BCU86-SMD

Description
Small Signal Bipolar Transistor, 3A I(C), 50V V(BR)CEO, 1-Element, NPN, Silicon
CategoryDiscrete semiconductor    The transistor
File Size126KB,6 Pages
ManufacturerTT Electronics plc
Websitehttp://www.ttelectronics.com/
Download Datasheet Parametric Compare View All

BCU86-SMD Overview

Small Signal Bipolar Transistor, 3A I(C), 50V V(BR)CEO, 1-Element, NPN, Silicon

BCU86-SMD Parametric

Parameter NameAttribute value
MakerTT Electronics plc
package instructionSMALL OUTLINE, R-PSSO-F3
Reach Compliance Codecompliant
ECCN codeEAR99
Shell connectionCOLLECTOR
Maximum collector current (IC)3 A
Collector-emitter maximum voltage50 V
ConfigurationSINGLE
Minimum DC current gain (hFE)100
JESD-30 codeR-PSSO-F3
Number of components1
Number of terminals3
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Polarity/channel typeNPN
Certification statusNot Qualified
surface mountYES
Terminal formFLAT
Terminal locationSINGLE
transistor applicationsSWITCHING
Transistor component materialsSILICON
Nominal transition frequency (fT)150 MHz
BCU86-SMD
BCU87-SMD
MECHANICAL DATA
Dimensions in mm
4 .5
1 .6
1 .5
NPN/PNP EPITAXIAL PLANAR
SILICON TRANSISTOR
Ideal For High current Switching
Application
4 .2 5 m a x .
2 .5
FEATURES
• LOW V
CE(SAT)
0 .4 0
0 .5 0
1 .5
3 .0
1 .0
0 .4 0
• HIGH CURRENT CAPACITY AND WIDE ASO
• FAST SWITCHING SPEED
-
+
*
APPLICATIONS
SOT89
• VOLTAGE REGULATORS
• RELAY DRIVERS
• LAMP DRIVERS
• ELECTRICAL EQUIPMENT
ABSOLUTE MAXIMUM RATINGS
(Tcase = 25°C unless otherwise stated)
V
CBO
V
CEO
V
EBO
I
C
I
CP
P
C
T
j
T
stg
Collector – Base voltage
Collector – Emitter voltage (I
B
= 0)
Emitter – Base voltage
Collector current
Collector Current (Pulse)
Collector Dissipation
(Mounted on Ceramic Board (250mm
2 x 0.8mm)
Junction Temperature
Storage Temperature
Telephone +44(0)1455 554711.
Fax +44(0)1455 558843.
E-mail:
magnatec@semelab.co.uk
Website:
http://www.semelab.co.uk
BCU86
60V
50V
6V
3A
6A
500mW
1.5W
150°C
BCU87
– 60V
– 50V
– 6V
– 3A
– 6A
–55 to 150°C
Prelim.9/98
Magnatec.

BCU86-SMD Related Products

BCU86-SMD BCU87-SMD
Description Small Signal Bipolar Transistor, 3A I(C), 50V V(BR)CEO, 1-Element, NPN, Silicon Small Signal Bipolar Transistor, 3A I(C), 50V V(BR)CEO, 1-Element, PNP, Silicon
Maker TT Electronics plc TT Electronics plc
package instruction SMALL OUTLINE, R-PSSO-F3 SMALL OUTLINE, R-PSSO-F3
Reach Compliance Code compliant compliant
ECCN code EAR99 EAR99
Shell connection COLLECTOR COLLECTOR
Maximum collector current (IC) 3 A 3 A
Collector-emitter maximum voltage 50 V 50 V
Configuration SINGLE SINGLE
Minimum DC current gain (hFE) 100 100
JESD-30 code R-PSSO-F3 R-PSSO-F3
Number of components 1 1
Number of terminals 3 3
Package body material PLASTIC/EPOXY PLASTIC/EPOXY
Package shape RECTANGULAR RECTANGULAR
Package form SMALL OUTLINE SMALL OUTLINE
Polarity/channel type NPN PNP
Certification status Not Qualified Not Qualified
surface mount YES YES
Terminal form FLAT FLAT
Terminal location SINGLE SINGLE
transistor applications SWITCHING SWITCHING
Transistor component materials SILICON SILICON
Nominal transition frequency (fT) 150 MHz 150 MHz
