S-Parameters
Frequency S11 Mag S11 Ang S21 Mag S21 Ang S12 Mag S12 Ang S22 Mag S22 Ang
10.0
100.0
200.0
400.0
600.0
800.0
1000.0
1200.0
1400.0
1600.0
1800.0
2000.0
0.070
0.070
0.080
0.100
0.120
0.140
0.160
0.160
0.160
0.160
0.170
0.230
-9.00
-30.00
-57.00
-99.00
-134.00
-160.00
173.00
144.00
109.00
65.00
12.00
-36.00
3.290
3.250
3.220
3.130
3.060
3.010
2.970
3.020
3.100
3.170
3.180
3.010
-180.00
168.00
156.00
133.00
112.00
90.00
69.00
47.00
24.00
-1.00
-29.00
-61.00
0.150
0.150
0.150
0.150
0.150
0.150
0.150
0.150
0.160
0.170
0.180
0.190
1.00
-4.00
-7.00
-16.00
-24.00
-31.00
-40.00
-47.00
-56.00
-66.00
-77.00
-92.00
0.070
0.080
0.080
0.100
0.120
0.130
0.130
0.130
0.120
0.130
0.160
0.190
-178.00
153.00
130.00
88.00
53.00
27.00
-2.00
-33.00
-71.00
-108.00
-151.00
170.00
Absolute Maximum Conditions
Maximum Operating Temperature
Maximum Case Temperature
Continuous RF Input Power
Maximum Peak Power
(3 µsec max)
-55.0 - 100.0 °C
125.0 °C
13.0 dBm
0.5 W
Maximum Storage Temperature
Maximum Supply Voltage
Short Term RF Input Power
(1 minute max)
-62.0 - 125.0 °C
18.0 Volts
50.0 mW
