5962D9568801VGA

Description
Operational Amplifier, 1 Func, 4000uV Offset-Max, BIPolar, MBCY8
CategoryAnalog mixed-signal IC    Amplifier circuit
File Size78KB,5 Pages
ManufacturerHarris
Websitehttp://www.harris.com/
Download Datasheet Parametric Compare View All

5962D9568801VGA Overview

Operational Amplifier, 1 Func, 4000uV Offset-Max, BIPolar, MBCY8

5962D9568801VGA Parametric

Parameter NameAttribute value
MakerHarris
package instruction,
Reach Compliance Codeunknown
ECCN codeEAR99
Amplifier typeOPERATIONAL AMPLIFIER
Maximum average bias current (IIB)0.015 µA
Maximum input offset voltage4000 µV
JESD-30 codeO-MBCY-W8
JESD-609 codee0
Nominal Negative Supply Voltage (Vsup)-15 V
Number of functions1
Number of terminals8
Maximum operating temperature125 °C
Minimum operating temperature-55 °C
Package body materialMETAL
Package shapeROUND
Package formCYLINDRICAL
Certification statusNot Qualified
Nominal slew rate35 V/us
Nominal supply voltage (Vsup)15 V
surface mountNO
technologyBIPOLAR
Temperature levelMILITARY
Terminal surfaceTIN LEAD
Terminal formWIRE
Terminal locationBOTTOM
total dose10k Rad(Si) V
Nominal Uniform Gain Bandwidth100000 kHz
HS-2620RH, HS-2622RH
Data Sheet
August 1999
File Number
4014.1
Radiation Hardened, Very Wideband, High
Input Impedance Uncompensated
Operational Amplifiers
HS-2620RH and HS-2622RH are radiation hardened bipolar
operational amplifiers that feature very high input impedance
coupled with wideband AC performance. The high resistance
of the input stage is complemented by low offset voltage (4mV
Max at 25
o
C for HS-2620RH) and low bias and offset current
(15nA Max at 25
o
C for HS-2620RH) to facilitate accurate
signal processing. Offset voltage can be reduced further by
means of an external nulling potentiometer. Closed loop gains
greater than 5, the 25V/µs minimum slew rate at 25
o
C and the
100kV/V minimum open loop gain at 25
o
C, enables the
HS-2620RH to perform high gain amplification of very fast,
wideband signals. These dynamic characteristics, coupled
with fast settling times, make these amplifiers ideally suited to
pulse amplification designs as well as high frequency or video
applications. The frequency response of the amplifier can be
tailored to exact design requirements by means of an external
bandwidth control capacitor. Other high performance designs
such as high gain, low distortion audio amplifiers, high-Q and
wideband active filters and high speed comparators are
excellent uses of this part.
Specifications for Rad Hard QML devices are controlled
by the Defense Supply Center in Columbus (DSCC). The
SMD numbers listed here must be used when ordering.
Detailed Electrical Specifications for these devices are
contained in SMD 5962-95688. A “hot-link” is provided
on our homepage for downloading.
www.intersil.com/spacedefense/space.asp
Features
• Electrically Screened to SMD # 5962-95688
• QML Qualified per MIL-PRF-38535 Requirements
• High Input Impedance (HS-2620RH) . . . . . . . 65MΩ (Min)
• High Gain (HS-2620RH) . . . . . . . . . . . . . . . . 100kV/V (Min)
150kV/V (Typ)
• High Slew Rate (HS-2620RH) . . . . . . . . . . . . . . 25V/µs (Min)
35V/µs (Typ)
• Low Input Bias Current (HS-2620RH) . . . . . . . 15nA (Max)
5nA (Typ)
• Low Input Offset Voltage (HS-2620RH) . . . . . . 4mV (Max)
• Wide Gain Bandwidth Product (AV
5) . . . . . .100MHz (Typ)
• Output Short Circuit Protection
• Total Dose . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 x 10
4
RAD(Si)
Applications
• Video and RF Amplifiers
• Pulse Amplifiers
• Audio Amplifiers and Filters
• High-Q Active Filters
• High Speed Comparators
Ordering Information
ORDERING NUMBER
5962D9568801VGA
5962D9568801VPA
5962D9568801VPC
5962D9568802VGA
5962D9568802VPA
5962D9568802VPC
INTERNAL
MKT. NUMBER
HS2-2620RH-Q
HS7-2620RH-Q
HS7B-2620RH-Q
HS2-2622RH-Q
HS7-2622RH-Q
HS7B-2622RH-Q
TEMP. RANGE
(
o
C)
-55 to 125
-55 to 125
-55 to 125
-55 to 125
-55 to 125
-55 to 125
Pinouts
HS7-2620RH, HS7-2622RH (CERDIP) GDIP1-T8
OR
HS7B-2620RH, HS7B-2622RH (SBDIP) CDIP2-T8
TOP VIEW
BAL
-IN
+IN
V-
1
2
3
4
8
COMP
V+
OUT
BAL
IN-
2
BAL
1
HS2-2620RH, HS2-2622RH (CAN) MACY1-X8
TOP VIEW
COMP
8
7
V+
-
+
7
6
5
-
+
3
4
V-
5
6
OUT
IN+
BAL
1
CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.
1-888-INTERSIL or 321-724-7143 | Copyright © Intersil Corporation 1999

5962D9568801VGA Related Products

5962D9568801VGA 5962D9568802VPA 5962D9568802VGA
Description Operational Amplifier, 1 Func, 4000uV Offset-Max, BIPolar, MBCY8 Operational Amplifier, 1 Func, 7000uV Offset-Max, CDIP8, CERAMIC, DIP-8 Operational Amplifier, 1 Func, BIPolar, MBCY8
Reach Compliance Code unknown unknown unknown
ECCN code EAR99 EAR99 EAR99
Amplifier type OPERATIONAL AMPLIFIER OPERATIONAL AMPLIFIER OPERATIONAL AMPLIFIER
JESD-30 code O-MBCY-W8 R-GDIP-T8 O-MBCY-W8
JESD-609 code e0 e0 e0
Nominal Negative Supply Voltage (Vsup) -15 V -15 V -15 V
Number of functions 1 1 1
Number of terminals 8 8 8
Maximum operating temperature 125 °C 125 °C 125 °C
Minimum operating temperature -55 °C -55 °C -55 °C
Package body material METAL CERAMIC, GLASS-SEALED METAL
Package shape ROUND RECTANGULAR ROUND
Package form CYLINDRICAL IN-LINE CYLINDRICAL
Certification status Not Qualified Not Qualified Not Qualified
Nominal supply voltage (Vsup) 15 V 15 V 15 V
surface mount NO NO NO
Temperature level MILITARY MILITARY MILITARY
Terminal surface TIN LEAD TIN LEAD TIN LEAD
Terminal form WIRE THROUGH-HOLE WIRE
Terminal location BOTTOM DUAL BOTTOM
total dose 10k Rad(Si) V 10k Rad(Si) V 10k Rad(Si) V
Maker Harris - Harris
Maximum average bias current (IIB) 0.015 µA 0.06 µA -
Maximum input offset voltage 4000 µV 7000 µV -
technology BIPOLAR - BIPOLAR
Nominal Uniform Gain Bandwidth 100000 kHz - 100000 kHz
