DTC123 YE/YUA/YCA/YSA
NPN Small Signal Transistor
Small Signal Diode
Features
Built-in bias resistors enable the configuration of an inverter
circuit without connecting external input resistor
(see equivalent circuit).
The bias resistors consist of thin -film resistors with
complete isolation to allow negative biasing of the input.
They also have the advantage of almost completely
eliminating parasitic effects.
Only the on/off conditions need to be set for
operation,marking device design easy.
Green compound (Halogen free) with suffix "G" on
packing code and prefix "G" on date code.
Ordering Information
Package
SOT-523
SOT-323
SOT-23
TO-92S
Part No.
DTC123 YE
DTC123 YUA
DTC123 YCA
DTC123 YSA
Packing
3K / 7" Reel
3K / 7" Reel
3K / 7" Reel
3K / 7" Reel
Marking
62
62
62
Maximum Ratings and Electrical Characteristics
Rating at 25°C ambient temperature unless otherwise specified.
Value
JUA
JCA
200
50
-5½12
100
100
-55 to + 150
°C
Type Number
Power Dissipation
Supply Voltage
Input Voltage
Output Current
Junction and Storage Temperature Range
Symbol
PD
V
CC
V
IN
I
O
I
C(MAX)
TJ, T
STG
JE
150
JSA
300
Units
mW
V
V
mA
Notes:1. Valid provided that electrodes are kept at ambient temperature
Parameter
Input Voltage
Output Voltage
Input Current
Output Current
DC Current Gain
Input Resistance
Resistance Ratio
Transition Frequency
Symbol
V
I(off)
V
I(on)
V
O(on)
I
I
I
O（off)
G
I
R
1
R
2
/R
1
f
T
Min
0.3
Typ
Max
3
Condtion
V
CC
=5V,I
O
=100μA
V
O
=0.3V,I
O
=20mA
I
O
/I
I
=10mA/0.5mA
V
I
=5V
V
CC
=50V,V
I
=0
V
O
=5V,I
O
=10mA
Unit
V
V
V
mA
μA
0.1
0.3
3.8
0.5
33
1.54
3.6
2.2
4.5
250
2.86
5.5
KΩ
V
O
=10V,I
O
=5mA,f=100MHz
MHz
Version:A12
