Light Emitting Diodes
LNP125024
Pandel Display Units
RG Type
Structure
Illumination color: Red, Green, Amber (Red and Green lighting)
Display surface: 96 mm
×
96 mm
Number of dots (dot): 256 (16
×
16 dot)
Dot size: 3.2 mm
×
2.5 mm, Dome type chip LED
Dot pitch: 6.0 mm
Absolute Maximum Ratings
T
a
= 25°C
Parameter
Operating supply voltage
LED operating supply voltage
Input voltage
Operating ambient temperature
Storage temperature
Symbol
V
CC
V
LEDA
V
IN
T
opr
T
stg
Rating
– 0.3 to +5.5
+5.5
– 0.3 to V
CC
+ 0.3
–10 to +45
–25 to +80
Unit
V
V
V
°C
°C
Recommending Operating Conditions
T
a
= 25°C±3°C
Parameter
Operating supply voltage
LED operating supply voltage
Input voltage
Symbol
V
CC
V
LEDA
V
IN
Min
4.75
4.80
0.00
Typ
5.00
5.00
Max
5.25
5.20
V
CC
Unit
V
V
V
Electro-Optical Characteristics
T
a
= 25°C±3°C, V
CC
= V
LEDA
= 5.0 V
Parameter
Brightness
Drive system
Clock frequency
Supply current (Logic)
*
Supply current (LED)
*
Note) *: Two-color all lighting
Symbol
f
CLK
I
CC(LOGIC)
I
CC(LED)
Red
Green
Max. 20
Max. 0.1
Max. 2.5
Specification
Typ. 130
Typ. 150
Unit
cd/m
2
cd/m
2
MHz
A
A
Duty 1/16 Dynamic lighting
Publication date: July 2008
SHJ00052AEK
1
