HCMOS/TTL CERAMIC SMD OSCILLATORS
F3160/F3165
The Fox F3160 / F3165 are ceramic surface mount oscillators
which can drive both HCMOS and TTL loads in high density
applications such as notebook computers. This oscillator has
compatible pin spacing (0.2" x 0.3") with other industry standards
but features smaller overall dimensions.
FEATURES
•
•
•
•
•
HCMOS/TTL
Wide Frequency Range
Industry Compatible Pinout
Tri-state Enable/Disable
Tape and Reel
(1,000 pcs. STD)
• PART NUMBER SELECTION
Frequency Stability
±100PPM
±50PPM (F3170 up to 70 MHz)
±25PPM (up to 50 MHz)
Part Number
F3160 F3165
F3170 F3175
F3171
-------
Actual Size
• ELECTRICAL CHARACTERISTICS (V
DD
= 5.0V, C
L
= Max Load)
OSCILLATORS
PARAMETERS
Frequency Range (Fo)
Frequency Stability
Temperature Range
Operating
(T
OPR
)
Storage
(T
STG
)
Supply Voltage (V
DD
)
Input Current
(I
DD
)
FREQUENCY
RANGE
F3160
CONDITIONS
All Conditions *
MIN
1.800
-100
-10
-55
+4.5
MAX
80.000
+100
+70
+125
+5.5
25
45
76
80
55
60
---
7
5
---
7
5
0.5
16
-16
10
50
10
100
F3165
MIN
MAX
1.800
-100
-10
-55
+4.5
50.000
+100
+70
+125
+5.5
20
35
---
---
55
---
10
---
---
10
---
---
0.5
4
-4
10LS
15
10
100
UNITS
MHz
PPM
ºC
V
mA
1.800 ~ 80.000
Output Symmetry
Rise Time
(T
R
)
Fall Time
(T
F
)
Output Voltage
Output Current
Output Load
(V
OL
)
(V
OH
)
(I
OL
)
(I
OH
)
1.800
25.000+
50.000+
70.000+
1.800
70.000+
1.800
1.800
70.000+
1.800
1.800
70.000+
1.800
~
~
~
~
~
~
~
~
~
~
~
~
~
25.000
50.000
70.000
80.000
70.000
80.000
50.000
70.000
80.000
50.000
70.000
80.000
80.000
2.5V
0.5V to 4.5V
0.5V to 4.5V
4.5V to 0.5V
4.5V to 0.5V
I
OL
= 16 mA / I
OL
= 4 mA
I
OH
= -16 mA / I
OH
= - 4 mA
V
OL
= 0.5 V
V
OH
= 4.5 V
TTL
HCMOS
45
40
45
---
%
nS
V
mA
TTL
pF
mS
nS
4.5
4.5
1.800 ~ 80.000
1.800 ~ 80.000
1.800 ~ 80.000
1.800 ~ 80.000
Start-up Time
(T
S
)
Enable/Disable Time
INH (Pin 1)
OPEN ***
'1' Level V
IH
≥
2.2 V
'0' Level V
IL
≤
0.8 V
• ENABLE / DISABLE FUNCTION**
OUTPUT (Pin 3)
ACTIVE
ACTIVE
High Z
* Inclusive of 25ºC tolerance, operating temperature range, input voltage change, load change, aging, shock, and vibration.
***An internal pullup resistor from pin 1 to pin 4 allows active output if pin 1 is left open.
See page 35 for mechanical specifications, test circuits, and output waveform.
All specifications subject to change without notice. Rev. 5/20/98
All dimensions are in millimeters.
See page 64 for tape and reel specifications.
