1 Watt
IQ Series
•
•
•
•
•
•
•
Single & Dual Output
SIP Package
1000 VDC Isolation
Optional 3000 VDC Isolation
40 °C to +85 °C Operation
Semi regulated
3 Year Warranty
DC DC
xppower.com
Specification
Input
Input Voltage Range
Input Reflected
Ripple Current
Input Reverse Voltage
Protection
• Nominal ±10%
• 5 & 12 V: 20 mA, 15 V: 30 mA
24 V: 40 mA, 48 V: 50 mA pk-pk,
5 Hz to 20 MHz
• None
Input Output
Voltage Voltage
5.0 V
5 VDC
9.0 V
12.0 V
15.0 V
5.0 V
12 VDC
9.0 V
12.0 V
15.0 V
5.0 V
15 VDC
9.0 V
12.0 V
15.0 V
5.0 V
24 VDC
9.0 V
12.0 V
15.0 V
5.0 V
48 VDC
9.0 V
12.0 V
15.0 V
Max
Output No Load
Input Capacitive Efficiency
Current
Current
Load
200 mA
111 mA
83 mA
67 mA
200 mA
111 mA
83 mA
67 mA
200 mA
111 mA
83 mA
67 mA
200 mA
111 mA
83 mA
67 mA
200 mA
111 mA
83 mA
67 mA
20 mA
20 mA
20 mA
20 mA
15 mA
15 mA
15 mA
15 mA
10 mA
10 mA
10 mA
10 mA
7 mA
7 mA
7 mA
7 mA
5 mA
5 mA
5 mA
5 mA
200 µF
200 µF
100 µF
100 µF
200 µF
200 µF
100 µF
100 µF
200 µF
200 µF
100 µF
100 µF
200 µF
200 µF
100 µF
100 µF
200 µF
200 µF
100 µF
100 µF
83%
86%
87%
87%
84%
86%
88%
88%
84%
86%
87%
89%
81%
84%
85%
86%
78%
80%
81%
81%
Load
Reg.
6.0%
5.5%
5.5%
5.0%
4.0%
3.5%
3.5%
3.0%
4.0%
3.5%
3.5%
3.0%
4.0%
3.5%
3.5%
2.5%
4.0%
3.5%
3.0%
3.0%
Model
(3)
Number
IQ0505SA
IQ0509SA
IQ0512SA
IQ0515SA
IQ1205SA
IQ1209SA
IQ1212SA
IQ1215SA
IQ1505SA
IQ1509SA
IQ1512SA
IQ1515SA
IQ2405SA
IQ2409SA
IQ2412SA
IQ2415SA
IQ4805SA
IQ4809SA
IQ4812SA
IQ4815SA
Output
Output Voltage
•
Minimum Load
•
Line Regulation
•
Load Regulation
•
Setpoint Accuracy
•
Ripple & Noise
•
Temperature Coefficient
•
Maximum Capacitive
•
Load
See table
None
(1)
1.2%/1%
∆
Vin
See table (10-100%)
±3%
50 mV pk-pk max, 20 MHz bandwidth
0.02%/°C
See table
General
Efficiency
Isolation Voltage
Isolation Resistance
Isolation Capacitance
Switching Frequency
MTBF
•
•
•
•
•
•
See table
1000 VDC minimum, 3000 VDC option
(2)
10
9
Ω
60 pF typical
Variable, 55 kHz -85 kHz
>1.1 MHrs to MIL-HDBK-217F at 25 °C, GB
Mechanical Details
0.76 (19.5)
0.37
(9.5)
0.02
(0.5)
0.10
(2.5)
0.60 (15.2)
0.02
(0.5)
1 2
0.05 (1.2)
4 5 6 7
0.01
(0.2)
0.12 (3.0)
* The depth of
48 V input voltage
model is 0.28 (7.20)
0.24*
(6.0)
0.39
(10.0)
Environmental
Operating Temperature
Storage Temperature
Case Temperature
Cooling
•
•
•
•
-40 °C to +85 °C
-40 °C to +125 °C
100 °C max
Convection-cooled
0.24
(6.0)
Notes
1. Operation at no load will not damage unit but it may not meet
all specifications.
2. For optional 3000 VDC isolation, add suffix ‘-H’ to the model number.
3. For dual output delete suffix ‘A’ and split output current equally between rails.
4. All dimensions in inches (mm).
5. Pin pitch tolerance: ±0.014 (±0.35)
6. Case tolerance: ±0.02 (±0.5)
7. Weight: 0.06 lbs (2.8 g)
0.02 (0.5)
Pin
1
2
4
5
6
7
Single
+Vin
-Vin
-Vout
N.P
+Vout
N.P
Pin Connections
Dual
+Vin
-Vin
-Vout
Common
+Vout
N.P
Single-H
+Vin
-Vin
N.P
-Vout
N.P
+Vout
Dual-H
+Vin
-Vin
N.P
-Vout
Common
+Vout
