Z+A1SA
DTC143 ZM/ZE/ZUA/ZCA/ZSA
NPN Small Signal Transistor
Small Signal Diode
Features
Built-in bias resistors enable the configuration of an inverter
circuit without connecting external input resistor
(see equivalent circuit).
The bias resistors consist of thin -film resistors with
complete isolation to allow negative biasing of the input.
They also have the advantage of almost completely
eliminating parasitic effects.
Only the on/off conditions need to be set for
operation,marking device design easy.
Green compound (Halogen free) with suffix "G" on
packing code and prefix "G" on date code.
Ordering Information
Package
SOT-723
SOT-523
SOT-323
SOT-23
TO-92S
Part No.
DTC143 ZM
DTC143 ZE
DTC143 ZUA
DTC143 ZCA
DTC143 ZSA
Packing
8K / 7" Reel
3K / 7" Reel
3K / 7" Reel
3K / 7" Reel
3K / 7" Reel
Marking
E23
E23
E23
E23
Maximum Ratings and Electrical Characteristics
Rating at 25°C ambient temperature unless otherwise specified.
Value
ZUA ZCA
200
50
-5½30
100
100
-55 to + 150
Type Number
Power Dissipation
Supply Voltage
Input Voltage
Output Current
Junction and Storage Temperature Range
Symbol
PD
V
CC
V
IN
I
O
I
C(MAX)
TJ, T
STG
ZM
100
ZE
150
XSA
300
Units
mW
V
V
mA
mA
°C
Notes:1. Valid provided that electrodes are kept at ambient temperature
Parameter
Input Voltage
Output Voltage
Input Current
Output Current
DC Current Gain
Input Resistance
Resistance Ratio
Transition Frequency
Symbol
V
I(off)
V
I(on)
V
O(on)
I
I
I
O（off)
G
I
R
1
R
2
/R
1
f
T
Min
0.5
Typ
Max
1.3
Condtion
V
CC
=5V,I
O
=100μA
V
O
=0.3V,I
O
=5mA
I
O
/I
I
=5mA/0.25mA
V
I
=5V
V
CC
=50V,V
I
=0
V
O
=5V,I
O
=-10mA
Unit
V
V
V
mA
μA
0.1
0.3
1.8
0.5
80
3.29
8
4.7
10
250
6.11
12
KΩ
V
CE
=10V,I
E
=-5mA,f=100MHz
MHz
Version:A12
