompatibilities arising from future
changes to them.
The Intel
®
Xeon
™
processor may contain design defects or errors known as errata which may cause the product to deviate from
published specifications. Current characterized errata are available on request.
Contact your local Intel sales office or your distributor to obtain the latest specifications and before placing your product order.
Copies of documents which have an ordering number and are referenced in this document, or other Intel literature may be obtained
by calling 1-800-548-4725 or by visiting Intel's website at http://www.intel.com.
Intel, Pentium, Pentium III Xeon, Intel Xeon and Intel NetBurst are trademark or registered trademarks of Intel Corporation or its
subsidiaries in the United States and other countries.
Copyright © Intel Corporation, 2002-2003
