TSF10H45C thru TSF10H60C
Taiwan Semiconductor
Trench Schottky Rectifier
FEATURES
- Patented Trench Schottky technology
- Excellent high temperature stability
- Low forward voltage
- Low power loss/ High efficiency
- High forward surge capability
- Compliant to RoHS directive 2011/65/EU and
in accordance to WEEE 2002/96/EC
- Halogen-free according to IEC 61249-2-21 definition
ITO-220AB
TYPICAL APPLICATIONS
Trench Schottky barrier rectifier are designed for high frequency
miniature switched mode power supplies such as adapters, lighting
and on-board DC/DC converters.
MECHANICAL DATA
Case:
ITO-220AB
Molding compound meets UL 94 V-0 flammability rating
Base P/N with suffix "M" on P/N - commercial grade
Base P/N with suffix "G" on packing code - green compound (halogen-free)
Terminal:
Matte tin plated leads, solderable per JESD22-B102
Meet JESD 201 class 1A whisker test
Polarity:
As marked
Mounting torque:
0.56 Nm max.
Weight:
1.7 g (approximately)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
(T
A
=25 C unless otherwise noted)
PARAMETER
Maximum repetitive peak reverse voltage
Maximum average forward rectified
current
per device
per diode
SYMBOL
V
RRM
I
F(AV)
I
FSM
dV/dt
V
AC
Min.
I
F
= 5A
Instantaneous forward voltage per diode
( Note1 )
I
F
= 10A
I
F
= 5A
I
F
= 10A
Instantaneous reverse current per diode at rated
reverse voltage
Typical thermal resistance per diode
Operating junction temperature range
Storage temperature range
Note 1: Pulse Test with Pulse Width=300μs, 1% Duty Cycle
T
J
= 25°C
T
J
= 125°C
T
J
= 25°C
T
J
= 125°C
V
F
V
F
I
R
R
θJC
T
J
T
STG
-
-
-
-
-
-
Typ.
0.44
0.48
0.33
0.40
-
5
TSF10H45C
45
10
5
100
10000
1500
Max.
-
0.58
-
0.50
500
15
5.5
- 55 to +150
- 55 to +150
Min.
-
-
-
-
-
-
Typ.
0.46
0.54
0.38
0.48
-
6
Max.
-
0.62
-
0.56
500
25
O
o
TSF10H60C
60
UNIT
V
A
A
V/μs
V
Peak forward surge current, 8.3 ms single half sine-wave
superimposed on rated load per diode
Voltage rate of change (Rated V
R
)
Isolation voltage from terminal to heatsink t = 1 min
V
μA
mA
C/W
O
O
C
C
Document Number: DS_D1408070
Version: C14
TSF10H45C thru TSF10H60C
Taiwan Semiconductor
ORDERING INFORMATION
PART NO.
TSH10HxxC
(Note 1)
PART NO.
SUFFIX
M
PACKING CODE
C0
PACKING CODE
SUFFIX
G
PACKAGE
ITO-220AB
PACKING
50 / Tube
Note 1: "xx" defines voltage from 45V (TSF10H45C) to 60V (TSF10H60C)
EXAMPLE
PREFERRED P/N
TSF10H45CMC0
TSF10H45CMC0G
PART NO.
TSF10H45C
TSF10H45C
PART NO.
SUFFIX
M
M
PACKING CODE
C0
C0
G
PACKING CODE
SUFFIX
DESCRIPTION
Commercial grade
Commercial grade
Green compound
RATINGS AND CHARACTERISTICS CURVES
(T
A
=25
o
C unless otherwise noted)
FIG.1- FORWARD CURRENT DERATING CURVE
12.5
INSTANTANEOUS FORWARD CURRENT (A)
100
FIG. 2- TYPICAL FORWARD CHARACTERISTICS
TSF10H45C
AVERAGE FORWARD CURRENT (A)
10
10
T
J
=150
o
C
7.5
T
J
=125
o
C
T
J
=100
o
C
1
5
2.5
WITH HEATSINK
3in x 5in x 0.25in
Al-Plate
T
J
=25
o
C
0.1
0
0.2
0.4
0.6
0.8
1
FORWARD VOLTAGE (V)
0
0
25
50
75
100
125
150
CASE TEMPERATURE (
o
C)
FIG. 3- TYPICAL FORWARD CHARACTERISTICS
100
100
FIG. 4- TYPICAL REVERSE CHARACTERISTICS
TSF10H60C
INSTANTANEOUS REVERSE CURRENT (mA)
INSTANTANEOUS FORWARD CURRENT (A)
10
TSF10H45C
T
J
=150
o
C
10
T
J
=150
o
C
T
J
=125
o
C
T
J
=100
o
C
1
T
J
=125
o
C
T
J
=100
o
C
0.1
1
T
J
=25
o
C
0.01
T
J
=25
o
C
0.1
0
0.2
0.4
0.6
0.8
1
1.2
FORWARD VOLTAGE (V)
0.001
10
20
30
40
50
60
70
80
90
100
PERCENT OF RATED PEAK REVERSE VOLTAGE (%)
Document Number: DS_D1408070
Version: C14
TSF10H45C thru TSF10H60C
Taiwan Semiconductor
FIG. 5- TYPICAL REVERSE CHARACTERISTICS
100
FIG. 6- TYPICAL JUNCTION CAPACITANCE
10000
TSF10H60C
T
J
=150
o
C
f=1.0MHz
Vsig=50mVp-p
JUNCTION CAPACITANCE (pF)
A
INSTANTANEOUS REVERSE CURRENT (mA)
10
T
J
=125
o
C
T
J
=100
o
C
1000
1
TSF10H45C
0.1
100
TSF10H60C
0.01
T
J
=25
o
C
0.001
10
20
30
40
50
60
70
80
90
100
PERCENT OF RATED PEAK REVERSE VOLTAGE (%)
10
0.1
1
10
REVERSE VOLTAGE (V)
100
Document Number: DS_D1408070
Version: C14
TSF10H45C thru TSF10H60C
Taiwan Semiconductor
PACKAGE OUTLINE DIMENSIONS
ITO-220AB
DIM.
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
Unit (mm)
Min
4.30
2.50
2.30
0.46
6.30
9.60
3.00
0.95
0.50
2.40
14.80
-
12.60
-
2.41
Max
4.70
3.16
2.96
0.76
6.90
10.30
3.40
1.45
0.90
3.20
15.50
4.10
13.80
1.80
2.67
Unit (inch)
Min
0.17
0.10
0.09
0.02
0.25
0.38
0.12
0.04
0.02
0.09
0.58
-
0.50
-
0.09
Max
0.19
0.12
0.12
0.03
0.27
0.41
0.13
0.06
0.04
0.13
0.61
0.16
0.54
0.07
0.11
MARKING DIAGRAM
P/N
G
YWW
F
= Specific Device Code
= Green Compound
= Date Code
= Factory Code
Document Number: DS_D1408070
Version: C14
TSF10H45C thru TSF10H60C
Taiwan Semiconductor
CREAT BY ART
Notice
