Pomona
®
Model 5250, 5251, 5252, 5253, 5254 & 5437
Chip Lead Spacing: 0.050” (1,27)
These new test clips are designed
especially for in-circuit testing on Small
Outline Integrated Circuits (SOIC & SOJ).
The SOIC Clip test clip assures a positive
connection to all chip leads and provides
hands-free testing.
•
Upper contacts are .025" sq. pins,
spaced at .100". Pins are perfect for
sq. pin receptacles, wire-wrap or
jumper leads.
Gold plated lower contacts assure
reliable, noise free connections.
Molded barriers between each contact
allow connections to be made on live
boards without accidental shorting to
adjacent chip leads.
•
•
Fits surface mounted SOIC and SOJ chips
with gull wing or “J” leads and body width
from .150" to .350" wide.
Model 5514 is a kit of eight SOIC Test Clips, from 8 through 28 pins.
Model
Number
5250
No. of
Pins
Width
"A"
.430
Width
"B"
.260
(6,6)
.410
(10,41)
.460
(11,68)
Model
Number
5253
No. of
Pins
Width
"A"
1.030
Width
"B"
.560
(14,22)
.660
(16,76)
.760
(19,3)
8
(10,92)
.755
20
(26,16)
1.230
5251
14
(19,18)
.830
5254
24
(31,24)
1.430
5252
16
(21,08)
5437
28
(36,32)
All dimensions are in inches. Tolerances (except noted): .xx = ±.02” (,51 mm), .xxx = ± .005” (,127 mm).
All specifications are to the latest revisions. Specifications are subject to change without notice.
Registered trademarks are the property of their respective companies. Made in USA
7/1/02
SY/EH/LS
Sales: 800-490-2361 Fax: 888-403-3360
Technical Assistance: 800-241-2060
PomonaACCESS
90320
(800) 444-6785 or (425) 446-6010
More drawings available at www.pomonaelectronics.com
Page 1 of 1
