General Product Information .....................................................................................................................................3
Absolute Maximum Ratings ..................................................................................................................................8
Mechanical Dimensions: LUXEON Z Blue/Green/Royal-Blue and Cyan Emitters ......................................10
Mechanical Dimensions: LUXEON Z White Emitter .........................................................................................11
Mechanical Dimensions: LUXEON Z Red, Red-Orange, Amber and Deep Red Emitters .........................12
Pad Configuration .......................................................................................................................................................13
Solder Pad Design .................................................................................................................................................13
Typical Light Output Characteristics over Temperature ....................................................................................15
Typical Forward Current Characterisics ...............................................................................................................16
Forward Voltage Bins ..................................................................................................................................................25
Color Bins.....................................................................................................................................................................26
LUXEON Z Datasheet DS105 20120516
2
General Product Information
Product Nomenclature
The part number designation for LUXEON Z - Color LEDs is explained as follows:
L X Z 1 -A B C D - E F G H
Where:
A — designates radiation pattern (value P for lambertian)
B — designates color (see LUXEON Z color binning and labeling section)
C — designates color variant (0 for color variants)
D — designates test current (value 1 for 350 mA; 2 for 700 mA.)
E — open slot to accommodate additional requirements per product and part number
FGH — minimum luminous flux (lm) or radiometric power (mW) performance
The part number designation for LUXEON Z - White LEDs is explained as follows
L X Z 1 -A B C D - E F G H
Where:
A — 1
st
digit of Color temperature (e.g. 4 for 4000K, 3 for 3000K)
B — 2
nd
digit of Color temperature (e.g.: 0 for 4000K, 0 for 3000K)
C — 1
st
digit of CRI (e.g.: 6 for 60 CRI, 8 for 85 CRI)
D — 2
nd
digit of CRI (e.g.: 0 for 60 CRI, 5 for 85 CRI)
E — open slot to accommodate additional requirements per product and part number
FGH — minimum luminous flux (lm)
LUXEON Z Datasheet DS105 20120516
3
Flux and Efficacy Performance Characteristics
Luminous Flux Characteristics for LUXEON Z Color Portfolio, Thermal Pad Temperature =25°C
Min Luminous
Flux (lm)
or Radiometric
Power (mW)
Table 1.
Typ Efficacy
(lm/W) or
WPE
Typ Luminous
Flux (lm) or
Radiometric
Power (mW)
Typ Efficacy
(lm/W) or
WPE
Color
Part
Number
Typ
Flux
(lm/mw)
Performance @ 500 mA
LXZ1-PM01-0104
LXZ1-PM01-0096
Green
104
96
98
63
Performance @ 700 mA
120
53
LXZ1-PM01-0088
88
92
59
113
50
LXZ1-PM01-0080
80
84
54
103
46
LXZ1-PM01-0072
72
76
49
93
41
LXZ1-PE01-0080
80
81
52
100
44
LXZ1-PE01-0072
72
70
45
86
38
Cyan
LXZ1-PE01-0064
64
68
44
84
38
LXZ1-PE01-0056
56
60
39
74
33
LXZ1-PE01-0048
48
54
35
67
30
LXZ1-PB01-0048
48
50
34
65
30
LXZ1-PB01-0040
40
44
30
57
27
Blue
LXZ1-PB01-0032
32
38
26
49
23
LXZ1-PB01-0024
24
30
21
39
19
LXZ1-PR01-0600
600
620
43%
823
40%
LXZ1-PR01-0550
550
570
40%
757
37%
Royal-Blue
LXZ1-PR01-0500
500
530
37%
704
35%
LXZ1-PR01-0450
450
480
33%
637
31%
LXZ1-PA01-0350
350
360
34%
454
31%
Deep Red
LXZ1-PA01-0300
300
330
32%
416
29%
LXZ1-PA01-0250
250
280
26%
353
24%
LXZ1-PD01-0056
56
57
54
77
49
LXZ1-PD01-0048
48
52
50
70
46
Red
LXZ1-PD01-0040
40
44
42
60
38
LXZ1-PD01-0032
32
37
35
50
32
LXZ1-PH01-0064
64
66
63
90
58
Red-Orange
LXZ1-PH01-0056
56
60
57
82
53
LXZ1-PH01-0048
48
54
51
73
47
LXZ1-PL01-0064
64
66
63
90
59
LXZ1-PL01-0056
56
60
57
82
53
Amber
LXZ1-PL01-0048
48
54
51
73
48
LXZ1-PL01-0040
40
46
44
63
41
Notes for Table 1:
1. Minimum luminous flux or radiometric power performance guaranteed within published operating conditions. Philips Lumileds maintains a
tolerance of ± 6.5% on flux and power measurements.
2. Typical luminous flux or radiometric power performance when device is operated within published operating conditions.
LUXEON Z Datasheet DS105 20120516
4
Flux and Efficacy Performance Characteristics,
Continued
Luminous Flux Characteristics for LUXEON Z White, Thermal Pad Temperature =25°C
Min Luminous
Flux (lm)
or Radiometric
Power (mW)
Table 2.
Typ Efficacy
(lm/W) or
WPE
Typ Luminous
Flux (lm) or
Radiometric
Power (mW)
Typ Efficacy
(lm/W) or
WPE
White
Part
Number
Typ
Flux
(lm/mw)
Performance @ 500 mA
4000K/
70 CRI
LXZ1-4070-0144
LXZ1-4070-0134
LXZ1-4070-0124
LXZ1-4070-0114
144
134
124
114
148
140
130
122
102
96
90
85
Performance @ 700 mA
194
183
170
160
94
88
83
78
Flux Performance, Binning, and Supportability
LEDs are produced with semiconductor technology that is subject to process variation, yielding a range of flux performance that is approximately
Gaussian in nature. In order to provide customers with fine granularity within the overall flux distribution, Philips Lumileds separates LEDs into
fixed, easy to design with, minimum luminous flux bins. To verify supportability of parts chosen for your application design, please consult your
Philips Lumileds or Future Lighting Solutions sales representative.
