Clock Oscillators Surface Mount Type
KC5032P-P3 Series
LV-PECL/ 3.3V/ 5.0×3.2mm
Features
• Miniature ceramic package
• Highly reliable with seam welding
• LV-PECL output
• Supply voltage V
CC
=3.3V
•
±25×10
-
6
available
How to Order
KC5032P 125.000 P 3 0 E 00
①
②
③④⑤⑥ ⑦
①
Type (5.0×3.2mm SMD)
②
Output Frequency
③
Output Type (LV-PECL)
④
Supply Voltage (3.3V)
⑤
Frequency Tolerance (See Table 1)
⑥
Symmetry/ INH Function
(45/ 55%, Stand-by)
⑦
Customer Special Model Suffix
(STD Specification is “00”)
Packaging (Tape & Reel 1000 pcs./ reel)
Table 1
Operating
Freq. Tol.
Note
-
6
Temperature
Code
×
10
Range (
°
C)
±
50
0
Standard specifications
±
30 0 to
+70
S
±
25
U
With only certain
frequencies
±100
F
-40
to
+85
±
50
G
RoHS Compliant
Specifications
Item
Output Frequency Range
Note1
Frequency Tolerance
Storage Temperature Range
Operating Temperature Range
Max. Supply Voltage
Supply Voltage
Current Consumption
Stand-by Current
Symmetry
Rise/ Fall Time
(20% to 80% Output Level)
Low Level Output Voltage
Note2
High Level Output Voltage
Note2
Output Load
Input Voltage Range
Low Level Input Voltage
High Level Input Voltage
Disable Time
Enable Time
Start-up Time
Deterministic Jitter (DJ)
1 Sigma jitter
Peak to Peak Jitter
Symbol
fo
f
_tol
T
_stg
T
_use
—
V
CC
I
CC
I
_std
SYM
tr/ tf
V
OL
V
OH
RL
V
IN
V
IL
V
IH
t
_dis
t
_ena
t
_str
DJ
J
Sigma
J
PK-PK
Freq. Tol.Code: 0, S, F
Freq. Tol.Code: U, G
Standard Specifications
Extend (Option)
Conditions
Initial tolerance, Operating tem-
perature range, Rated power supply
voltage change, Load change, Aging
(1 year @25°C), Shock and vibration
Op. Temp.:
-40
to
+85°C
Op. Temp.: 0 to
+70°C/ -40
to
+85°C
Op. Temp.: 0 to
+70°C
Op. Temp.: 0 to
+70°C
Min.
50
-100
-50
-30
-25
-55
0
-40
-0.5
+2.97
+3.14
—
—
45
—
Max.
190
+100
+50
+30
+25
+125
+70
+85
+5.0
+3.63
+3.46
90
30
55
0.6
Units
MHz
×10
-
6
°C
°C
V
V
mA
μA
%
ns
V
V
ohm
V
V
V
ns
ms
ms
ps
ps
ps
50ohm @crossing point
50ohm
Op. Temp.: 0 to
+85°C/
Typ. 1.600V
Op. Temp.:
-40
to 0°C/ Typ. 1.605V
Op. Temp.: 0 to
+85°C/
Typ. 2.350V
Op. Temp.:
-40
to 0°C/ Typ. 2.295V
LV-PECL Output
@Minimum operating voltage to be 0 sec.
Measured with Wavecrest SIA-3000
V
CC
-1.810
V
CC
-1.620
V
CC
-1.830
V
CC
-1.555
V
CC
-1.025
V
CC
-0.880
V
CC
-1.085
V
CC
-0.900
50
0
V
CC
—
30% V
CC
70% V
CC
—
—
150
—
10
—
10
—
2
—
4
—
30
Note : All electrical characteristics are defined at the maximum load and operating temperature range.
Note1: Please contact us for inquiry about operating temperature range, available frequencies and other conditions.
Note2: DC characteristic
Dimensions
5.0
1.0
0.5
0.7
(Unit: mm)
Recommended Land Pattern
0.9
1.6
(Unit: mm)
3.2
#3
#2
#1
0.6
0.7
1.1
0.64
0.63
2.6
#4
#5
#6
#1
#2
#3
#4
#5
#6
Pad Connections
INH
NC
Case GND
Output
Complementary Output
V
CC
Plating: Ni+Au
Tolerance:
±0.2
INH Function
Pad1
Pad4/ Pad5 (Output)
Open
Active
"H" Level
Active
"L" Level High Z (No-Oscillation)
1.3
1.3
Note: A capacitor of value 0.01µF and 10µF
between V
CC
and GND is recommended.
