EMC/EMI Products
IEC Inlet Filters
FN 9260
General Purpose Power Entry Module
with Fuses
n
n
n
n
n
Rated currents up to 10A
For one or two fuses
Optional safety version (A type)
Optional medical versions (B type)
according to IEC/EN 60601-1
Snap-in versions (S type)
Approvals
Technical specifications
Maximum continuous operating voltage:
Operating frequency:
Rated currents:
High potential test voltage:
250VAC, 50/60Hz
dc to 400Hz
1 to 10A @ 40°C max.
P –> PE 2000VAC for 2 sec (standard types)
P –> PE 2500VAC for 2 sec (B types)
P –> N 760VAC for 2 sec (standard types)
P –> N 1700VDC for 2 sec (B types)
IP40 according to IEC 60529
-25°C to +85°C (25/85/21)
UL 1283, CSA 22.2 No. 8 1986, IEC/EN 60939
UL 94V-2 or better
2,200,000 hours
1 or 2 fuses (Ø5 x 20mm)
Typical electrical schematic
FN 9260 (B types without Y-capacitors)
Cx
N
PE
P
Line
Load
R
2xL
2xCy
N‘
PE
P‘
Protection category:
Temperature range (operation and storage):
Design corresponding to:
Flammability corresponding to:
MTBF @ 40°C/230V (Mil-HB-217F):
Fuse holder:
FN 261
Cx
N
PE
P
Line
Load
R
2xL
2xCy
N‘
PE
P‘
Features and benefits
The FN 9260 power entry module combines
an IEC inlet, mains filter with excellent filter
attenuation and fuses in a small form factor.
Choosing FN 9260 product line brings you
rapid availability of a standard filter associ-
ated with the necessary safety acceptances.
Standard IEC connector filters are a practical
solution helping you to pass EMI system
approval in a short time. A wide selection
on amperage ratings, output connections,
mounting possibilities and filters for medical
applications are designed to offer you the
desired solution.
n
n
n
n
Typical applications
n
Exceptional conducted attenuation
performance, based on chokes with high
saturation resistance and excellent thermal
behavior.
B types comply with the requirements of
IEC/EN 60601-1 for creepage and clea-
rance, leakage current and high potential
testing.
Versions up to 10A are available with
fuse holder for one or two fuses.
Custom-specific versions are available on
request.
Portable electrical and electronic
equipment
n
n
Medical equipment
Small to medium-sized machines and
household equipment
n
Single-phase power supplies, switch-mode
power supplies
n
Test and measurement equipment
2
EMC/EMI Products
Filter selection table
Filter
Rated current
@ 40°C (25°C)
Leakage current*
@
230VAC/50Hz
Inductance
L
[mH]
5.3
2.7
1.0
0.3
0.2
5.3
2.7
1.0
0.3
0.2
5.3
2.7
1.0
0.3
0.2
5.3
2.7
1.0
0.3
0.2
Capacitance
Cx
Cy
[μF]
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
2.2
2.2
2.2
2.2
2.2
[nF]
2.2
2.2
2.2
2.2
2.2
Resistance
R
Input/Output
connections
Fuses
[Qty]
-06
-06
-06
-06
-06
-06
-06
-06
-06
-06
-06
-06
-06
-06
-06
-06
-06
-06
-06
-06
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
1
1
1
1
1
Weight
[
A
]
FN
FN
FN
FN
FN
FN
FN
FN
FN
FN
FN
FN
FN
FN
FN
FN
FN
FN
FN
FN
*
[
μA
]
373
373
373
373
373
[kΩ]
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
1000
[g]
55
55
55
55
55
55
55
55
55
55
55
55
55
55
55
55
55
55
55
55
9260x-1-06-y
9260x-2-06-y
9260x-4-06-y
9260x-6-06-y
9260x-10-06-y
9260xA1-1-06-y
9260xA-2-06-y
9260xA-4-06-y
9260xA-6-06-y
9260xA-10-06-y
9260xB-1-06-y
9260xB-2-06-y
9260xB-4-06-y
9260xB-6-06-y
9260xB-10-06-y
261x-1-06-y
261x-2-06-y
261x-4-06-y
261x-6-06-y
261x-10-06-y
1 (1.2)
2 (2.3)
4 (4.6)
6 (6.9)
10 (11.5)
1 (1.2)
2 (2.3)
4 (4.6)
6 (6.9)
10 (11.5)
1 (1.2)
2 (2.3)
4 (4.6)
6 (6.9)
10 (11.5)
1 (1.2)
2 (2.3)
4 (4.6)
6 (6.9)
10 (11.5)
37
74
74
74
74
2
2
2
2
2
373
373
373
373
373
0.22
0.47
0.47
0.47
0.47
Maximum leakage under normal operating conditions. Note: if the neutral line is interrupted, worst case leakage could reach twice this level.
Product selector
FN 9260xx-yy-yy-y
Snap-in range for S version only
10:
20:
30:
Snap-in range 0.6 to 1.5mm
Snap-in range 1.6 to 2.5mm
Snap-in range 2.6 to 3.5mm
06:
Faston 6.3 x 0.8mm (spade/soldering)
1 to 10:
Rated current
Blank:
A:
B:
Standard version
Safety version
Medical version (wihtout Y-capacitor)
Blank:
S:
Standard housing with mounting flanges
Snap-in version, snapper on vertical side
For example: FN 9260-1-06-10, FN 9260SB-10-06-20, FN 261S-6-06-30
Typical filter attenuation
Per CISPR 17; A = 50
Ω
/50
Ω
sym; B = 50
Ω
/50
Ω
asym; C = 0.1
Ω
/100
Ω
sym; D = 100
Ω
/0.1
Ω
sym
FN 9260: 1 to 4A types
FN 9260: 6 and 10A types
FN 261: 1 to 4A types
FN 261: 6 and 10A types
