AEW Dual Output Series
30W DC-DC Converters
Feature:
❒
Two wide input voltage range
❒
Input over-/under-voltage protection
❒
Trim function
❒
Output over-voltage shutdown
❒
Output over-current protection
❒
Load shortcircuit protection
❒
High efficiency, density and reliability
❒
Low profile (Typical height: 12.7mm)
❒
UL CSA TUV approved
❒
Meet with FCC Class A
Size: 76.2%63.5%12.7 (3.0″
%
2.5″
%
0.5″)
%
%
″
″
″
Application
❂
Data collection
❂
Program controlled equipment
❂
Instruments
❂
Communication system
❂
Separately power supply system
Introduction:
AEW series adopt 3"x2.5" standard industrial encapsulation and pin with height less than 0.5", providing
2-output and 3-output.
AEW 30W 2-output and AEW 30W 3-output products are compact, high performance DC/DC
converters. They adopt state-of-the-art SMT and sealing structure, feature high power density, small
weight, and are suitable for applications requiring isolated stabilized voltage. They provide +-5V, +-12V,
+-15V 2-output or 5V/+-12V, 5V/+-15V 3-output. The input voltage can be 24VDC or 48VDC.
With low output ripple and noise, highly stabilized voltage accuracy, high efficiency and reliability, the
AEW 2-output and AEW 3-output series are suitable for by-board distributed power supply system.
TEL:
FAX:
USA
1-760-930-4600
1-760-930-0698
Europe
44-(0)1384-842-211
44-(0)1384-843-355
Asia
852-2437-9662
852-2402-4426
1
List 1 AEW dual output products list
Model
AEW03AA24
AEW01BB24
AEW01CC24
AEW03AA48
AEW01BB48
AEW01CC48
Input voltage
(V)
18-36
18-36
18-36
36-72
36-72
36-72
Output voltage
(V)
±5
±12
±15
±5
±12
±15
Output current
(A)
±3.0
±1.25
±1.0
±3.0
±1.25
±1.0
Product code
02280360
02280358
02280362
02280359
02280264
02280361
Absolute maximum value:
The following list is the maximum stress that the module can endure. If the module works under
the condition for a long time, it may short the lifetime and have bad effect on its reliability. If the
environmental stress exceeds the absolute maximum value listed below, the module may be
damaged forever.
List 2 Extreme limit parameters
Parameters
Input voltage
(+Vin~-Vin)
Rated 48V
Model
Rated 24V
Minimum
Maximum
42
50
82
100
CNT voltage
CNT~-Vin
Isolated voltage
Input-output
Operating ambient
temperature
Storage temperature
Pin soldering
temperature
All
All
All
All
-25
-40
2000
+70
+105
260
Vdc
°C
°C
°C
Wave solder < 12S
Rated 24V
Rated 48V
42
82
Unit
Vdc
Vdc
Vdc
Vdc
Vdc
Vdc
Note
Continuously
Instant < 100ms
Continuously
Instant < 100ms
Continuously
Continuously
TEL:
FAX:
USA
1-760-930-4600
1-760-930-0698
Europe
44-(0)1384-842-211
44-(0)1384-843-355
Asia
852-2437-9662
852-2402-4426
2
Electrical Characteristic (continued)
List 3 Input characteristics
Parameter
Input voltage range
Model
Rated 24V
Rated 48V
Maximum input
current
(the lowest input
voltage, rated
output )
AEW03AA24
AEW01BB24
AEW01CC24
AEW03AA48
AEW01BB48
AEW01CC48
Input under-voltage
shutdown
Rated 24V
Rated 48V
Rated 24V
Rated 48V
Symbol
Vi
Vi
Iin
Iin
Iin
Iin
Iin
Iin
14
30
36
72
15.5
33
40
76
Minimum
18
36
Typical
24
48
Maximum
36
72
2.03
1.98
1.98
1.01
0.99
0.99
18
36
42
82
Unit
Vdc
Vdc
A
A
A
A
A
A
Vdc
Vdc
Vdc
Vdc
Input over-voltage
shutdown
Input reflected
current
(5Hz-20MHz 12µH
impedance,
TA=25°C reference
figure 3)
All
—
—
5
10
mAp-p
Note: there is no fuse inside the power module. Recommend adding an external fuse in the input of the
module.
A common fuse can be selected, the value can refer to the maximum current in the list 3.
List 4 Remote ON/OFF
Parameter
Remote ON/OFF
logic
Model
All
Symbol
CNT
Minimum
Typical
Maximum
Unit
CNT in the midair, output ON
CNT connects with -VIN, output
OFF
TEL:
FAX:
USA
1-760-930-4600
1-760-930-0698
Europe
44-(0)1384-842-211
44-(0)1384-843-355
Asia
852-2437-9662
852-2402-4426
4
