Surface Mount Polymer-Tantalum Capacitor
FEATURES
• Ultra Low ESR and High Ripple Current Ratings
• Values from 3.3μF to 1,000μF
• Suitable for Reflow Soldering
• Available in A, B2, B, C, V and D Case Sizes
CHARACTERISTICS
Capacitance Range
3.3μF to 1000μF
±20% (M)
Capacitance Tolerance
2.5Vdc ~ 25Vdc*
Rated Voltage Range @ 85°C (Vdc)
Operating Temperature Range
-55°C ~ +105°C (voltage derating above +85°C, see table below)
Dissipation Factor
See Specifications Table
Leakage Current @ +25°C
Not More Than 0.1CV or 3μA, whichever is greater
(After 5 Minutes at Rated Voltage)
-55°C
+105°C
Capacitance Change
With Temperature
ΔC
- 20%
ΔC
-+50%
Resistance to Soldering Heat
ΔC
± 20% Max, LC = Less than initial specification
(+240°C for 5 ~ 10 Seconds)
DF = 130% of initial measured value
Moisture Resistance
ΔC
+30% ~ -20% Max, LC = Less than initial specification
(500 hours; 90~95% RH @ 40°C)
DF = 130% of initial measured value
Load Life at Rated Voltage
ΔC
+30% Max, LC = Less than initial specification
(1,000 hours @ 85°C)
DF = 150% of initial measured value
1%/1000 hours at +85°C and rated voltage
Base Failure Rate
* It is recommended that the applied voltage be less than 80% of the rated voltage
NTP Series
STANDARD VALUES AND CASE SIZES
2.5
Rated Voltage @ +85°C
3.3
Surge Voltage @ +85°C
2.0
Derated Voltage @ 105°C
Capacitance (μF) Code Case Size
3.3
335
-
4.7
475
-
6.8
685
-
10
106
-
15
156
-
22
226
-
33
336
-
47
476
-
68
686
-
100
107
-
150
157
-
220
227
A, B
330
470
680
1000
337
477
687
108
B, C, V
V
D
D
4.0
5.2
3.3
Case Size
-
-
-
-
-
-
A
A, B2
A
A, B2, B
B, C
B, C, V, D
C, V, D
D
D
-
6.3
8.0
5.0
Case Size
-
-
-
A
-
B2
A, B2, B
A, B2, B, C
B, C
A, B, C, V
B, C, V, D
B, V, D
V, D
-
-
-
20
25
10
16
23
29
13
20
16
20
8.0
12.8
Case Size Case Size Case Size Case Size
A
-
-
-
A
B
-
-
-
-
-
B
A, B
B
-
-
-
-
-
V
B2, B, C
-
V
-
A, B2, B
V
-
-
B2, B, C
V, D
-
-
C, V, D
-
-
-
C, V, D
-
-
-
C, V, D
-
-
-
D
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
PART NUMBER SYSTEM
NTP 157 M 10 TR V(40) 3K F
RoHS Compliant
Optional Reel Quantity/Size
ESR
Case Code
TR=Tape/Reel
Voltage
Tolerance Code
Capacitance Code
Series
NIC COMPONENTS CORP.
www.niccomp.com
www.lowESR.com
www.RFpassives.com
www.SMTmagnetics.com
SPECIFICATIONS ARE SUBJECT TO CHANGE
1
Surface Mount Polymer-Tantalum Capacitor
CASE DIMENSIONS (mm)
Case Size EIA Code
A
B2
B
C
V
D
3216
3528L
3528
6032
7343
7343
L
3.2 ± 0.2
3.5 ± 0.2
3.5 ± 0.2
6.0 ± 0.3
7.3 ± 0.3
7.3 ± 0.3
H
1.6 ± 0.2
1.1 ± 0.1
1.9 ± 0.2
2.5 ± 0.3
1.9 ± 0.1
2.8 ± 0.3
W
1
1.6 ± 0.2
2.8 ± 0.2
2.8 ± 0.2
3.2 ± 0.3
4.3 ± 0.3
4.3 ± 0.3
W
2
1.2 ± 0.1
2.2 ± 0.1
2.2 ± 0.1
2.2 ± 0.1
2.4 ± 0.1
2.4 ± 0.1
T
0.8 ± 0.3
0.8 ± 0.3
0.8 ± 0.3
1.3 ± 0.3
1.3 ± 0.3
1.3 ± 0.3
20°C
1.0
85°C
0.9
105°C
0.6
NTP Series
RIPPLE CURRENT TEMPERATURE DERATING
"A” Case Size
L
H
W
1
“B2, B” Case Size
L
H
W
1
“C, V, D” Case Size
L
W
1
H
W
2
W
2
T
T
T
T
T
T
W
2
Gold Body
Anode (+)
Identifier
Anode (+)
Identifier
Black Body
Value Marking/Production Code
(Format varies, see marking guide)
