SMCJ5.0(C)A - SMCJ170(C)A
1500W SURFACE MOUNT TRANSIENT VOLTAGE
SUPPRESSOR
Features
·
·
·
·
·
·
·
1500W Peak Pulse Power Dissipation
5.0V - 170V Standoff Voltages
Glass Passivated Die Construction
Uni- and Bi-Directional Versions Available
Excellent Clamping Capability
Fast Response Time
Plastic Case Material has UL Flammability
Classification Rating 94V-0
B
SMC
Dim
A
B
C
D
E
G
H
Min
5.59
6.60
2.75
0.15
7.75
0.10
0.76
2.00
Max
6.22
7.11
3.18
0.31
8.13
0.20
1.52
2.62
A
C
Mechanical Data
·
·
·
·
·
·
·
Case: SMC, Transfer Molded Epoxy
Terminals: Solderable per MIL-STD-202,
Method 208
Also Available in Lead Free Plating (Matte Tin
Finish). Please see Ordering Information,
Note 5, on Page 4
Polarity Indicator: Cathode Band
(Note: Bi-directional devices have no polarity
indicator.)
Marking: Date Code and Marking Code
See Page 3
Weight: 0.21 grams (approx.)
Ordering Info: See Page 3
D
J
H
G
E
J
All Dimensions in mm
Maximum Ratings
@ T
A
= 25°C unless otherwise specified
Characteristic
Peak Pulse Power Dissipation
(Non repetitive current pulse derated above T
A
= 25°C) (Note 1)
Peak Forward Surge Current, 8.3ms Single Half Sine Wave
Superimposed on Rated Load (JEDEC Method) (Notes 1, 2, & 3)
Steady State Power Dissipation @ T
L
= 75°C
Instantaneous Forward Voltage @ I
PP
= 35A
(Notes 1, 2, & 3)
Operating Temperature Range
Storage Temperature Range
Notes:
Symbol
P
PK
I
FSM
PM
(AV)
V
F
T
j
T
STG
Value
1500
200
5.0
3.5
-55 to +150
-55 to +175
Unit
W
A
W
V
°C
°C
1. Valid provided that terminals are kept at ambient temperature.
2. Measured with 8.3ms single half sine-wave. Duty cycle = 4 pulses per minute maximum.
3. Unidirectional units only.
DS19003 Rev. 12 - 2
1 of 4
www.diodes.com
SMCJ5.0(C)A - SMCJ170(C)A
ã
Diodes Incorporated
100
PEAK PULSE DERATING IN % OF
PEAK POWER OR CURRENT
10,000
Measured at
zero bias
C
T
, CAPACITANCE (pF)
75
Uni-directional
1000
50
Bi-directional
100
25
10 X 1000 Waveform
as defined by REA
T
j
= 25°C
f = 1.0 MHz
V
sig
= 50 mV p-p
0
0
25
50
75
100 125 150 175
200
10
1
10
100
1000
T
A
, AMBIENT TEMPERATURE (°C)
Fig. 1 Pulse Derating Curve
V
RWM
, REVERSE STANDOFF VOLTAGE (V)
Fig. 2 Typical Total Capacitance
100
P
d
, PEAK PULSE POWER (kW)
T
j
= 25°C
Non Repetitive
Pulse Waveform
Shown in Fig. 4
I
P
, PEAK PULSE CURRENT (%I
pp
)
100
Peak Value I
pp
10
Half Value I
pp
/2
50
1.0
t
p
0.1
0.1
1.0
10
100
1000
10000
0
10 X 1000 Waveform
as defined by R.E.A.
0
1
2
3
t, TIME (ms)
Fig. 4 Pulse Waveform
PM
(AV),
STEADY STATE POWER DISSIPATION (W)
5.0
PEAK FORWARD SURGE CURRENT, (A)
200
Pulse Width 8.3ms
Single Half-Sine-Wave
(JEDEC METHOD)
4.0
100
3.0
2.0
1.0
60Hz Resistive or
Inductive Load
10
1
2
5
10
20
50
100
0.0
0
25
50
75
100
125
150
175
200
T
L
, LEAD TEMPERATURE (°C)
Fig. 6 Steady State Power Derating Curve
NUMBER OF CYCLES AT 60Hz
Fig. 5, Maximum Non-Repetitive Surge Current
DS19003 Rev. 12 - 2
3 of 4
www.diodes.com
SMCJ5.0(C)A - SMCJ170(C)A
Ordering Information
Device
(Note 4)
Packaging
SMC
Shipping
5000/Tape & Reel
SMCJXXX(C)A-13
Notes:
4. For Packaging Details, go to our website at http://www.diodes.com/datasheets/ap02007.pdf.
5. For Lead Free version (with Lead Free terminal finish) part number, please add "-F" suffix to part number above.
Example: SMCJ170A-13-F.
Marking Information
YWW
XXX
XXX = Product type marking code (See Page 2)
= Manufacturers’ code marking
YWW = Date code marking
Y = Last digit of year ex: 2 for 2002
WW = Week code 01 to 52
DS19003 Rev. 12 - 2
4 of 4
www.diodes.com
