PHD
CONNECTOR
2.0mm pitch/Disconnectable Crimp style connectors
Specifications –––––––––––––––––––
• Current rating: 3A AC, DC (AWG #22)
• Voltage rating: 250V AC, DC
• Temperature range: -25˚C to +85˚C
(including temperature rise in applying
electrical current)
• Contact resistance: Initial value/10m
Ω
max.
After environmental testing/20m
Ω
max.
• Insulation resistance:
1,000M
Ω
min.
• Withstanding voltage: 800V AC/minute
• Applicable wire: AWG #28 to #22
• Applicable PC board thickness: 1.6mm
* RoHS compliant products are published.
* Refer to "General Instruction and Notice when using
Terminals and Connectors" at the end of this catalog.
* Contact JST for details.
This is a 2.0mm pitch, crimp style, double-
row, wire-to-board connector. It is
designed to meet the demand for high-
density and low-profile connection.
• Compact
• Reliable contacts
• Fully shrouded header
Standards ––––––––––––––––––––––
1
Certified LR20812
5.0
0
Recognized E60389
PC board layout (viewed from soldering side) and Assembly layout
Top entry type
1.5
min
2.0
±0.05
Side entry type
2.0
±0.05
φ0.7
8.8
＋0.1
0
1.95
min
11.8
φ0.7
＋0.1
0
1.95
min
2.0
±0.05
（3.0）
Circuit No.1
Note: 1. Tolerances are non-cumulative:
±
0.05mm for all centers.
2. Hole dimensions differ according to the kind of PC board and piercing method. If PC boards made of hard material are used, the hole dimensions should
be larger. The dimensions above should serve as a guideline. Contact JST for details.
Contact
Model No.
SPHD-002T-P0.5
SPHD-001T-P0.5
6.5
2.85
1.3
Applicable wire
AWG #
mm
2
0.08∼0.21
0.13∼0.33
28∼24
26∼22
2.0
±0.05
Even number
circuits
Odd number
circuits
Insulation O.D.
(mm)
0.9∼1.5
1.0∼1.5
Q'ty /
reel
8,000
1.5
Material and Finish
Phosphor bronze, tin-plated (reflow treatment)
RoHS compliance
Contact
Crimping
machine Crimp applicator
*MKS-SC-10
Applicator
Dies
Crimp applicator with dies
Contact
SPHD-001T-P0.5
Crimping
machine Crimp applicator
AP-K2N
*MKS-SC-10
Applicator
Dies
Crimp applicator with dies
SPHD-002T-P0.5
AP-K2N
MKS-LS-10・MKS-L-10 MK/SPHD-002-05 APLMK SPHD002-05
SC/SPHD-002-05 APLSC SPHD002-05
MKS-L-10・MKS-LS-10 MK/SPHD-001-05 APLMK SPHD001-05
SC/SPHD-001-05 APLSC SPHD001-05
Note: *Strip-crimp applicator
26
（3.0） 5.0
7.0
min
PHD CONNECTOR
Housing
Cir-
cuits
8
10
12
14
16
18
Circuit Circuit
No.1
No.1
Circuit
No.2
Model No.
PHDR-08VS
PHDR-10VS
PHDR-12VS
PHDR-14VS
PHDR-16VS
PHDR-18VS
PHDR-20VS
PHDR-22VS
PHDR-24VS
PHDR-26VS
PHDR-28VS
PHDR-30VS
PHDR-32VS
PHDR-34VS
A
Dimensions (mm)
B
9.9
11.9
13.9
15.9
17.9
19.9
21.9
23.9
25.9
27.9
29.9
31.9
33.9
35.9
Q'ty /
bag
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
1,000
6.0
8.0
10.0
12.0
14.0
16.0
18.0
20.0
22.0
24.0
26.0
28.0
30.0
32.0
20
22
24
26
7.3
2.0
1.95
A
B
Shrouded header
Top entry type
Circuit No.1
6.5
（3.0）
2.0
1.95
A
B
Side entry type
Circuit No.1
6.5
7.0
9.5
2.0
2.0
1.95
A
B
H JST
28
30
32
34
2.0
4.2
5.0
Material
PA 66, UL94V-0, natural (white)
RoHS compliance
<For reference>
As the color identification,
the following alphabet shall be put in the underlined part.
For availability, delivery and minimum order quantity, contact JST.
ex.
PHDR-10VS-
S…natural (white)
K…black Y…yellow E…blue R…red
Cir-
cuits
H
JST
8
10
12
14
16
1.5 2.0
5.0
Circuit
No.2
0.5
Circuit
No.1
18
20
22
24
26
28
30
32
34
Model No.
Glass-filled nylon
Nylon
Top entry
Side entry
Top entry
Side entry
type
type
type
type
B8B-PHDSS S8B-PHDSS
-
-
B10B-PHDSS S10B-PHDSS B10B-PHDSS-B S10B-PHDSS-B
B12B-PHDSS S12B-PHDSS B12B-PHDSS-B S12B-PHDSS-B
B14B-PHDSS S14B-PHDSS B14B-PHDSS-B S14B-PHDSS-B
B16B-PHDSS S16B-PHDSS B16B-PHDSS-B S16B-PHDSS-B
B18B-PHDSS S18B-PHDSS B18B-PHDSS-B S18B-PHDSS-B
B20B-PHDSS S20B-PHDSS B20B-PHDSS-B S20B-PHDSS-B
B22B-PHDSS S22B-PHDSS B22B-PHDSS-B S22B-PHDSS-B
B24B-PHDSS S24B-PHDSS B24B-PHDSS-B S24B-PHDSS-B
B26B-PHDSS S26B-PHDSS B26B-PHDSS-B S26B-PHDSS-B
B28B-PHDSS S28B-PHDSS B28B-PHDSS-B S28B-PHDSS-B
B30B-PHDSS S30B-PHDSS B30B-PHDSS-B S30B-PHDSS-B
B32B-PHDSS S32B-PHDSS B32B-PHDSS-B S32B-PHDSS-B
B34B-PHDSS S34B-PHDSS B34B-PHDSS-B S34B-PHDSS-B
Material and Finish
Dimensions
(mm)
A
6.0
8.0
10.0
12.0
14.0
16.0
18.0
20.0
22.0
24.0
26.0
28.0
30.0
32.0
Q'ty / box
Top entry Side entry
type
type
500
500
500
500
500
500
250
250
250
250
250
250
250
250
500
500
500
250
250
250
250
250
200
200
200
200
200
200
B
9.9
11.9
13.9
15.9
17.9
19.9
21.9
23.9
25.9
27.9
29.9
31.9
33.9
35.9
H
JST
Circuit
No.2
Post: Copper alloy, copper-undercoated, tin-plated (reflow treatment)
Wafer: Glass-filled PA 66, UL94V-0, natural (ivory)
PA 66, UL94V-0, natural (white)
0.5
5.0
（3.0）
Circuit
No.1
RoHS compliance
This product displays (LF)(SN) on a label.
<For reference>
As the color identification,
the following alphabet shall be put in the underlined part.
For availability, delivery and minimum order quantity, contact JST.
ex.
ex.
B10B-PHDSS-
S…natural (ivory)
B10B-PHDSS-B-
S…natural (white)
K…black Y…yellow E…blue R…red
27
