72PK21502600M Overview

Film Capacitor, Polypropylene, 630V, 0.015uF

72PK21502600M Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Reach Compliance Code	compli
ECCN code	EAR99
capacitance	0.015 µF
Capacitor type	FILM CAPACITOR
diameter	8.5 mm
dielectric materials	POLYPROPYLENE
JESD-609 code	e3
length	20.5 mm
negative tolerance	20%
Number of terminals	2
Maximum operating temperature	105 °C
Minimum operating temperature	-55 °C
Package form	Axial
method of packing	TR
positive tolerance	20%
Rated (AC) voltage (URac)	300 V
Rated (DC) voltage (URdc)	630 V
Terminal surface	Tin (Sn)
Base Number Matches	1

Preview

Download Datasheet

View All

General Purpose, Pulse and DC Transient Suppression

A72 Series Polypropylene Film/Foil, Axial

Overview

The A72 Series is a capacitor with polypropylene film and metal

foil or metallized film and metal foil electrodes. The capacitor

is encapsulated in self-extinguishing resin in a box of material

meeting the requirements of UL 94 V–0 and protected with

polyester tape wrapping and thermosetting resin end fill.

Applications

Typical applications include switching spikes suppression and

resonant capacitors in switched mode power supply (SMPS), and

deflection circuits in televisions (S-correction and flyback tuning)

as well as applications with high voltage and high current.

Benefits

•

Rated voltage: 100 – 2,000 VDC

Rated voltage: 63 – 500 VAC

Capacitance range: 47 – 0.33 µF

Diameter: 5 – 22.5 mm

Length: 11 – 33 mm

Capacitance tolerance: ±5%, ±10%, ±20%

Climatic category: 55/105/56, IEC 60068–1

Tape and reel packaging in accordance with IEC 60286–1

Category temperature range of -55˚C to +105˚C

Part Number System

A72

Series

Polypropylene

Film/Foil

Rated Voltage (VDC)

E = 100

I = 250

M = 400

P = 630

Q = 1000

S = 1500

U = 2000

Length (mm)

F = 11

H= 14

K = 20.5

Q = 28

T = 33

1470

Capacitance Code (pF)

Digits 2 – 4 indicate the

first three digits of the

capacitance value.

First digit indicates the

number of zeros to be

added.

Lead and

Packaging Code

See Ordering

Options Table

Internal Use

00, 02 (Standard)

Capacitance

Tolerance

J = ±5%

K = ±10%

M = ±20%

One world. One KEMET

F3039_A72_AXIAL • 4/4/2013
