MKE02Z64VLH2R datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The embedded processor and controller> Microcontrollers and processors> MKE02Z64VLH2R

MKE02Z64VLH2R: DescriptionRISC MICROCONTROLLER; CategoryThe embedded processor and controller Microcontrollers and processors; File Size1MB，36 Pages; ManufacturerFREESCALE (NXP); Environmental Compliance

Download Datasheet Parametric Compare View All

MKE02Z64VLH2R Overview

RISC MICROCONTROLLER

MKE02Z64VLH2R Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Objectid	1328239158
Reach Compliance Code	compliant
rom(word)	65536
technology	CMOS
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER, RISC

Preview

Download Datasheet

View All

Freescale Semiconductor

Data Sheet: Technical Data

Document Number MKE02P64M20SF0

Rev 3, 07/2013

KE02 Sub-Family

MKE02P64M20SF0

Supports the following:

MKE02Z16VLC2(R),

MKE02Z32VLC2(R),

MKE02Z64VLC2(R),

MKE02Z16VLD2(R),

MKE02Z32VLD2(R),

MKE02Z64VLD2(R),

MKE02Z32VLH2(R),

MKE02Z64VLH2(R),

MKE02Z32VQH2(R), and

MKE02Z64VQH2(R)

Key features

• Operating characteristics

– Voltage range: 2.7 to 5.5 V

– Flash write voltage range: 2.7 to 5.5 V

– Temperature range (ambient): -40 to 105°C

• Performance

– Up to 20 MHz ARM® Cortex-M0+ core

– Single cycle 32-bit x 32-bit multiplier

– Single cycle I/O access port

• Memories and memory interfaces

– Up to 64 KB flash

– Up to 256 B EEPROM

– Up to 4 KB RAM

• Clocks

– Oscillator (OSC) - loop-controlled Pierce

oscillator, crystal or ceramic resonator range of

31.25 kHz to 39.0625 kHz or 4 MHz to 20 MHz

– Internal clock source (ICS) - internal FLL with

internal or external reference, precision

trimming of internal reference allowing 1%

deviation across temperature range of 0 °C to

70 °C and 1.5% deviation across temperature

range of -40 °C to 105 °C, up to 20 MHz

– Internal 1 kHz low-power oscillator (LPO)

• System peripherals

– Power management module (PMC) with three

power modes: Run, Wait, Stop

– Low-voltage detection (LVD) with reset or

interrupt, selectable trip points

– Watchdog with independent clock source

(WDOG)

– Programmable cyclic redundancy check module

(CRC)

– Serial wire debug interface (SWD)

– Bit manipulation engine (BME)

• Security and integrity modules

– 64-bit unique identification (ID) number per chip

• Human-machine interface

– Up to 57 general-purpose input/output (GPIO)

– Two 8-bit keyboard interrupt modules (KBI)

– Interrupt (IRQ)

• Analog modules

– One 16-channel 12-bit SAR ADC, operation in

Stop mode, optional hardware trigger (ADC)

– Two analog comparators containing a 6-bit

DAC and programmable reference input

(ACMP)

• Timers

– One 6-channel FlexTimer/PWM (FTM)

– Two 2-channel FlexTimer/PWM (FTM)

– One 2-channel periodic interrupt timer (PIT)

– One real-time clock (RTC)

Freescale reserves the right to change the detail specifications as may be

required to permit improvements in the design of its products.

Table of Contents

1 Ordering parts...........................................................................4

1.1 Determining valid orderable parts......................................4

2 Part identification......................................................................4

2.1 Description.........................................................................4

2.2 Format...............................................................................4

2.3 Fields.................................................................................4

2.4 Example............................................................................5

3 Parameter classification............................................................5

4 Ratings......................................................................................6

4.1 Thermal handling ratings...................................................6

4.2 Moisture handling ratings..................................................6

4.3 ESD handling ratings.........................................................6

4.4 Voltage and current operating ratings...............................6

5 General.....................................................................................7

5.1 Nonswitching electrical specifications...............................7

5.1.1

5.1.2

5.1.3

DC characteristics.................................................7

Supply current characteristics...............................14

EMC performance.................................................15

5.2.2

FTM module timing...............................................17

5.3 Thermal specifications.......................................................18

5.3.1

Thermal characteristics.........................................18

6 Peripheral operating requirements and behaviors....................19

6.1 Core modules....................................................................19

6.1.1

SWD electricals ....................................................19

6.2 External oscillator (OSC) and ICS characteristics.............20

6.3 NVM specifications............................................................22

6.4 Analog...............................................................................23

6.4.1

6.4.2

ADC characteristics...............................................24

Analog comparator (ACMP) electricals.................26

6.5 Communication interfaces.................................................27

6.5.1

SPI switching specifications..................................27

7 Dimensions...............................................................................30

7.1 Obtaining package dimensions.........................................30

8 Pinout........................................................................................31

8.1 Signal multiplexing and pin assignments...........................31

8.2 Device pin assignment......................................................33

9 Revision history.........................................................................34

5.2 Switching specifications.....................................................16

5.2.1

Control timing........................................................16

KE02 Sub-Family Data Sheet, Rev3, 07/2013.

Freescale Semiconductor, Inc.

MKE02Z64VLH2R Related Products

	MKE02Z64VLH2R	MKE02P64M20SF0	MKE02Z16VLC2R	MKE02Z16VLD2R	MKE02Z32VLC2R	MKE02Z32VLH2R	MKE02Z32VQH2R	MKE02Z64VLC2R	MKE02Z64VLD2R	MKE02Z64VQH2R
Description	RISC MICROCONTROLLER	RISC MICROCONTROLLER	RISC MICROCONTROLLER	RISC MICROCONTROLLER	Kinetis E 32-bit MCU, ARM Cortex-M0+ core, 32KB Flash, 20MHz, 5V, QFP 32	RISC MICROCONTROLLER	RISC MICROCONTROLLER	RISC MICROCONTROLLER	RISC MICROCONTROLLER	RISC MICROCONTROLLER
Is it Rohs certified?	conform to	-	conform to	conform to	conform to	conform to	conform to	conform to	conform to	conform to
Objectid	1328239158	-	1328239142	1328239144	1328239146	1328239150	1328239152	1328239154	1328239156	1328239160
Reach Compliance Code	compliant	-	compliant	compliant	compliant	compliant	compliant	compliant	compliant	compliant
rom(word)	65536	-	16384	16384	32768	32768	32768	65536	65536	65536
technology	CMOS	-	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER, RISC	-	MICROCONTROLLER, RISC	MICROCONTROLLER, RISC	MICROCONTROLLER, RISC	MICROCONTROLLER, RISC	MICROCONTROLLER, RISC	MICROCONTROLLER, RISC	MICROCONTROLLER, RISC	MICROCONTROLLER, RISC
