MEMS Tap/VOA Hybrid
DiCon's MEMS Tap/VOA Hybrid is based on a micro-electro-
mechanical system (MEMS) chip integrated with a thin film filter.
The thin film tap filter couples a portion of the input signal to an
output tap fiber while transmitting the rest of the input signal
onto a movable MEMS mirror. The MEMS mirror position
depends on the applied voltage, thereby adjusting the power level
coupled into the attenuator (VOA) output fiber.
Optical Specifications
1
Insertion loss C-P1 2%
5%
10%
Insertion loss C-P2 2%
5%
10%
Temperature dependence
Flatness
4
Fast
ripple
5
0 to 15 dB
2, 3
Ordering Information
MTA -
Tap Ratio
2
2%
5
5%
10
10%
Transmission Band
15
1528 - 1563 nm
16
1570 - 1610 nm
Connector Type
FC
FC/APC
FC/UPC
SC
SC/APC
SC/UPC
ST
ST/UPC
LC
LC/UPC
MU/UPC
N
FC/SPC
FC/APC
FC/UPC
SC/SPC
SC/APC
SC/UPC
ST/SPC
ST/UPC
LC/SPC
LC/UPC
MU/UPC
None
0.8 dB max.
1.0 dB max.
1.2 dB max.
18 dB max.
15 dB max.
12 dB max.
+/ - 0.15 dB max.
0.4 dB max.
0.7 dB max.
0.1 dB max.
0.15 dB max.
0.1 ps max.
-55 dB max.
300 mW max.
2 ms max.
0.1 dB max.
1 x 10
7
cycles min.
20 dB/V max.
0 dB/V min.
9/125 Corning SMF-28
250 micron, 200 kpsi bare fiber
0
0
C to +65
0
C
-40
o
C to +85
o
C
-
-2-
-
-
-
0 to 15 dB
15 to 20 dB
Polarization
dependent loss
15 to 20 dB 0.2 dB max.
Polarization mode dispersion
Back-reflection
Optical power
Response speed
Features
Repeatability
Wear-out
Attenuation slope
Monotonicity
Fiber type
Fiber jacket
Operating temperature
Storage temperature
1.
2.
3.
4.
•
•
•
•
Attenuation Range
20
X
20 dB min. @ 5.0 VDC
Specify X dB min. @ 5.0 VDC
Slow ripple
1
Fast ripple
2
MEMS Attenuator with integrated input Tap
Combines power level control and power monitoring
Preserves board real estate through hybridization
Smallest attenuator hybrid package in the telecom industry
Ripple Type
S
F
Pigtail Length
1
X
1 meter
Specify X meters
Applications
MEMS Tap/VOA Hybrids are used in telecom modules which require
power level control and power monitoring. Examples of such modules
are VOA-MUX/DMUXes, OADMs with integrated power equalization,
Dynamic Band Equalizers, Dynamic Channel Equalizers and Fiber
Amplifiers.
Electrical Specifications
Actuation type
DC drive voltage
Voltage damage threshold
Resistance
Capacitance
Power consumption
Non-latching
0 - 5 VDC
10 VDC max.
100 Kohms min.
2 pF typ.
10 uWatt max.
Housing Dimensions
10.00
35.0
12.7
1.0
MEMS TAP/VOA
S/N 15A11M001098
3.00
Ø5.56
Ø2.5
Ø5.56
1 (CNTL)
2 (CNTL)
3 (GND)
Units: mm
U.S. patented. Specifications subject to change. Copyright ©2002 DiCon Fiberoptics, Inc. All rights reserved.
DiCon Fiberoptics, Inc. 1689 Regatta Blvd. Richmond, CA 94804
Tel. (510)620-5000
Fax. (510)620-4100
www.diconfiber.com
0099A
