AWH50G-E222-IDC-R datasheet, PDF

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > The connector> The connector> AWH50G-E222-IDC-R

Preview

AWH50G-E222-IDC-R: DescriptionBoard Connector, 50 Contact(s), 2 Row(s), Male, 0.1 inch Pitch, IDC Terminal, Latch, Receptacle; CategoryThe connector The connector; File Size169KB，1 Pages; ManufacturerASSMANN; Websitehttps://www.assmann.com/en/about-assmann/

Download Datasheet Parametric View All

AWH50G-E222-IDC-R Overview

Board Connector, 50 Contact(s), 2 Row(s), Male, 0.1 inch Pitch, IDC Terminal, Latch, Receptacle

AWH50G-E222-IDC-R Parametric

Parameter Name	Attribute value
Maker	ASSMANN
Reach Compliance Code	compliant
ECCN code	EAR99
Other features	ROHS COMPLIANT
body width	0.327 inch
subject depth	0.756 inch
Body/casing type	RECEPTACLE
Connector type	BOARD CONNECTOR
Contactor design	PREASSEM CONN
Contact to complete cooperation	SN ON NI
Contact completed and terminated	TIN OVER NICKEL
Contact point gender	MALE
Contact material	COPPER ALLOY
contact mode	RECTANGULAR
Contact style	SQ PIN-SKT
Dielectric withstand voltage	1000VAC V
Insulation resistance	5000000000 Ω
Manufacturer's serial number	AWH
Plug contact pitch	0.1 inch
Installation option 1	LATCH
Installation option 2	LOCKING
Installation type	CABLE
Number of rows loaded	2
Maximum operating temperature	105 °C
Minimum operating temperature	-40 °C
Plating thickness	100u inch
polarization key	POLARIZED HOUSING
Rated current (signal)	3 A
Guideline	UL
reliability	COMMERCIAL
Termination type	IDC
Total number of contacts	50

Preview

Download Datasheet

View All

1

4

NOTES:

2

3

5

6

7

A

B

5

C

8

5

MATERIAL

1.Insulator Material:PBT+30%G.F,(UL94V-0),Grey

2.Contact Material : Brass

3.Contact Plating : 1u" Au selective Over Ni

ELECTRICAL

1.Current Rating : 3.0 AMP

2.Withstand Voltage : 1000V AC/minute

3.Contact Resistance : 20mΩ max

4.Insulation Resistance: 1000MΩ min

ENVIRONMENTAL

1.Operation Temperature: -40°C to +105°C

7

2.Packing : Tube

3.10P~18P with slot"M" without slot "N"

20P-64P with slot "M" and "N"

A

Ordering Information

AWH xxG-E2x2-IDC

No. of Contacts :

10,14,16,20,26,

30,34,40,50,60,64

Latch Type

0 -without latch

2 -with short latches

3 -with long latches

B

4

C

D

8

D

5

8

without Latch

with short Latch

with long Latch

3

E

9

4

E

F

Scale

Free

9

TOLERANCE

X.X

X.XX

6

8

Correct the dimension L =4.10mm

Modify the shape of insulator

20.12.2017

05.06.2017

Winnie

Drawn

Short Latch

Long Latch

F

Date

29.05.2006

G

RoHS compliant

Unit: mm

Name

Customer-No.

Hellwig

±0.40

±0.25

X.XXX ±0.15

ANGLE

7

6

Change the packing tray into tube

Add UL file no.

21.09.2015

12.12.2013

Winnie

Amy

Approved

20.19.2017

G

±

3°

Winnie

ASSMANN WSW-No.

AWH xxG-E2x2-IDC

5

4

Update

Correct drawing of short latch

03.04.2013

05.05.2010

Winnie

Dean

Drawing-No.

H

DIM

TOL

ASS 0532 CO

Id.

Modification

Date

Name

rev09

H

1

2

3

4

5

Replace

Sheet

6

7
