SURFACE MOUNT ALUMINUM LONG LIFE, 105°C, 6.3MM HIGH
FEATURES
• Cylindrical leadless type for surface mounting.
• 2000 hour life, 105°C.
• Wide temperature (-40°C ~ +105°C).
• 6.3mm maximum height.
• Solvent resistant (2 minutes).
• Designed for automatic mounting and reflow soldering.
Tecate Group
TYPE MXWL
PART NUMBERING
Part Number Example: MXWL-016/100M4X6TR13F
MXWL
Type
-
016
Rated DC
Voltage
/
100
Capacitance
Code (µF)*
M
Tolerance
Code
4X6
Size
TR
Package
Code**
13
Reel Size
F
RoHs
Compliant
* Capacitance Code: First two digits represent significant figure, third digit represents multiplier (number of zeros).
** Package Code: TR = Tape & Reel.
SPECIFICATIONS
Operating Temperature Range
Temperature Characteristics (120Hz)
Voltage Range
Surge Voltage (20°C, 120Hz)
Capacitance Range
Maximum Dissipation Factor (20°C,
120Hz)
Maximum Leakage Current (20°C) (after 2
minutes)
Load Life Test (105°C, 2000 hours)
Performance Characteristics
-40°C ~ +105°C.
Impedance Ratio
Rated Voltage (WVDC)
4
6.3
Z (-40°C) / Z (+20°C)
7
4
Z (-55°C) / Z (+20°C)
15
8
4VDC ~ 50VDC.
5
8
VDC
0.1µF ~ 47µF.
Rated Voltage (WVDC)
4
6.3
DF %
50
30
0.01CV or 3µA, whichever is greater.
Capacitance Change
DF
Leakage Current
Within ±25% of initial measured value.
Less than 200% of specific value.
Less than specified value.
10
3
6
13
10
22
16
2
4
20
16
16
25
2
4
32
25
16
35
2
3
44
35
12
STANDARD PRODUCT TABLE (dØ X L(mm))
Capacitance
(µF)
0.10
0.22
0.33
0.47
1.0
2.2
3.3
4.7
10
22
33
47
100
220
4
6.3
10
WVDC
16
25
35
50
4X
4X
4X
4X
4X
4X
4X
5X
6.3 X
4 X 6.3
4x
4X
5X
6.3 X
6.3
6.3
6.3
6.3
4 X 6.3
5 X 6.3
5 X 6.3
6.3 X 6.3
6.3 X 6.3
5 X 6.3
6.3 X 6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
6.3
5 X 6.3
6.3 X 6.3
© Tecate Industries 2006
Phone: (619) 398-9700 Fax: (619) 398-9777
Web Site: www.tecategroup.com
Tecate Industries
2006/08/30 Rev.02
SURFACE MOUNT ALUMINUM LONG LIFE, 105°C, 6.3MM HIGH
DIMENSIONS (mm)
Case Size
4 x 6.3
5 x 6.3
6.3 x 6.3
dØ ± 0.5
4.0
5.0
6.3
L Max.
6.3
6.3
6.3
A ± 0.2
4.3
5.3
6.6
B ± 0.2
4.3
5.3
6.6
1 ± 0.2
1.8
2.2
2.4
Tecate Group
TYPE MXWL
W
0.5 ~ 0.8
0.5 ~ 0.8
0.5 ~ 0.8
P ± 0.2
1.0
1.5
2.2
RECOMMENDED LAND PATTERN (mm)
Case Size
A
B
P
4 x 6.3
5 x 6.3
6.3 x 6.3
2.5
2.7
3.1
1.6
1.6
1.6
1.0
1.4
2.2
MAXIMUM RIPPLE (mA rms @ 120Hz & 105°C)
Cap.
(µF)
0.10
0.22
0.33
0.47
1.0
2.2
3.3
4.7
10
22
33
47
100
220
4
6.3
10
WVDC
16
25
35
50
1
2
3
5
10
16
16
23
35
Ω
MAXIMUM ESR (Ω @ 120Hz & 20°C)
Cap.
(µF)
0.10
0.22
0.33
0.47
1.0
2.2
3.3
4.7
10
22
33
47
100
220
4
6.3
10
WVDC
16
25
35
50
993
906
604
424
199
90.8
60.4
42.4
19.9
22
20
29
46
71
28
39
43
70
58
28
55
49.5
22.6
15.1
10.6
4.96
26.6
12.1
11.1
5.66
7.05
19.9
9.05
34
61
82
17.7
8.31
3.77
© Tecate Industries 2006
Phone: (619) 398-9700 Fax: (619) 398-9777
Web Site: www.tecategroup.com
Tecate Industries
2006/04/17 Rev.00
