MIL-STD-1553 / MIL-PRF-21038
DATABUS INTERFACE TRANSFORMERS
LOW PROFILE SINGLE/DUAL
ADD "+" ON P/N FOR RoHS COMPLIANCE
*
Designed to Meet MIL-STD-1553 A/B & MIL-PRF-21038
*
Common Mode Rejection (CMR) Greater Than 45dB
*
Impedance Test Frequency from 75Khz to 1MHz
*
Droop Less Than 20%
*
Overshoot & Ringing
±
1V Max
*
Pulse Width 2
S
*
For Non-RoHS,
reflow process must not cause the peak body temperature of the device to exceed 225°C and
must not expose the device to temperature above 183°C for more than 90 seconds.
*
For RoHS (+),
reflow process must not cause the peak body temperature of the device to exceed 245°C and must
not expose the device to temperature above 217°C for more than 150 seconds.URE
RANGE -55
O
C TO +125
O
C
ELECTRICAL SPECIFICATIONS AT 25
O
C
PART
NUMBER
TERMINALS / RATIO

3%)
TERMINALS / RATIO

3%)
DCR
(Ohms Max.)
IMPEDANCE
(Ohms MIN.)
SCHEMATICS
/
PACKAGE
PM-DB2701
PM-DB2701EX
PM-DB2702
PM-DB2703
PM-DB2704
PM-DB2705
PM-DB2705EX
PM-DB2706
PM-DB2707
PM-DB2708
PM-DB2709
PM-DB2710
PM-DB2711
PM-DB2712
PM-DB2713
PM-DB2714
PM-DB2715
PM-DB2716
PM-DB2717
PM-DB2718
PM-DB2719
PM-DB2720
PM-DB2721
PM-DB2722
PM-DB2723
PM-DB2724
PM-DB2725
PM-DB2725R
PM-DB2725EX
PM-DB2726
PM-DB2727
PM-DB2728
PM-DB2729
PM-DB2730
PM-DB2731
PM-DB2755
1-3:4-8
1-3:4-8
1-3:4-8
1-3:4-8
4-8:1-3
1-2:4-3
1-2:3-4
1-5:6-2
1-5:6-2
1-5:6-2
1-5:6-2
1-3:4-8
1-3:4-8
1-3:4-8
1-3:4-8
4-8:1-3
1-3:4-8
1-3:4-8
1-3:4-8
1-3:4-8
4-8:1-3
1-3:4-8
1-3:4-8
1-3:4-8
1-3:4-8
1-3:4-8
1-3:4-8
1-3:4-8
1-3:4-8
1-3:4-8
1-3:4-8
1-5:6-2
1-5:6-2
1-5:6-2
1-3:4-8
1-3:4-8
1:1
1:1
1.4:1
1.25 : 1
2.3:1
1:1.41
1:1.41
1:1
1:1.41
1:1.66
1:2
1:2.12
1:1
1.4:1
1.25:1
2.3:1
1:2.12
1:1
1.41:1
1.25:1
2.3:1
1:2.12
1:1
1.41:1
1.25:1
1:2.12
1:2.5
1:2.5
1:2.5
1:2.5
1:2.5
1:1.5
1:1.79
1:2.5
1:2.5
1:3.75
1-3:5-7
1-3:5-7
1-3:5-7
1-3:5-7
5-7:1-3
---
---
---
---
---
---
1-3:5-7
1-3:5-7
1-3:5-7
1-3:5-7
5-7:1-3
1-3:5-7
1-3:5-7
1-3:5-7
1-3:5-7
5-7:1-3
1-3:5-7
1-3:5-7
1-3:5-7
1-3:5-7
1-3:5-7
1-3:5-7
1-3:5-7
1-3:5-7
1-3:5-7
1-3:5-7
---
---
---
1-3:5-7
1-3:5-7
1:.707
1:.707
2:1
1.66:1
3.2:1
---
---
---
---
---
---
1:1.5
1:.707
2:1
1.66:1
3.2:1
1:1.5
1:.707
2:1
1.66:1
3.2:1
1:1.5
1:.707
2:1
1.66:1
1:1.5
1:1.79
1:1.79
1:1.79
1:1.79
1:1.79
---
---
---
1:1.79
1:2.70
1-3=3.0, 4-8=3.0
1-3=3.0, 4-8=3.0
1-3=3.5, 4-8=3.0
1-3=3.2, 4-8=3.0
1-3=1.2, 4-8=3.0
1-2=2.2, 3-4=2.7
1-2=2.2, 3-4=2.7
1-5=2.5, 6-2=2.8
1-5=2.2, 6-2=2.7
1-5=1.5, 6-2=2.4
1-5=1.3, 6-2=2.6
1-3=1.0, 4-8=3.5
1-3=3.0, 4-8=3.0
1-3=3.5, 4-8=3.0
1-3=3.2, 4-8=3.0
1-3=1.2, 4-8=3.0
1-3=1.0, 4-8=3.5
1-3=3.0, 4-8=3.0
1-3=3.5, 4-8=3.0
1-3=3.2, 4-8=3.0
1-3=1.2, 4-8=3.0
1-3=1.0, 4-8=3.5
1-3=3.0, 4-8=3.0
1-3=3.5, 4-8=3.0
1-3=3.2, 4-8=3.0
1-3=1.0, 4-8=3.5
1-3=1.0, 4-8=3.5
1-3=1.0, 4-8=3.5
1-3=1.0, 4-8=3.5
1-3=1.0, 4-8=3.5
1-3=1.0, 4-8=3.5
1-5=0.9, 6-2=2.5
1-5=0.9, 6-2=2.5
1-5=1.0, 6-2=2.8
1-3=1.0, 4-8=3.5
1-3=1.0, 4-8=4.0
4000
4000
7200
4000
3000
3000
3000
3000
3000
3000
3000
4000
4000
7200
4000
3000
4000
4000
7200
4000
3000
3000
4000
7200
4000
4000
4000
4000
4000
4000
4000
3000
3000
3000
4000
4000
1/A
1/G
1/A
1/A
4/A
3/C
5/F
2/B
2/B
2/B
2/B
1/A
1/D
1/D
1/D
4/D
1/D
1/E
1/E
1/E
1/E
1/E
1/A
1/A
1/A
1/A
1/A
16/AD
1/G
1/A
1/D
2/B
2/B
2/B
1/E
1/G
Specifications subject to change without notice.
06/2018
20381 BARENTS SEA CIRCLE, LAKE FOREST, CA 92630
TEL: (949) 452-0511
FAX: (949) 452-0512
http://www.premiermag.com
1
