INDUCTORS
TECHNOLOGY OF TOMORROW
FERRITE CORE
RADIAL CHOKE COILS
LH • RLH
RLH
LHB
LHC
STRUCTURE
1
2
3
4
5
6
Ferrite bobbin core
Winding wire
Lead wire
Adhesive
Solder joint
Coating
Products with Pb-free terminations
meet RoHS requirements
TYPE DESIGNATION (HOW TO ORDER)
Old Part No.
LHB
LHB
PRODUCT CODE
LHB, RLH
0608
0608
STYLE
mm
(diameter/height)
M
T
TERMINATION
SURFACE MATERIAL
T: Sn
L: Sn/Pb
BA
*
1R0
Specifications given herein may be changed at any time without prior notice.
Please confirm technical specifications before you order and/or use.
INDUCTORS
New Part No.
(Pb-free)
1R0
INDUCTANCE
TOLERANCE
M(±20%)
K(±10%)
M
INDUCTANCE
TOLERANCE
M(±20%)
K(±10%)
PACKAGING
Blank: Bulk
*Please see “PACKAGING”
NOMINAL
INDUCTANCE
3 digits
Unit: µH
FEATURES
■
The below mentioned characteristic values are
representative examples and can be changed in
accordance with the customers requirements
■
Choke coils for general power supplies
■
Clear (LHC) or shrinkable tube (LHB) coating is
available
■
The RLH-type is the automatic insertion inductor
■
Covers a wide range of allowable DC current
(up to 5.4 A)
■
Measuring frequency: 1 kHz
■
Operating temperature range: -25°C ... +80°C
DIMENSIONS (mm)
TYPE
LHB 0608
LHB 0712
LHB 0812
LHB 0912
LHB 0914
LHB 1014
LHB 1216
LHB 1314
Ø
A
Max.
B Max.
C Min.
D Min.
E Max.
F(±1)
2.0
3.0
Ø
W
(nominal)
6.0
7.5
8.0
9.5
10.0
12.0
13.0
8.5
12.0
15
14.0
16.0
14.0
15 ± 5
–
–
10
3.0
0.50
0.65
5.0
7.0
7.0: L≥ 68µH
10.0: L≤ 47µH
0.80
0.6: 33µH≤L≤ 47µH
0.7: 6.8µH≤ L≤ 22µH
0.8: L≤ 4.7µH, L≥ 68µH
CHARACTERISTICS
LHB • DC BIAS
LHB • L vs. FREQUENCY
RLH • DC BIAS
RLH • L vs. FREQUENCY
