DTC114 TM/TE/TUA/TCA/TSA
NPN Small Signal Transistor
Small Signal Product
Features
◇
Built-in bias resistors enable the configuration of an inverter
circuit without connecting external input resistor
(see equivalent circuit).
◇
The bias resistors consist of thin -film resistors with
complete isolation to allow negative biasing of the input.
◇
They also have the advantage of almost completely
eliminating parasitic effects.
◇
Only the on/off conditions need to be set for
operation,marking device design easy.
◇
Green compound (Halogen free) with suffix "G" on
packing code and prefix "G" on date code.
Equivalent Circuit
Ordering Information (example)
Part No.
DTC114 TM
Package
SOT-723
Packing
8K / 7" Reel
Packing code
RM
Packing code
(Green)
RMG
Manufacture code
M0
Marking
04
Note : Detail please see "Ordering Information(detail, example)" below
Maximum Ratings and Electrical Characteristics
Rating at 25°C ambient temperature unless otherwise specified.
Maximum Ratings
Parameter
Power Dissipation
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Collector Current -Continuous
Junction and Storage Temperature Range
Symbol
PD
V
CBO
V
CEO
V
EBO
I
C
TJ, T
STG
Value
TM
100
TE
150
EUA / ECA
200
50
50
5
100
-55 to + 150
ESA
300
Units
mW
V
V
V
mA
°C
Notes: 1. Valid provided that electrodes are kept at ambient temperature
Electrical Characteristics
Parameter
Collector-base breakdown voltage
Collector-emitter breakdown voltage
Emitter-base breakdown voltage
Collector cut-off current
Emitter cut-off current
DC Current Gain
Collector-emitter saturation voltage
Transition frequency
Imput resistor
Symbol
V
(BR)CBO
V
(BR)CEO
V
(BR)EBO
I
CBO
I
EBO
h
FE
V
CE(sat)
f
T
R
1
Min
50
50
5
Typ
Max
Condtion
Ic=50μA,I
E
=0
Ic=1mA,IB=0
I
E
=50μA,I
C
=0
Unit
V
V
V
μA
μA
V
MHz
KΩ
0.5
0.5
100
250
7
10
13
300
600
0.3
V
CB
=50V,I
E
=0
V
EB
=4V,IC=0
V
CE
=5V,I
C
=1mA
I
C
=10mA,I
B
=1mA
V
CE
=10V,I
E
=-5mA, f=100MHz
Version : B13
