MOEH & MOEZ Series – Euro Package 5 Pin OCXO
Oven Controlled Oscillator
1.0 MHz to 150.0 MHz Available
SC Crystal Option
RoHS Option Available
±2ppb to ±500ppb
Frequency Range
Stability
Frequency at +25ºC at time of shipment
Frequency vs. Ambient
Frequency vs. Voltage
Frequency vs. Load
Frequency
vs. Time
Warm Up
Supply and Reference Voltages
Supply Voltage (V
dd
)
Supply
Current
Reference Voltage (Output)
Output
HCMOS
Logic “0” (max)
Logic “1” (min)
Symmetry (50% of Waveform)
Load
SINEWAVE
Amplitude
Spurious (Harmonics)
Spurious (Non Harmonics)
Load
Electronic Frequency Control
Control Voltage Range
V
nom
(Pin 1)
Total
Frequency
Change
Slope
Input Impedance
10 Hz
Phase Noise at 10.000MHZ
100 Hz
1 kHz
10 kHz
AT Cut
SC Cut
0.00 to +3.30 VDC
+1.65 VDC
0.00 to + 5.00 VDC
+2.50 VDC
±1.0 ppm typ
±0.6 ppm min
Positive
100kΩ typ
SC Cut Crystal
110 dBC
-130 dBc
-140 dBc
-155 dBc
AT Cut Crystal
-100 dBc
-110 dBc
-135 dBc
-140 dBc
0.00 to + 5.00 VDC
+2.50 VDC
See Part Number Guide for Options
-20 dBc
-80 dBc
50Ω
+0.33 VDC
+2.97 VDC
+0.50 VDC
+4.50 VDC
See Part Number Guide for Options
15pF
+0.50 VDC
+4.50 VDC
Steady State
Warm Up
+3.30 VDC ±5%
540 mA
1000 mA
+3.00 VDC ±5%
+5.00 VDC ±5%
360 mA
720 mA
+4.00 VDC ±5%
+12.00 VDC ±5%
150 mA
650 mA
4.00 VDC ±5%
AT Cut
SC Cut
±10 ppb at +25ºC with V
nom
on Pin 1
See Part Number Guide for Options
Less than ±5 ppb for 5% change in Supply Voltage
Less than ±5 ppb for 5% change in Load
±1.0 ppm per year after 30 days
±0.1 ppm per year after 30 days
3 min at +25ºC to ±1.0 ppm of final frequency (1 hr reading)
1.000MHZ to 150.000MHZ
MMD Monitor/Quartztek
30400 Esperanza, Rancho Santa Margarita, CA, 92688
Phone: (949) 709-5075, Fax: (949) 709-3536,
www.mmdcomp.com
Sales@mmdcomp.com
Revision:
Revisions only with customer approval
MOEH060611F
Pg 1 of 2
Part Number Guide
MOE
Frequ ency
O utput
H = HCM O S
Z3 = Sinew ave + 3dBm
Z7 = Sinew ave + 7dBm
H eigh t
A = 18.64 [.734]
B = 13.46 [.530]
R oH S C om pliant
Blank = N ot Com pliant
F = is Com pliant
Su pply Voltage
3 = + 3.30 VDC
5 = + 5.00 VDC
12 = + 12.00 VD C
C rystal Cut
Blank = AT Cut*
S = SC Cut
Frequen cy
Stability
002 = ±2 ppb
005 = ±5 ppb
010 = ± 10 ppb
050 = ± 50 ppb
XXX = 3 digits in ppb
O perating
T em peratu re
A = 0°C to + 50°C
C = -20°C to + 70°C
D = -30°C to + 70°C
E = -30°C to + 80°C
F = -40°C to + 85°C
G = 0°C to + 70°C
Sym m etry
Blank = 40% /60%
A = 45% /55%
Value Added O ption s
Blank = N o Added O ptions
S3 = Stratum 3
Please Consult with M M D Sales D epartm ent for any other Param eters or O ptions
*AT Cut Crystal cannot be used in all Tem perature/Stability options
Mechanical Details
35.33 [1.391]
H DIM
6.35 [.250]
MIN
25.40 [1.000]
12.70 [.500]
3
4
PIN
PIN
PIN
PIN
PIN
PIN CONNECTIONS
1 FREQUENCY CONTROL
2 REFERENCE VOLTAGE
3
SUPPLY VOLTAGE
4
OUTPUT
5
GROUND
MMD
PART NUMBER
FREQUENCY
SYYWWL
26.97 [1.062]
0.80 [.031]
17.60 [.693]
2
15.24 [.600]
A
B
HEIGHT DIMENSION
18.64 [.734]
13.46 [.530]
8.80 [.346]
0.51 [.020]
Ø2.00 [Ø.079]
DIMENSION IN BRACKETS ARE IN INCHES
EXTERNAL BYPASS CAPACITOR IS RECOMMENDED
PIN NUMBERS ARE FOR REFERENCE ONLY
1
5
17.78 [.700]
Environmental/Mechanical Specification
Shock
Solderability
Vibration
Gross Leak Test
Fine Leak Test
MSL
MIL-STD-883, Meth 2002, Cond B
MIL-STD-883, Meth 2003
MIL-STD-883, Meth 2007, Cond A
MIL-STD-883, Meth 1014, Cond C
MIL-STD-883, Meth 1014, Cond A
Level 1 per IPC/JEDEC’S J-STD-20
Marking Detail
Line 1 = MMD
Line 2 = MMD Part Number (per sales order)
Line 3 = Frequency Output (per sales order)
Line 4 = SYYWWL
S
YY
= Internal Code
YY = Year, 2 numerical digits that rep-
= resents the last 2 digits of the year of
manufacture.
WW = Week, 2 numerical digits that
= represents the week of the year that
the OCXO was manufactured.
= Denotes RoHS Compliant
WW
L
Pin 1 Designator
MMD Monitor/Quartztek
30400 Esperanza, Rancho Santa Margarita, CA, 92688
Phone: (949) 709-5075, Fax: (949) 709-3536,
www.mmdcomp.com
Sales@mmdcomp.com
Revision:
Revisions only with customer approval
MOEH060611F
Pg 2 of 2
