228268108126 datasheet, PDF - EEWORLD Datasheet

228268108126: DescriptionCAPACITOR, CERAMIC, 1000 V, X7R, 0.0015 uF, THROUGH HOLE MOUNT, RADIAL LEADED, ROHS COMPLIANT; CategoryPassive components capacitor; File Size655KB，2 Pages; ManufacturerVishay; Websitehttp://www.vishay.com; Environmental Compliance

Download Datasheet Parametric View All

228268108126 Overview

CAPACITOR, CERAMIC, 1000 V, X7R, 0.0015 uF, THROUGH HOLE MOUNT, RADIAL LEADED, ROHS COMPLIANT

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
package instruction	,
Reach Compliance Code	unknow
ECCN code	EAR99
capacitance	0.0015 µF
Capacitor type	CERAMIC CAPACITOR
dielectric materials	CERAMIC
JESD-609 code	e3
Installation features	THROUGH HOLE MOUNT
multi-layer	N
negative tolerance	10%
Number of terminals	2
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package shape	DISK PACKAGE
method of packing	AMMO PACK
positive tolerance	10%
Rated (DC) voltage (URdc)	1000 V
surface mount	NO
Temperature characteristic code	X7R
Temperature Coefficient	15% ppm/°C
Terminal surface	Matte Tin (Sn)
Terminal shape	WIRE
Base Number Matches	1

SINGLE LAYER CERAMIC

DISC CAPACITORS

H Se r ie s 50 0 V ( DC ) a nd 1 kV ( DC )

CAPACITORS

PRODUCT SHEET

Ceramic Disc Capacitor

KEY BENEFITS

• High Capacitance in small size

• Inside kinked leads (preferred)

• WEEE/RoHS compliance, acc. EU directive 2002/95/EC

KEY SPECIFICATIONS

• Capacitance range: 1 nF to 10nF

Class 2 X7R, at 1 kHz, 1 ± 0.2 V (RMS)

• Dielectric strength: 250% of rated voltage for 500 V;

200% of rated voltage for 1 kV

• Insulation resistance: ≥ 10000 MΩ

• Acc. IEC 60384-9 and EIA 198

• Operating temperature: - 55 ºC to + 125 ºC

• Climatic Category: 55/125/21

• Dissipation factor: ≤ 2.5%

APPLICATIONS

• Bypassing

• Coupling

• SMPS

Datasheet is available on our web site at www.vishay.com

for H Series 500 V (DC and 1 kV (DC) - http://www.vishay.com/doc?28540

w w w. v i s h a y. c o m
