KMM464S924AT1-FH datasheet, PDF

Datasheet> All Categories > storage> storage> KMM464S924AT1-FH

KMM464S924AT1-FH: DescriptionSynchronous DRAM Module, 8MX64, 6ns, CMOS; Categorystorage storage; File Size162KB，10 Pages; ManufacturerSAMSUNG; Websitehttp://www.samsung.com/Products/Semiconductor/

Download Datasheet Parametric Compare View All

KMM464S924AT1-FH Overview

Synchronous DRAM Module, 8MX64, 6ns, CMOS

KMM464S924AT1-FH Parametric

Parameter Name	Attribute value
Maker	SAMSUNG
package instruction	,
Reach Compliance Code	unknown
ECCN code	EAR99
access mode	FOUR BANK PAGE BURST
Maximum access time	6 ns
Other features	AUTO/SELF REFRESH
JESD-30 code	R-XDMA-N144
memory density	536870912 bit
Memory IC Type	SYNCHRONOUS DRAM MODULE
memory width	64
Number of functions	1
Number of ports	1
Number of terminals	144
word count	8388608 words
character code	8000000
Operating mode	SYNCHRONOUS
Maximum operating temperature	70 °C
Minimum operating temperature
organize	8MX64
Package body material	UNSPECIFIED
Package shape	RECTANGULAR
Package form	MICROELECTRONIC ASSEMBLY
Certification status	Not Qualified
self refresh	YES
Maximum supply voltage (Vsup)	3.6 V
Minimum supply voltage (Vsup)	3 V
Nominal supply voltage (Vsup)	3.3 V
surface mount	NO
technology	CMOS
Temperature level	COMMERCIAL
Terminal form	NO LEAD
Terminal location	DUAL

Preview

Download Datasheet

View All

KMM464S924AT1

Revision History

Revision 0.0 (June 7, 1999)

PC100 SODIMM

• Changed tRDL from 1CLK to 2CLK in OPERATING AC PARAMETER.

• Skip ICC4 value of CL=2 in DC characteristics in datasheet.

• Define a new parameter of tDAL( 2CLK +20ns), Last data in to Active delay in OPERATING AC PARAMETER.

• Eliminated FREQUENCY vs.PARAMETER RELATIONSHIP TABLE.

• Symbol Change Notice

Before

Input leakage current (inputs)

Input leakage current (I/O pins)

Output open @ DC characteristic table

After

Input leakage current

Output open @ DC characteristic table

•

Test Condition in

DC CHARACTERISTIC Change Notice

Symbol

CC2P ,

CC3P

CC2N ,

CC3N

CC4

Before

CKE

≤

(max), t

= 15ns

CKE

≥

(min), CS

≥

(min), t

= 15ns

Input signals are changed one time during 30ns

2 Banks activated

After

CKE

≤

(max), t

= 10ns

CKE

≥

(min), CS

≥

(min), t

= 10ns

Input signals are changed one time during 20ns

4 Banks activated

Rev. 0.0 Jun. 1999
