HI1-0549-2 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> The signal circuit> HI1-0549-2

HI1-0549-2: Description4-CHANNEL, DIFFERENTIAL MULTIPLEXER, CDIP16, FRIT SEALED, CERDIP-16; CategoryAnalog mixed-signal IC The signal circuit; File Size901KB，25 Pages; ManufacturerRenesas Electronics Corporation; Websitehttps://www.renesas.com/

Download Datasheet Parametric View All

HI1-0549-2 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	HI1-0549-2	-	-	View	Buy Now

HI1-0549-2 Overview

4-CHANNEL, DIFFERENTIAL MULTIPLEXER, CDIP16, FRIT SEALED, CERDIP-16

HI1-0549-2 Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Renesas Electronics Corporation
Parts packaging code	DIP
package instruction	DIP, DIP16,.3
Contacts	16
Reach Compliance Code	not_compliant
ECCN code	EAR99
Factory Lead Time	19 weeks
Other features	OVERVOLTAGE PROTECTION
Analog Integrated Circuits - Other Types	DIFFERENTIAL MULTIPLEXER
JESD-30 code	R-CDIP-T16
JESD-609 code	e0
Nominal Negative Supply Voltage (Vsup)	-15 V
Number of channels	4
Number of functions	1
Number of terminals	16
Nominal off-state isolation	68 dB
On-state resistance matching specifications	105 Ω
Maximum on-state resistance (Ron)	1500 Ω
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package body material	CERAMIC, METAL-SEALED COFIRED
encapsulated code	DIP
Encapsulate equivalent code	DIP16,.3
Package shape	RECTANGULAR
Package form	IN-LINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
power supply	+-15 V
Certification status	Not Qualified
Maximum seat height	5.08 mm
Maximum signal current	0.02 A
Maximum supply current (Isup)	2 mA
Nominal supply voltage (Vsup)	15 V
surface mount	NO
Maximum disconnect time	500 ns
Maximum connection time	500 ns
switch	BREAK-BEFORE-MAKE
technology	CMOS
Temperature level	MILITARY
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
width	7.62 mm

Preview

Download Datasheet

View All

DATASHEET

HI-546, HI-547, HI-548, HI-549

Single 16 and 8, Differential 8-Channel and 4-Channel CMOS Analog MUXs with

Active Overvoltage Protection

The HI-546, HI-547, HI-548 and HI-549 are analog

multiplexers with active overvoltage protection and

guaranteed r

matching. Analog input levels may greatly

exceed either power supply without damaging the device or

disturbing the signal path of other channels. Active

protection circuitry assures that signal fidelity is maintained

even under fault conditions that would destroy other

multiplexers.

Analog inputs can withstand constant 70V

P-P

levels with

15V

supplies. Digital inputs will also sustain continuous

faults up to 4V greater than either supply. In addition, signal

sources are protected from short circuiting should

multiplexer supply loss occur. Each input presents 1k of

resistance under this condition. These features make the

HI-546, HI-547, HI-548 and HI-549 ideal for use in systems

where the analog inputs originate from external equipment

or separately powered circuitry. All devices are fabricated

with 44V Dielectrically Isolated CMOS technology. The

HI-546 is a single 16-Channel, the HI-547 is an 8-Channel

differential, the HI-548 is a single 8-Channel and the HI-549

is a 4-Channel differential device. If input overvoltage

protection is not needed the HI-506/507/508/509

multiplexers are recommended. For further information see

Application Notes AN520 and AN521.

For MIL-STD-883 compliant parts, request the HI-546/883,

HI-547/883, HI-548/883 and HI-549/883 datasheets.

FN3150

Rev 7.00

Jun 15, 2016

Features

• Analog Overvoltage Protection. . . . . . . . . . . . . . . . . . 70V

P-P

• No Channel Interaction During Overvoltage

• Guaranteed r

Matching

• Maximum Power Supply . . . . . . . . . . . . . . . . . . . . . . 44V

• Break-Before-Make Switching

• Analog Signal Range . . . . . . . . . . . . . . . . . . . . . . . .

15V

• Access Time (Typical) . . . . . . . . . . . . . . . . . . . . . . . 500ns

• Standby Power (Typical) . . . . . . . . . . . . . . . . . . . . 7.5mW

• Pb-Free Plus Anneal Available (RoHS Compliant)

Applications

• Data Acquisition

• Industrial Controls

• Telemetry

FN3150 Rev 7.00

Jun 15, 2016

Page 1 of 25
