Silicon NPN Power Transistor
DESCRIPTION
·DC
Current Gain -
: h
FE
= 40(Min.)@ I
C
=
0.5A
·Collector-Emitter
Sustaining Voltage-
: V
CEO(SUS)
= 80V(Min)
·Complement
to Type BD910
·Minimum
Lot-to-Lot variations for robust device
performance and reliable operation
APPLICATIONS
·Designed
for use in general purpose power amplifier and
switching applications.
ABSOLUTE MAXIMUM RATINGS(T
a
=25
℃)
SYMBOL
V
CBO
V
CEO
V
EBO
I
C
I
CM
I
B
P
C
T
J
T
stg
PARAMETER
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Collector Current-Continuous
Collector Current-Peak
Base Current
Collector Power Dissipation
@ T
C
=25℃
Junction Temperature
Storage Temperature Range
VALUE
80
80
5
15
20
5
90
150
-65~150
UNIT
V
V
V
A
A
A
W
℃
℃
BD909
THERMAL CHARACTERISTICS
SYMBOL
R
th j-c
PARAMETER
Thermal Resistance, Junction to Case
MAX
1.38
UNIT
℃/W
isc website
：
www.iscsemi.com
1
isc & iscsemi
is registered trademark
isc
Silicon NPN Power Transistor
ELECTRICAL CHARACTERISTICS
T
C
=25℃ unless otherwise specified
SYMBOL
V
CEO(SUS)
V
CE(
sat
)-1
V
CE(
sat
)-2
V
BE(
sat
)
V
BE(
on
)
I
CBO
I
CEO
I
EBO
h
FE-1
h
FE-2
h
FE-3
f
T
PARAMETER
Collector-Emitter Sustaining Voltage
Collector-Emitter Saturation Voltage
Collector-Emitter Saturation Voltage
Base-Emitter Saturation Voltage
Base-Emitter On Voltage
Collector Cutoff Current
Collector Cutoff Current
Emitter Cutoff Current
DC Current Gain
DC Current Gain
DC Current Gain
Current-Gain—Bandwidth Product
CONDITIONS
I
C
= 30mA ;I
B
= 0
I
C
= 5A; I
B
= 0.5A
I
C
= 10A; I
B
= 2.5A
I
C
= 10A; I
B
= 2.5A
I
C
= 5A ; V
CE
= 4V
V
CB
= 80V; I
E
= 0
V
CE
= 40V; I
B
= 0
V
EB
= 5V; I
C
= 0
I
C
= 0.5A ; V
CE
= 4V
I
C
= 5A ; V
CE
= 4V
I
C
= 10A ; V
CE
= 4V
I
C
= 0.5A ; V
CE
= 4V; f
test
= 1.0MHz
40
15
5
3.0
MIN
80
BD909
MAX
UNIT
V
1.0
3.0
2.5
1.5
0.5
1.0
1.0
250
150
V
V
V
V
mA
mA
mA
MHz
NOTICE：
ISC reserves the rights to make changes of the content herein the datasheet at any time without
notification. The information contained herein is presented only as a guide for the applications of
our products.
ISC products are intended for usage in general electronic equipment. The products are not designed
for use in equipment which require specialized quality and/or reliability, or in equipment which
could have applications in hazardous environments, aerospace industry, or medical field. Please
contact us if you intend our products to be used in these special applications.
ISC makes no warranty or guarantee regarding the suitability of its products for any particular
purpose, nor does ISC assume any liability arising from the application or use of any products, and
specifically disclaims any and all liability, including without limitation special, consequential or
incidental damages.
