PI74FCT162Q245T
LOW NOISE 16-BIT BIDIRECTIONAL TRANSCEIVERS
PI74FCT162Q245T
21098765432121098765432109876543210987654321210987654321098765432109876543212109876543210987654321098765432121098765432109876543210987654321
21098765432121098765432109876543210987654321210987654321098765432109876543212109876543210987654321098765432121098765432109876543210987654321
Product Features:
• V
CC
= 5V ±10%
• Balanced output drivers:
±12 mA
• Output impedance:
35Ω (typical)
• Typical V
OLP
(Output Ground Bounce) < 0.5V
at V
CC
= 5V, T
A
= 25°C
• Bus Hold retains last active bus state during tri-state
• Hysteresis on all inputs
• Packages available:
– 48-pin 240-mil wide plastic TSSOP (A48)
– 48-pin 300-mil wide plastic SSOP (V48)
– 48-pin 150-mil wide plastic BQSOP (B48)
• Device models available on request
Fast, Low Noise CMOS 16-Bit
Bidirectional Transceivers
Product Description:
Pericom Semiconductor’s PI74FCT series of logic circuits are pro-
duced in the Company’s advanced 0.6 micron CMOS technology,
achieving industry leading speed grades.
The PI74FCT162Q245T is a 16-bit bidirectional transceiver designed
for asynchronous two-way communication between data buses.
The direction control input pin (xDIR) determines the direction of
data flow through the bidirectional transceiver. The Direction and
Output Enable controls are designed to operate these devices as
either two independent 8-bit transceivers or one 16-bit transceiver.
The output enable (OE) input, when HIGH, disables both A and B
ports by placing them in HIGH Z condition.
The PI74FCT162Q245T is designed with current limiting resistors
at its outputs to control the output edge rate resulting in lower
ground bounce and undershoot. This device features a typical
output impedance of 35Ω, eliminating the need for external
terminating resistors for most bus interface applications. This noise
suppression benefit is designated by the letter “Q” (for quiet) in the
part number.
The PI74FCT162Q245T also features “Bus Hold” which retains
the input’s last state whenever the input goes to high-impedance
preventing “floating” inputs and eliminating the need for pullup/
down resistors.
Logic Block Diagram
1
DIR
2
DIR
1
OE
2
OE
1
A
0
1
B
0
1
A
1
1
B
1
1
A
2
1
B
2
1
A
3
1
B
3
1
A
4
1
B
4
1
A
5
1
B
5
1
A
6
1
B
6
1
A
7
1
B
7
2
A
0
2
B
0
2
A
1
2
B
1
2
A
2
2
B
2
2
A
3
2
B
3
2
A
4
2
B
4
2
A
5
2
B
5
2
A
6
2
B
6
2
A
7
2
B
7
290
PS2050A 04/12/96
Product Pin Description
Pin Name
xOE
xDIR
xAx
xBx
GND
V
CC
Description
Output Enable Inputs (Active LOW)
Direction Control Input
Side A Inputs or 3-State Outputs
(1)
Side B Inputs or 3-State Outputs
(1)
Ground
Power
21098765432121098765432109876543210987654321210987654321098765432109876543212109876543210987654321098765432121098765432109876543210987654321
PI74FCT162Q245T
LOW NOISE 16-BIT BIDIRECTIONAL TRANSCEIVERS
Truth Table
Inputs
(1)
X
OE
L
L
H
xDIR
L
H
X
Outputs
(1)
Bus B Data to Bus A
Bus A Data to Bus B
High Z State
Note:
1. For the PI74FCT162Q245T, these pins have “Bus
Hold.” All other pins are standard, outputs, or I/Os.
Note:
1. H = High Voltage Level
X = Don’t Care
L = Low Voltage Level
Z = High Impedance
Product Pin Configuration
1
DIR
1
B
0
1
B
1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
48
47
46
45
44
43
42
41
40
1
OE
1
A
0
1
A
1
GND
1
B
2
1
B
3
GND
1
A
2
1
A
3
V
CC
1
B
4
1
B
5
V
CC
1
A
4
1
A
5
GND
1
B
6
1
B
7
2
B
0
2
B
1
48-PIN
A48
B48
V48
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
GND
1
D
6
1
A
7
2
A
0
2
A
1
GND
2
B
2
2
B
3
GND
2
A
2
2
A
3
V
CC
2
B
5
2
B
5
GND
2
B
6
2
B
7
2
DIR
V
CC
2
A
4
2
A
5
GND
2
A
6
2
A
7
2
OE
291
PS2050A 04/12/96
