MAX507BCNG datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> converter> MAX507BCNG

MAX507BCNG: DescriptionD/A Converter, 1 Func, Parallel, Word Input Loading, PDIP24, PLASTIC, DIP-24; CategoryAnalog mixed-signal IC converter; File Size1MB，13 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/

Download Datasheet Parametric Compare View All

MAX507BCNG Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	MAX507BCNG	-	-	View	Buy Now

MAX507BCNG Overview

D/A Converter, 1 Func, Parallel, Word Input Loading, PDIP24, PLASTIC, DIP-24

MAX507BCNG Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Rochester Electronics
Parts packaging code	DIP
package instruction	DIP,
Contacts	24
Reach Compliance Code	unknown
ECCN code	EAR99
Maximum analog output voltage	10 V
Minimum analog output voltage
Converter type	D/A CONVERTER
Enter bit code	BINARY, OFFSET BINARY
Input format	PARALLEL, WORD
JESD-30 code	R-PDIP-T24
JESD-609 code	e0
length	31.75 mm
Maximum linear error (EL)	0.024%
Humidity sensitivity level	1
Number of digits	12
Number of functions	1
Number of terminals	24
Maximum operating temperature	70 °C
Minimum operating temperature
Package body material	PLASTIC/EPOXY
encapsulated code	DIP
Package shape	RECTANGULAR
Package form	IN-LINE
Peak Reflow Temperature (Celsius)	245
Certification status	Not Qualified
Maximum seat height	5.08 mm
Nominal supply voltage	12 V
surface mount	NO
Temperature level	COMMERCIAL
Terminal surface	TIN LEAD
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
width	15.24 mm
