Z06FF5: DescriptionRectifier Diode, 1 Phase, 1 Element, 2.2A, 600V V(RRM), Silicon,; CategoryDiscrete semiconductor diode; File Size103KB，2 Pages; ManufacturerVOLTAGE MULTIPLIERS INC.; Websitehttp://www.voltagemultipliers.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

Z06FF5 Overview

Rectifier Diode, 1 Phase, 1 Element, 2.2A, 600V V(RRM), Silicon,

Z06FF5 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	VOLTAGE MULTIPLIERS INC.
package instruction	E-LALF-W2
Reach Compliance Code	compliant
ECCN code	EAR99
application	GENERAL PURPOSE
Shell connection	ISOLATED
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	2.5 V
JESD-30 code	E-LALF-W2
Maximum non-repetitive peak forward current	60 A
Number of components	1
Phase	1
Number of terminals	2
Maximum operating temperature	175 °C
Maximum output current	2.2 A
Package body material	GLASS
Package shape	ELLIPTICAL
Package form	LONG FORM
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	600 V
Maximum reverse recovery time	0.05 µs
surface mount	NO
Terminal form	WIRE
Terminal location	AXIAL

Preview

Download Datasheet

View All

600 V - 1,000 V Rectifiers

1.2A - 2.2A Forward Current

30 ns - 50 ns Recovery Time

AXIAL LEADED

HERMETICALLY SEALED

Z06FF3 Z10FF3

Z06FF5 Z10FF5

ELECTRICAL CHARACTERISTICS AND MAXIMUM RATINGS

Part

Working

Number Reverse

Voltage

(Vrwm)

Average

Rectified

Current

(Io)

Reverse

Current

@ Vrwm

(Ir)

Forward

Voltage

1 Cycle Repetitive Reverse

Surge

Recovery

Current

Time

tp=8.3ms

(3)

(Ifsm)

(Ifrm)

(Trr)

25°C

Amps

25°C

Amps

25°C

Thermal

Impedance

Junction

Cap.

@50VDC

@ 1kHZ

(Cj)

25°C

(Vf)

25°C

Volts

Amps

J-L

L=.125 L=.375 L=.500

°C/W

55°C(1) 100°C(2) 25°C 100°C

Volts

Z06FF3

Z10FF3

Z06FF5

Z10FF5

Amps

µA

600

1000

600

1000

2.00

1.20

2.20

2.00

1.30

0.80

1.50

1.30

1.0

2.5

4.0

2.0

2.2

2.0

1.5

2.0

12.0

10.0

12.0

10.0

(1)TL=55°C L=0.375" (2)TL=100°C L=0.375" (3)If=0.5A, Ir=1.0A, Irr=0.25A • Op.Temp.= -65°C to +175°C Stg.Temp.= -65°C to +200°C

.180(4.6)

MAX.

.185(4.7)

MAX.

1.00(25.4)

MIN.

.040 ±.003

(1.02 ±.06)

Dimensions: In. (mm) • All temperatures are ambient unless otherwise noted. • Data subject to change without notice.

VOLTAGE MULTIPLIERS INC.

8711 W. Roosevelt Ave.

Visalia, CA 93291

TEL

559-651-1402

FAX

559-651-0740

www.voltagemultipliers.com

Z06FF5 Related Products

	Z06FF5	Z06FF3
Description	Rectifier Diode, 1 Phase, 1 Element, 2.2A, 600V V(RRM), Silicon,	Rectifier Diode, 1 Phase, 1 Element, 2A, 600V V(RRM), Silicon,
Is it Rohs certified?	conform to	conform to
Maker	VOLTAGE MULTIPLIERS INC.	VOLTAGE MULTIPLIERS INC.
package instruction	E-LALF-W2	E-LALF-W2
Reach Compliance Code	compliant	compliant
ECCN code	EAR99	EAR99
application	GENERAL PURPOSE	GENERAL PURPOSE
Shell connection	ISOLATED	ISOLATED
Configuration	SINGLE	SINGLE
Diode component materials	SILICON	SILICON
Diode type	RECTIFIER DIODE	RECTIFIER DIODE
Maximum forward voltage (VF)	2.5 V	2.5 V
JESD-30 code	E-LALF-W2	E-LALF-W2
Maximum non-repetitive peak forward current	60 A	60 A
Number of components	1	1
Phase	1	1
Number of terminals	2	2
Maximum operating temperature	175 °C	175 °C
Maximum output current	2.2 A	2 A
Package body material	GLASS	GLASS
Package shape	ELLIPTICAL	ELLIPTICAL
Package form	LONG FORM	LONG FORM
Certification status	Not Qualified	Not Qualified
Maximum repetitive peak reverse voltage	600 V	600 V
Maximum reverse recovery time	0.05 µs	0.03 µs
surface mount	NO	NO
Terminal form	WIRE	WIRE
Terminal location	AXIAL	AXIAL
