wiecon
PC board connectors, rising cage clamp system
Spacing: 7.50 mm
Rated cross section:
2.5 mm
2
Rated current:
16 A
Connection range:
0.14 – 4.0 mm
2
solid/
0.14 – 2.5 mm
2
fine stranded
500 V/6 kV/3 – Overvoltage category III
1000 V/6 kV/2 – Overvoltage category II
1000 V/6 kV/1 – Overvoltage category I
Solder pin 0.8 x 0.9 mm
Bore hole Ø 1.2 mm
M 2.5
6.5
Type 8390
wire horizontal to PC board
No. 22 – 12 AWG
No. 22 – 14 AWG
300 V
300 V
Part no.
15 A
10 A
Accessories
Type 8390
Poles
Part no.
Std. pack
igqwd
G
T
Poles
Part no.
Std. pack
Spacing: 7.50 mm
100
100
50
50
50
50
50
50
50
50
50
15.86
23.36
30.86
38.36
45.86
53.36
60.86
68.36
75.86
83.36
90.86
7.5
15.0
22.5
30.0
37.5
45.0
52.5
60.0
67.5
75.0
82.5
2
3
4
5
6
7
8
9
10
11
12
unmarked
25.151.0253.0
25.151.0353.0
25.151.0453.0
25.151.0553.0
25.151.0653.0
25.151.0753.0
25.151.0853.0
25.151.0953.0
25.151.1053.0
25.151.1153.0
25.151.1253.0
marked
25.150.0253.0
25.150.0353.0
25.150.0453.0
25.150.0553.0
25.150.0653.0
25.150.0753.0
25.150.0853.0
25.150.0953.0
25.150.1053.0
25.150.1153.0
25.150.1253.0
1
2
Test plug / nominal current = 2 A
Z5.543.0153.0
100
Z5.543.0253.0
100
Material:
Insulating housing: PA 6/66, UL 94-V-0
Clamping body: zinc-plated steel
Contact clip with solder pin:
tin-plated E copper
Clamping screw: zinc-plated steel
359
wiecon
Rated voltages VDE 0110
UL ratings
CSA ratings
Approvals
