5.0V THRU-HOLE VOLTAGE CONTROLLED CRYSTAL OSCILLATOR
MODEL: VCXO-C
FEATURES
• 5.0V Operation
• HCMOS/TTL Output
• Rugged Resistance Weld
OPTIONS
• Many Stability/Pullability Options
• -40ºC ~ +85ºC Option ('R' Version)
• 1/2 Size Version Available
• PART NUMBER SELECTION
Learn More - Internet Required
Part Number
458-Frequency-xxxxx
466-Frequency-xxxxx
317-Frequency-xxxxx
467-Frequency-xxxxx
318-Frequency-xxxxx
468-Frequency-xxxxx
319-Frequency-xxxxx
469-Frequency-xxxxx
320-Frequency-xxxxx
470-Frequency-xxxxx
Model
Number
VCXO-C2
VCXO-C2R
VCXO-C3
VCXO-C3R
VCXO-C4
VCXO-C4R
VCXO-C7
VCXO-C7R
VCXO-C8
VCXO-C8R
Discontinued
Frequency
Frequency Frequency Operating
Stability
1
Pullability Temperature Range (MHz)
±50PPM
±200PPM -10 ~ +70
(ºC)
1.000 ~ 40.000
±50PPM
±200PPM -40 ~ +85
(ºC)
1.000 ~ 40.000
±50PPM
±100PPM -10 ~ +70
(ºC)
1.000 ~ 40.000
±50PPM
±100PPM -40 ~ +85
(ºC)
1.000 ~ 40.000
±25PPM
±100PPM -10 ~ +70
(ºC)
1.000 ~ 40.000
±25PPM
±100PPM -40 ~ +85
(ºC)
1.000 ~ 40.000
±25PPM
±50PPM -10 ~ +70
(ºC)
1.000 ~ 40.000
±25PPM
±50PPM -40 ~ +85
(ºC)
1.000 ~ 40.000
±100PPM ±100PPM -10 ~ +70
(ºC)
1.000 ~ 40.000
±100PPM ±100PPM -40 ~ +85
(ºC)
1.000 ~ 40.000
Learn more about:
Part Marking Identification
Internet required
• ELECTRICAL CHARACTERISTICS
PARAMETERS
Frequency Range (F
O
)
Storage Temperature Range (T
STG
)
Supply Voltage
(V
DD
)
Control Voltage
(V
C
)
Input Current
(I
DD
)
1.000 ~ 24.000 MHz
24.000+ ~ 30.000 MHz
30.000+ ~ 40.000 MHz
Output Symmetry (50% V
DD
)
Rise Time (10% ~ 90% V
DD
) (T
R
)
Fall Time (90% ~ 10% V
DD
) (T
F
)
Output Voltage
(V
OL
)
(V
OH
)
Output Current
(I
OL
)
(I
OH
)
Output Load
TTL
HCMOS
Start-up Time
(T
S
)
Phase Noise
Fo + 1 kHz
Fo + 10 kHz
Linearity
Modulation
1
MAX
(unless otherwise noted)
1.000 ~ 40.000
2
MHz
-40ºC ~ +85ºC
5.0V ± 5%
2.5V ± 2V
15mA
20mA
30mA
40% ~ 60%
10nS
10nS
10% V
DD
90% V
DD
Min
3.2mA Min
-0.1mA Min
8 LSTTL
15pF
10mS
-125 dBc/Hz
-130 dBc/Hz
±10%
10kHz
All dimensions are in millimeters.
Inclusive of 25ºC tolerance, operating temperature range, input voltage change, load change,
aging, shock, vibration, and Vc = 2.5V.
2
Higher frequencies available on an individual inquiry basis.
All specifications subject to change without notice.
Rev. 6/1/04
82
FOXElectronics
5570 Enterprise Parkway Fort Myers, Florida 33905 USA +1(239)693-0099 FAX +1(239)693-1554
http://www.foxonline.com
© 2004 FOX ELECTRONICS
