www.murata-ps.com
UNR D5/D12 Series
Single Output, Non-Isolated, 5 or 12V
IN
to 1.8/2.5/3.3V
OUT
8 and 10 Amp DC/DC Converters
Features
Input ranges of 4.75-5.5V or 10.8-13.6V
Output voltages of 1.8/2.5/3.3V
8 and 10 Amp output current models
V
OUT
user-trimmable from 1.28V to 3.6V
Non-isolated, full synchronous topology
1" x 2" through-hole or SMT package
Gull-wing leads for SMT package
High efficiency to 91%; Low noise
200kHz switching; Planar magnetics
–40 to +40/50/60°C ambient operation with
no derating
Remote on/off control; Output overcurrent
detection
IEC950/EN60950/UL1950 approval
As supply voltages trend lower and load currents increase, centralized power
becomes more impractical. The tight accuracy, low noise and quick transient
response demanded by today's low voltage CPU's, ASIC's and DSP's make power
processing at the point of use the only viable solution. The UNR 18-33W series pro-
vides a complete line of non-isolated DC/DC converters to satisfy this requirement.
With input voltages of 5V (-D5 models) and 12V (-D12 models) these converters
offer standard output voltages of 1.8, 2.5 and 3.3 Volts and up to 10 Amps of output
current in both through-hole and surface-mount 1" x 2" metal cases.
With on/off control and output voltage trim capability as standard features, these
non-isolated converters exploit full synchronous rectification, planar magnetics, and
100% automated assembly to deliver high efficiencies (to 91%) and low noise at low
cost.
These versatile DC/DC’s are fully line and load regulated. They feature quick
transient response (50µsec), user-optional on/off control (for power sequencing),
and output overcurrent detection and shutdown ("hiccup" technique with auto-recov-
ery). Their impressive guaranteed efficiencies enable them to deliver fully rated
output power from –40 to +50/55°C (ambient) without supplemental cooling.
If your high current requirements have made the use of inefficient linear regula-
tors impractical, take a look at one of Murata Power Solutions’ new switching buck
regulators. Their high efficiency, ease-of-use, long-term reliability, and overall cost
effectiveness will impress you. Safety agency approvals and EMC characterizations
are currently in progress.
OBSOLETE PRODUCT
Last time buy: 3 March 2014
Click here for more information.
+V
IN
+V
OUT
INPUT
RETURN
OUTPUT
RETURN
LOGIC
GROUND
VOLTAGE
BOOST
➀
+V
CC
OVERCURRENT
DETECTION
ON/OFF
CONTROL
PWM
CONTROLLER
REFERENCE &
ERROR AMP
V
OUT
TRIM
Figure 1. Simplified Schematic
➀
-D5 models only.
Typical topology is shown.
For full details go to
www.murata-ps.com/rohs
www.murata-ps.com/support
UNR18-33W.C01
Page 1 of 9
UNR D5/D12 Series
Performance Specifications and Ordering Guide
➀
Single Output, Non-Isolated, 5 or 12V
IN
to 1.8/2.5/3.3V
OUT
8 and 10 Amp DC/DC Converters
Input
Regulation (Max.)
Line
±0.1%
±0.1%
±0.1%
±0.1%
±0.1%
±0.1%
±0.25%
±0.25%
±0.1%
±0.1%
±0.25%
±0.25%
Output
Root Model
➄
UNR-1.8/10-D5T
UNR-1.8/10-D5SM
UNR-2.5/10-D5T
UNR-2.5/10-D5SM
UNR-3.3/8-D5T
UNR-3.3/8-D5SM
UNR-3.3/8-D12T
UNR-3.3/8-D12SM
UNR-3.3/10-D5T
UNR-3.3/10-D5SM
UNR-3.3/10-D12T
UNR-3.3/10-D12SM
V
OUT
(Volts)
1.8
1.8
2.5
2.5
3.3
3.3
3.3
3.3
3.3
3.3
3.3
3.3
I
OUT
(Amps)
10
10
10
10
8
8
8
8
10
10
10
10
R/N (mVp-p)
➁
Typ.
70
40
75
75
40
40
40
40
40
50
70
70
Max.
100
80
100
100
80
80
100
100
80
100
120
120
Load
➂
±0.5%
±0.5%
±0.5%
±0.5%
±0.5%
±0.5%
±0.875%
±0.875%
±0.5%
±0.5%
±0.875%
±0.875%
V
IN
Nom.
(Volts)
5
5
5
5
5
5
12
12
5
5
12
12
Range
(Volts)
4.75-5.5
4.75-5.5
4.75-5.5
4.75-5.5
4.75-5.5
4.75-5.5
10.8-13.6
10.8-13.6
4.75-5.5
4.75-5.5
10.8-13.6
10.8-13.6
I
IN
➃
(mA/mA)
150/4190
150/4190
150/5620
150/5620
100/5470
100/5470
50/2420
50/2420
150/7250
150/7250
90/3090
90/3090
Efficiency
Min.
82%
82%
85%
85%
88%
88%
86%
86%
86%
86%
86%
86%
Typ.
86%
86%
89%
89%
92%
92%
91%
91%
91%
91%
89%
89%
Package
(Case,
Pinout)
C16A2, P23
C18, P25
C16A2, P23
C18, P25
C16A1, P23
C18, P25
C16A1, P23
C18, P25
C16A2, P23
C18, P25
C16C2, P23
C18, P25
➀
Typical at T
A
= +25°C under nominal line voltage and full-load conditions, unless otherwise
noted. All models are tested and specified with an external 22µF output capacitor with a
200mΩ ESR and a 470µF input capacitor with 6Arms ripple-current rating and 20mΩ
ESR. See I/O Filtering and Noise Reduction for more details.
➁
Ripple/Noise (R/N) is tested/specified over a 20MHz bandwidth. Output noise may be further
reduced by installing additional external output caps. See I/O Filtering and Noise Reduction.
➂
These devices have no minimum-load requirements and will regulate under no-load conditions.
➃
Nominal line voltage, no-load/full-load conditions.
➄
These are only partial part numbers, refer to part number structure when ordering.
PART NUMBER STRUCTURE
MECHANICAL SPECIFICATIONS
2.00
(50.80)
METAL CASE
SEE
NOTES
U NR
-
1.8
/
10
-
D5 SM
-
C
INSULATED BASE
Case C16A1, A2,C2
Output Configuration:
U
= Unipolar
Non-Isolated
RoHS-6 compliant*
Packaging:
T
= Through-Hole Package
SM
= Surface-Mount Package
Input Voltage Range:
D5
= 4.75 to 5.5 Volts (5V nominal)
D12
= 10.8 to 13.6 Volts (12V nominal)
0.20 MIN
(5.08)
Nominal Output Voltage:
1.8, 2.5 or 3.3 Volts
1.800
(45.72)
1
2
5
6
7
BOTTOM VIEW
DIMENSIONS IN INCHES (MM)
0.10
0.10 (2.54)
(2.54)
3
4
0.800
(20.32)
4 EQ. SP. @
0.200 (5.08)
0.10
(2.54)
Maximum Rated Output
Current in Amps
1.00
(25.40)
0.300
(7.62)
* Contact Murata Power Solutions Technologies (DATEL) for availability.
0.100
(2.54)
4
3
9
8
7
0.110
(2.79)
CASE C16A1
CASE HEIGHT: 0.39 (9.91)
PIN DIAMETERS:
PINS 1-7:
0.040 ±0.002 (1.016 ±0.051)
0.800
(20.32)
4 EQ. SP. @
0.200 (5.08)
CASE C16A2
CASE HEIGHT: 0.39 (9.91)
PIN DIAMETERS:
PINS 1-2, 4:
0.040 ±0.002 (1.016 ±0.051)
PINS 3, 5-7:
0.062 ±0.002 (1.575 ±0.051)
I/O Connections
Pin
1
2
3
4
5
6
7
8
9
Function P23
Logic Ground
On/Off Control
+Output
Trim
Output Return
Input Return
+Input
No Pin
No Pin
Function P25
Logic Ground
On/Off Control
N.C.
N.C.
+Output
Trim
Output Return
Input Return
+Input
0.500
(12.70) 0.300
(7.62)
2
1
Case C18
1.00
(25.40)
6
5
TOP VIEW
0.10
(2.54)
2.00
(50.80)
0.110
(2.79)
0.060
(1.52)
0.015
(0.38)
CASE C16C2
CASE HEIGHT: 0.48 (12.19)
PIN DIAMETERS:
PINS 1-2, 4:
0.040 ±0.002 (1.016 ±0.051)
PINS 3, 5-7:
0.062 ±0.002 (1.575 ±0.051)
0.43
(10.92)
INSULATED BASE
METAL CASE
DIMENSIONS ARE IN INCHES (MM)
0.015
(0.38)
0.055
(1.40)
www.murata-ps.com/support
UNR18-33W.C01
Page 2 of 9
UNR D5/D12 Series
Performance/Functional Specifications
Typical @ T
A
= +25°C under nominal line voltage and full-load conditions unless noted.
➀
Single Output, Non-Isolated, 5 or 12V
IN
to 1.8/2.5/3.3V
OUT
8 and 10 Amp DC/DC Converters
Physical
Shielding
Case Connection
Case Material
5 sided
Input/Output Return
Corrosion-resistant steel with
non-conductive, epoxy-based, black
enamel finish and plastic baseplate
RoHS: Gold plate over copper alloy
Non-RoHS: Pure tin on copper alloy with
nickel underplate
Input
Input Voltage Range
D5 Models
D12 Models
Input Current:
Normal Operating Conditions
Standby/Off Mode
Input Ripple Current:
1.8/2.5V Models
3.3/8 -D5 Models
3.3/10 -D5 Models
3.3/8 -D12 Models
3/3/10 -D12 Models
Input Filter Type
Overvoltage Protection
Reverse-Polarity Protection
On/Off Control:
➂
Functionality
Logic Threshold
V
OUT
Accuracy
(50% load):
1.8V
OUT
Models
2.5/3.3V
OUT
Models
V
OUT
Trim Range
➃
Trim pin tied to +Output:
Trim pin tied to Output Return
Temperature Coefficient
Ripple/Noise
(20MHz BW)
➄
Line/Load Regulation
Efficiency
Overcurrent Protection:
➁
Technique
Overcurrent Detection Point
Average Short Circuit Current:
D5 Models
D12 Models
Transient Response
(50-100% load):
1.8V
OUT
Models
1.8/2.5V
OUT
Models
3.3V
OUT
-D5 Models
3.3/8 -D12 Models
3.3/10 -D12 Models
3.0 to 3.6 Volts (3.3V nominal)
4.75-5.5 Volts (5V nominal)
10.8-13.6 Volts (12V nominal)
See Ordering Guide
3.6mA typical
Pin Material
150mAp-p
100mAp-p
150mAp-p
110mAp-p
250mAp-p
Capacitive
None
None
TTL high (or open) = on, low = off
+0.8-2.0 Volts (1.5V typical)
➀
All models are tested and specified with an external 470µF input capacitor with a 20mΩ
ESR and a 6Arms ripple-current rating, as well as a 22µF output capacitor with a 200mΩ ESR.
See I/O Filtering and Noise Reduction for more details. These devices have no minimum-load
requirements and will regulate under no-load conditions. Listed specifications apply for both
"T" and "SM" models as appropriate.
➁
See Output Overcurrent Detection for details.
➂
See On/Off Control for details.
➃
See Output Voltage Trimming for details.
➄
For all models, output noise can be further reduced with the installation of additional
external output capacitors. See I/O Filtering and Noise Reduction for details.
➅
See Start-Up Time for details.
➆
See Temperature Derating for details.
Output
±2% of V
OUT
maximum
±1% of V
OUT
maximum
V
OUT
= 1.52 Volts or less
V
OUT
= 3.6 Volts or greater
±0.02% per °C
See Ordering Guide
See Ordering Guide
See Ordering Guide
Absolute Maximum Ratings
Input Voltage:
Continuous:
D5 Models
D12 Models
Transient (100msec)
Input Reverse-Polarity Protection
Input/Output Overvoltage Protection
Output Current
7 Volts
15 Volts
15 Volts
None
None
Current limited. Devices can
withstand a sustained output
short circuit without damage.
–40 to +105°C
+300°C
Storage Temperature
"Hiccup" with auto-recovery
110-180% of rated current
1 Amp typical, 3 Amps maximum
4 Amp typical, 6 Amps maximum
Lead Temperature
(Soldering, 10 sec.)
These are stress ratings. Exposure of devices to any of these conditions may adversely
affect long-term reliability. Proper operation under conditions other than those listed in the
Performance/Functional Specifications Table is not implied.
TECHNICAL NOTES
Dynamic Characteristics
100µsec to 3% of final value
25µsec to 2.5% of final value
50µsec to 2.5% of final value
50µsec to 1% of final value
50µsec to 2.5% of final value
Start-Up Time:
➅
V
IN
to V
OUT
25/30msec (1.8/2.5V
OUT
models)
On/Off to V
OUT
25/30msec (1.8/2.5V
OUT
models)
Switching Frequency
Operating Temperature
(Ambient):
➆
Without Derating
With Derating
Storage Temperature
Dimensions:
D5 Through-Hole Models
D5 Surface-Mount Models
D12 Through-Hole Models
D12 Surface-Mount Models
Flammability
300kHz (±30kHz)
Environmental
See Derating Curves
to +100°C (See Derating Curves)
–40 to +105°C
Return Current Paths
These are non-isolated DC/DC converters. The Input Return, Output Return
and Logic Ground pins are all connected together internally. To the extent
possible, all input and load currents should be returned through the Input
Return and Output Return, respectively (via low-impedance runs). Any con-
trol signals applied to the On/Off Control pin should be referenced to Logic
Ground. The internal trace leading to Logic Ground is not designed to carry
high current. Consequently, devices should never be installed in a manner
that results in high current flow through Logic Ground (i.e., the Input/Output
Return pins should never be left open or connected via high-impedance paths).
I/O Filtering and Noise Reduction
Physical
2" x 1" x 0.39" (51 x 25 x 9.9mm)
2" x 1" x 0.43" (51 x 25 x 10.9mm)
2" x 1" x 0.48" (51 x 25 x 12.2mm)
2" x 1" x TBD" (51 x 25 x 12.7mm)
94V-0
All UNR 18-33W Series converters are tested and specified with external
470µF input capacitors (20mΩ ESR, 6Arms ripple-current rating) and
external 22µF output capacitors (200mΩ ESR). External input capacitance is
required and must be rated to handle the input ripple current as follows:
I
RMS
= I
OUT
In critical applications, input/output ripple/noise may be further reduced by
installing additional I/O caps.
√
V
OUT
V
IN
(
1 – V
OUT
)
V
IN
www.murata-ps.com/support
UNR18-33W.C01
Page 3 of 9
UNR D5/D12 Series
Input Fusing
UNR 18-33W Series DC/DC converters are not internally fused. Certain
applications and or safety agencies may require the installation of fuses
at the inputs of power conversion components. For Murata Power Solu-
tions UNR Series DC/DC converters, you should use either slow-blow or
normal-blow fuses with values no greater than twice the expected input
current at full power. See Ordering Guide.
Input Overvoltage and Reverse-Polarity Protection
UNR 18-33W Series DC/DC converters do not incorporate either input over-
voltage or input reverse-polarity protection. Input voltages in excess of the
listed absolute maximum ratings and input polarity reversals of longer than
"instantaneous" duration can cause permanent damage to these devices.
On/Off Control
The On/Off Control pin may be used for remote on/off operation. UNR 18-
33W Series DC/DC converters are designed so that they are enabled when
the control pin is pulled high or left open (normal mode) and disabled when
the control pin is pulled low (to less than +0.8V relative to Logic Ground). As
shown in Figure 2, D5 models have internal 4.99kΩ pull-up resistors to V
IN
(+Input), while D12 models have 12.4kΩ.
Dynamic control of the on/off function is best accomplished with a mechani-
cal relay or open-collector/open-drain drive circuit (optically isolated if appro-
priate). The drive circuit should be able to sink appropriate current when
activated and withstand appropriate voltage when deactivated.
Applying an external voltage to the On/Off Control pin when no input power is
applied to the converter can cause permanent damage to the converter. The
on/off control function, however, is designed such that the converter can be
disabled (control pin pulled low) while input voltage is ramping up and then
"released" once the input has stabilized. The time duration between the point
at which the converter is released and its fully loaded output settles to within
specified accuracy can be found in the Performance/Functional Specifica-
tions Table. See Start-Up Time for more details.
Start-Up Time
The V
IN
to V
OUT
Start-Up Time is the interval between the time at which a
ramping input voltage crosses the lower limit of the specified input voltage
range (4.75V for D5 models, 10.8V for D12 models) and the fully loaded
output voltage enters and remains within it specified accuracy band. Actual
measured times will vary with heavy capacitive loading.
The On/Off to V
OUT
Start-Up Time assumes the converter is turned off via the
Remote On/Off Control with the nominal input voltage already applied to the
converter. The specification defines the interval between the time at which
the converter is turned on and the fully loaded output voltage enters and
remains within its specified accuracy band. See Typical Performance Curves
for details
Output Overvoltage Protection
UNR 18-33W Series DC/DC converters do not incorporate output overvolt-
age protection. In the extremely rare situation in which the device’s feedback
loop is broken, the output voltage may run to excessively high levels. If it is
absolutely imperative that you protect your load against any and all possible
overvoltage situations, voltage limiting circuitry must be provided external to
the power converter.
Single Output, Non-Isolated, 5 or 12V
IN
to 1.8/2.5/3.3V
OUT
8 and 10 Amp DC/DC Converters
+INPUT
R
PULL UP
D5 Models 4.99kΩ
D12 Models 12.4kΩ
ON/OFF
CONTROL
LOGIC
GROUND
Figure 2. Driving the On/Off Control Pin
Output Overcurrent Detection
Overloading the output of a power converter for an extended period of time
will invariably cause internal component temperatures to exceed their maxi-
mum ratings and eventually lead to component failure. High-current-carrying
components such as transformers, FET's and diodes are at the highest risk.
UNR 18-33W Series DC/DC converters incorporate an output overcur-
rent detection and shutdown function that serves to protect both the power
converter and its load.
When the output current of a thermally stabilized converter exceeds the
maximum rating by 40% (typical) to 80% (maximum), the internal overcurrent
detection circuit shuts down the converter by discharging the soft-start circuit
of the pulse width modulator (PWM). In this off state, which is similar to that
achieved by pulling the On/Off Control low, the output voltage quickly drops
as the output capacitors discharge into the load. Since there is no longer any
output current, the overcurrent detection circuit is released, allowing the soft-
start circuit to recharge and the converter to turn on again. If the faulty load
condition persists, the overcurrent detection circuit will again discharge the
soft-start circuit and shut down the converter. This continuous on/off cycling
of the converter is referred to as “hiccup mode.” Once the overload condition
is removed, the converter remains on, and the output voltage is quickly
restored to its regulated value.
The components used to sense the output current have large temperature
coefficients. Consequently, in a "cold-start" situation, the Overcurrent Detec-
tion Point may temporarily move to 80% to 120% above the rated current
specification. The device quickly heats up, particularly if an overload situation
exists, and restores the normal (40%) Overcurrent Detection Point. The
device will not be damaged by starting up into an output-short-circuit condition.
The overcurrent detection circuitry helps keep internal current levels and
operating temperatures within safe operating limits. Nevertheless, sustained
operation at current levels above the rated output current but below the Over-
current Detection Point may result in permanent damage to the converter.
Output Voltage Trimming
UNR 18-33W devices can be trimmed to any voltage between 1.50V and
3.55V. Trimming is accomplished with either a trimpot or a single fixed resis-
tor. The trimpot should be connected between +Output and Output Return
with its wiper connected to the Trim pin as shown in Figure 3 below.
www.murata-ps.com/support
UNR18-33W.C01
Page 4 of 9
UNR D5/D12 Series
Single Output, Non-Isolated, 5 or 12V
IN
to 1.8/2.5/3.3V
OUT
8 and 10 Amp DC/DC Converters
+OUTPUT
R
T
DOWN
(kΩ) =
+INPUT
TRIM
INPUT
RETURN
20kΩ
5-10
Turns
LOAD
UNR-1.8/10-D5T
UNR-1.8/10-D5SM
2.49(V
O
– 1.26)
1.8 – V
O
3.14
V
O
– 1.8
–1.74
–1.74
R
T
UP
(kΩ) =
OUTPUT
RETURN
Figure 3. Trim Connections Using a Trimpot
UNR-2.5/10-D5T
UNR-2.5/10-D5SM
R
T
DOWN
(kΩ) =
R
T
UP
(kΩ) =
7.5(V
O
– 1.26)
2.5 – V
O
9.47
V
O
– 2.5
–1.74
–1.74
A trimpot can be used to determine the value of a single fixed resistor which
should be connected, as shown in Figure 4, between the Trim pin and
+Output to trim down the output voltage, or between the Trim pin and Output
Return to trim up the output voltage. Fixed resistors should be metal-film
types with absolute TCR’s less than 100ppm/°C to ensure stability.
The equations below can be used as starting points for selecting specific
trim-resistor values. Recall that untrimmed devices are guaranteed to be
between
±1%
and ±2% accurate, depending on model. See Performance
and Functional Specifications.
UNR-3.3/8-D5T
UNR-3.3/8-D5SM
UNR-3.3/10-D5T
UNR-3.3/10-D5SM
UNR-3.3/8-D12T
UNR-3.3/8-D12SM
UNR-3.3/10-D12T
UNR-3.3/10-D12SM
R
T
DOWN
(kΩ) =
7.5(V
O
– 1.27)
3.3 – V
O
9.5
V
O
– 3.3
–1.0
–1.0
R
T
UP
(kΩ) =
R
T
DOWN
(kΩ) =
R
T
UP
(kΩ) =
7.5(V
O
– 1.26)
3.3 – V
O
9.41
V
O
– 3.3
–1.0
–1.0
+OUTPUT
+INPUT
TRIM
INPUT
RETURN
Trim Up
OUTPUT
RETURN
Trim
Down
LOAD
Note: Resistor values are in kΩ. Accuracy of adjustment is subject to
tolerances of resistors and factory-adjusted output accuracy.
V
O
= desired output voltage.
Note:
Install either a fixed trim-up resistor or a fixed trim-down resistor
depending upon desired output voltage.
Figure 4. Trim Connections Using Fixed Resistors
www.murata-ps.com/support
UNR18-33W.C01
Page 5 of 9
Analogue and Mixed Signal
京公网安备 11010802033920号
EEWORLD
