85 °C
ATBI
Axial terminals
Bipolar construction
For crossover networks
Features
•
•
•
•
RoHS compliant
REACH compliant
Different case sizes, voltages and
capacitance combinations are
available on request.
Also in small lots.
All contacts welded
Bipolar
HiFi
Consumer
Applications
General specifications
Items
Rated capacitance range C
R
Capacitance tolerance
U
R
bipolar (rated voltage DC)
Max. peak voltage (AC)
Category temperature range
Useful life
> 5000 h @ 85 °C
> 1000 h @105 °C
Characteristics
1… 100 µF @ 1 kHz
±
20%; ± 10% on request
63 V dc @ 23 V ac
100 V dc @ 35 V ac
May not exceed rated voltage (DC)
- 40°C ... + 85 °C
Requirements
Δ C/C ≤ 30 % of initial value
ESR ≤ 300 % of specified limit
I
L
≤ specified limit
Requirements
Δ C/C ≤ 20
% of initial value
ESR ≤ 130 % of specified limit
I
L
≤ specified limit
40/085/56
D ≤ 25 mm: ≥ 1000 V AC
D > 25 mm: ≥ 2500 V AC
Up to 25 mm Ø : 0,8 mm ;
more than 25 mm Ø : 1,0 mm
Endurance test
Climatic category IEC 60068
Voltage proof of the external insulation
Ø leads
100 000 h @40 °C
Leclanché Capacitors
1400 Yverdon, Switzerland
Tel. +41 24 445 66 88
Fax +41 24 445 66 89
www.Lcap.ch
capinfo@Lcap.ch
19
85 °C
Electrical data and ordering code for series ATBI
Rated voltage
U
R
[V]
(other values available on re-
quest)
ATBI
Order code
ATBI...
Rated capacitance
Case size
D x L [mm]
C
R
[µF]
1,0
2,2
3,3
4,7
6,8
10
15
22
10x20
10x20
10x20
10x20
10x20
10x30
10x30
12x30
12x30
14x37
16x39
18x39
25x38
25x38
25x38
25x38
25x38
25x49
25x49
10x20
10x30
10x30
10x30
10x30
10x30
10x30
12x30
12x30
14x37
16x39
18x39
25x38
1,002310020
2,202310020
3,302310020
4,702310020
6,802310020
10002310030
15002310030
22002312030
33002312030
47002314037
68002316039
10102318039
22102325038
33102325038
47102325038
56102325038
68102325038
80102325049
10202325049
1,003510020
2,203510030
3,303510030
4,703510030
6,803510030
10003510030
15003510030
22003512030
33003512030
47003514037
68003516039
10103518039
2203525038
23 Vac
@ 50 Hz
33
47
68
100
220
330
470
560
680
880
1000
1,0
2,2
3,3
4,7
6,8
35 Vac
@ 50 Hz
10
15
22
33
47
68
100
220
Leclanché Capacitors
1400 Yverdon, Switzerland
20
Tel. +41 24 445 66 88
Fax +41 24 445 66 89
www.Lcap.ch
capinfo@Lcap.ch
85 °C
