ISL6540CRZ-T: DescriptionSWITCHING CONTROLLER, 2000kHz SWITCHING FREQ-MAX, PQCC28, 5 X 5 MM, ROHS COMPLIANT, PLASTIC, MO-220VHHD-1, QFN-28; CategoryPower/power management The power supply circuit; File Size422KB，20 Pages; ManufacturerRenesas Electronics Corporation; Websitehttps://www.renesas.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

ISL6540CRZ-T Overview

SWITCHING CONTROLLER, 2000kHz SWITCHING FREQ-MAX, PQCC28, 5 X 5 MM, ROHS COMPLIANT, PLASTIC, MO-220VHHD-1, QFN-28

ISL6540CRZ-T Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Renesas Electronics Corporation
Parts packaging code	QFN
package instruction	HVQCCN, LCC28,.2SQ,20
Contacts	28
Reach Compliance Code	compliant
ECCN code	EAR99
Analog Integrated Circuits - Other Types	SWITCHING CONTROLLER
control mode	VOLTAGE-MODE
Control Technology	PULSE WIDTH MODULATION
Maximum input voltage	20 V
Minimum input voltage	3.3 V
Nominal input voltage	5 V
JESD-30 code	S-PQCC-N28
JESD-609 code	e3
length	5 mm
Humidity sensitivity level	2
Number of functions	1
Number of terminals	28
Maximum operating temperature	70 °C
Minimum operating temperature
Maximum output current	0.1 A
Package body material	PLASTIC/EPOXY
encapsulated code	HVQCCN
Encapsulate equivalent code	LCC28,.2SQ,20
Package shape	SQUARE
Package form	CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE
Peak Reflow Temperature (Celsius)	260
Certification status	Not Qualified
Maximum seat height	1 mm
surface mount	YES
Switch configuration	PUSH-PULL
Maximum switching frequency	2000 kHz
Temperature level	COMMERCIAL
Terminal surface	MATTE TIN
Terminal form	NO LEAD
Terminal pitch	0.5 mm
Terminal location	QUAD
Maximum time at peak reflow temperature	40
width	5 mm

Preview

Download Datasheet

View All

E S IGN S

NEW D

PART

E D F OR

MMEND PLACEMENT

D RE

N OT R E

MENDE

Data Sheet

RECOM

ISL6540

July 23, 2008

FN9214.1

Single-Phase Buck PWM Controller with

Integrated High Speed MOSFET Driver

and Pre-Biased Load Capability

The ISL6540 is a single-phase voltage-mode PWM controller

with input voltage feedforward compensation to maintain a

constant loop gain for optimal transient response, especially for

applications with a wide input voltage range. Its integrated high

speed synchronous rectified MOSFET drivers and other

sophisticated features provide complete control and protection

for a DC/DC converter with minimum external components,

resulting in minimum cost and less engineering design efforts.

The output voltage of the converter can be precisely regulated

with an internal reference voltage of 0.591V, and has a system

tolerance of ±0.85% over commercial temperature and line load

variations. An external voltage can be used in place of the

internal reference for voltage tracking/DDR applications.

The ISL6540 has an internal linear regulator or external linear

regulator drive options for applications with only a single supply

rail. The internal oscillator is adjustable from 250kHz to 2MHz.

The integrated voltage margining, programmable pre-biased

soft-start, differential remote sensing amplifier, and

programmable input voltage POR features enhance the

ISL6540 value.

Features

• VIN and Power Rail Operation from +3.3V to +20V

• Fast Transient Response - 0 to 100% Duty Cycle

15MHz Bandwidth Error Amplifier with 6V/

s Slew Rate

- Voltage-Mode PWM Leading and Trailing-edge

Modulation Control

- Input Voltage Feedforward Compensation

• 2.9V to 5.6V High Speed 2A/4A MOSFET Gate Drivers

Tri-state for Power Stage Shutdown

•

Internal Linear Regulator (LR) - 5.6V Bias from VIN

•

External LR Drive for Optimal Thermal Performance

• Voltage Margining with Independently Adjustable Upper and

Lower Settings for System Stress Testing & Over Clocking

•

Reference Voltage I/O for DDR/Tracking Applications

•

Precise 0.591V Internal Reference with Buffered Output

±0.85%/±1.25% Over Commercial/Industrial Range

•

Source and Sink Overcurrent Protections

Low- and High-Side MOSFET r

DS(ON)

Sensing

•

Overvoltage and Undervoltage Protections

•

Small Converter Size - QFN package

• Oscillator Programmable from 250kHz to 2MHz

• Differential Remote Voltage Sensing with Unity Gain

• Programmable Soft-start with Pre-Biased Load Capability

• Power Good Indication with Programmable Delay

• EN Input with Voltage Monitoring Capability

• Pb-Free Plus Anneal Available (RoHS Compliant)

Pinout

ISL6540

(28 LD 5x5 QFN)

TOP VIEW

VMON

COMP

HSOC

LSOC

GND

Applications

•

Power Supply for some Microprocessors and GPUs

•

Wide and Narrow Input Voltage Range Buck Regulators

BOOT

UGATE

PHASE

PGND

LGATE

PVCC

VSEN+

VSEN-

REFOUT

REFIN

OFS+

OFS-

•

Point of Load Applications

•

Low-Voltage and High Current Distributed Power Supplies

Ordering Information

PART

NUMBER*

(Note)

ISL6540CRZ

PART

MARKING

ISL6540CRZ

TEMP.

PACKAGE PKG.

RANGE (°C) (Pb-Free) DWG. #

0 to 70

-40 to 85

28 Ld QFN L28.5x5

GND

VCC

MARCTRL

PG_DLY

VFF

VIN

BOTTOM

SIDE PAD

ISL6540CRZA ISL6540CRZ

LINDRV

ISL6540IRZA

ISL6540IRZ

*Add “-T” suffix for tape and reel.

NOTE: These Intersil Pb-free plastic packaged products employ

special Pb-free material sets, molding compounds/die attach

materials, and 100% matte tin plate plus anneal (e3 termination

finish, which is RoHS compliant and compatible with both SnPb and

Pb-free soldering operations). Intersil Pb-free products are MSL

classified at Pb-free peak reflow temperatures that meet or exceed

the Pb-free requirements of IPC/JEDEC J STD-020.

CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.

1-888-INTERSIL or 1-888-468-3774

Intersil (and design) is a registered trademark of Intersil Americas Inc.

All other trademarks mentioned are the property of their respective owners.

ISL6540CRZ-T Related Products

	ISL6540CRZ-T	ISL6540IRZA-T	ISL6540IRZA	ISL6540CRZA-T
Description	SWITCHING CONTROLLER, 2000kHz SWITCHING FREQ-MAX, PQCC28, 5 X 5 MM, ROHS COMPLIANT, PLASTIC, MO-220VHHD-1, QFN-28	SWITCHING CONTROLLER, 2000kHz SWITCHING FREQ-MAX, PQCC28, 5 X 5 MM, ROHS COMPLIANT, PLASTIC, MO-220VHHD-1, QFN-28	SWITCHING CONTROLLER, 2000kHz SWITCHING FREQ-MAX, PQCC28, 5 X 5 MM, ROHS COMPLIANT, PLASTIC, MO-220VHHD-1, QFN-28	SWITCHING CONTROLLER, 2000kHz SWITCHING FREQ-MAX, PQCC28, 5 X 5 MM, ROHS COMPLIANT, PLASTIC, MO-220VHHD-1, QFN-28
Is it lead-free?	Lead free	Lead free	Lead free	Lead free
Is it Rohs certified?	conform to	conform to	conform to	conform to
Maker	Renesas Electronics Corporation	Renesas Electronics Corporation	Renesas Electronics Corporation	Renesas Electronics Corporation
Parts packaging code	QFN	QFN	QFN	QFN
package instruction	HVQCCN, LCC28,.2SQ,20	HVQCCN, LCC28,.2SQ,20	HVQCCN, LCC28,.2SQ,20	HVQCCN, LCC28,.2SQ,20
Contacts	28	28	28	28
Reach Compliance Code	compliant	compliant	compliant	compliant
ECCN code	EAR99	EAR99	EAR99	EAR99
Analog Integrated Circuits - Other Types	SWITCHING CONTROLLER	SWITCHING CONTROLLER	SWITCHING CONTROLLER	SWITCHING CONTROLLER
control mode	VOLTAGE-MODE	VOLTAGE-MODE	VOLTAGE-MODE	VOLTAGE-MODE
Control Technology	PULSE WIDTH MODULATION	PULSE WIDTH MODULATION	PULSE WIDTH MODULATION	PULSE WIDTH MODULATION
Maximum input voltage	20 V	20 V	20 V	20 V
Minimum input voltage	3.3 V	3.3 V	3.3 V	3.3 V
Nominal input voltage	5 V	5 V	5 V	5 V
JESD-30 code	S-PQCC-N28	S-PQCC-N28	S-PQCC-N28	S-PQCC-N28
JESD-609 code	e3	e3	e3	e3
length	5 mm	5 mm	5 mm	5 mm
Humidity sensitivity level	2	3	3	3
Number of functions	1	1	1	1
Number of terminals	28	28	28	28
Maximum operating temperature	70 °C	85 °C	85 °C	70 °C
Maximum output current	0.1 A	0.1 A	0.1 A	0.1 A
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	HVQCCN	HVQCCN	HVQCCN	HVQCCN
Encapsulate equivalent code	LCC28,.2SQ,20	LCC28,.2SQ,20	LCC28,.2SQ,20	LCC28,.2SQ,20
Package shape	SQUARE	SQUARE	SQUARE	SQUARE
Package form	CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE	CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE	CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE	CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE
Peak Reflow Temperature (Celsius)	260	260	260	260
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum seat height	1 mm	1 mm	1 mm	1 mm
surface mount	YES	YES	YES	YES
Switch configuration	PUSH-PULL	PUSH-PULL	PUSH-PULL	PUSH-PULL
Maximum switching frequency	2000 kHz	2000 kHz	2000 kHz	2000 kHz
Temperature level	COMMERCIAL	INDUSTRIAL	INDUSTRIAL	COMMERCIAL
Terminal surface	MATTE TIN	Matte Tin (Sn) - annealed	Matte Tin (Sn) - annealed	MATTE TIN
Terminal form	NO LEAD	NO LEAD	NO LEAD	NO LEAD
Terminal pitch	0.5 mm	0.5 mm	0.5 mm	0.5 mm
Terminal location	QUAD	QUAD	QUAD	QUAD
Maximum time at peak reflow temperature	40	40	30	40
width	5 mm	5 mm	5 mm	5 mm
