DK02S/D SERIES
2W DC/DC CONVERTER, DIP Package, High Isolation
FEATURES
Efficiency up to 75%
Standard DIP-16 Package
Reinforced Insulation rated for 300VAC Working
Voltage
High Isolation Voltage 4000VAC
Operating Temperatue Range –25°C to +80°C
Low isotation Capacitance
Low Leakage Current
Lead free, RoHs Compliant
3 Years Product Warranty
The DK02S/D series are miniature, DIP Package, isolated 2W DC/DC converters with ultra- high 4,000VAC isolation . It offers
low leakage current and allows a wide operating temperature range of –25°C to +80°C.These isolated DC/DC converters are the
latest offering from a world leader in power systems technology and manufacturing ― Delta Electronics, Inc. With creative design
technology and optimization of component placement, these converters possess outstanding electrical and thermal
performance, as well as extremely high reliability under highly stressful operating conditions
Model List
Model
Number
Input
Voltage
(Range)
VDC
DK02S0505A
DK02S0512A
DK02S0515A
DK02D0512A
DK02D0515A
DK02S1205A
DK02S1212A
DK02S1215A
DK02D1212A
DK02D1215A
DK02S2405A
DK02S2412A
DK02S2415A
DK02D2412A
DK02D2415A
Output
Voltage
VDC
5
12
15
±12
±15
5
12
15
±12
±15
5
12
15
±12
±15
Output Current
Max.
Ma
400
165
133
±83
±66
400
165
133
±83
±66
400
165
133
±83
±66
Min.
Ma
8
3
2.5
±1.5
±1
8
3
2.5
±1.5
±1
8
3
2.5
±1.5
±1
Input Current
@Max. Load
Ma(typ.)
606
600
605
553
542
253
250
252
224
220
126
125
126
112
110
@No Load
Ma(typ.)
% (max.)
12
10
10
10
10
12
10
10
10
10
12
10
10
10
10
Uf
330
Load
Max. Capacitive
Regulation
Load
Efficiency
(typ.)
@Max. Load
%
66
66
66
72
73
66
66
66
74
75
66
66
66
74
75
* For each output
5
(4.5 ~ 5.5)
60
100*
12
(10.8 ~ 13.2)
330
30
100*
24
(21.6 ~ 26.4)
330
15
100*
DS_DK02S/D_11052013
E-mail: DCDC@delta.com.tw
http://www.delta.com.tw/dcdc
P1
Input Characteristics
Parameter
Input Voltage Range
Model
5V Input Models
12V Input Models
24V Input Models
5V Input Models
Input Surge Voltage (1 sec. max.)
Reverse Polarity Input Current
Input Filter
Internal Power Dissipation
All Models
---
12V Input Models
24V Input Models
Min.
4.5
10.8
21.6
-0.7
-0.7
-0.7
---
Typ.
5
12
24
---
---
---
---
---
Max.
5.5
13.2
26.4
9
18
30
0.3
650
A
Mw
VDC
Unit
Internal Capacitor
Output Characteristics
Parameter
Output Voltage Accuracy
Output Voltage Balance
Line Regulation
Load Regulation
Ripple & Noise (20MHz)
Ripple & Noise (20MHz)
Ripple & Noise (20MHz)
Temperature Coefficient
Short Circuit Protection
Over Line, Load & Temp.
Dual Output, Balanced Loads
Vin=Min. to Max.
Io=20% to 100%
---
---
---
---
Conditions
Min.
---
---
---
Typ.
±2.0
±0.1
±1.2
100
---
---
±0.01
Max.
±4.0
±1.0
±1.5
150
200
15
±0.02
Unit
%
%
%
Mv
P-P
Mv
P-P
Mv rms
%/℃
See Model Selection Guide
0.5 Second Max.
Isolation and Safety Standards
Parameter
I/O Isolation Voltage (rated)
I/O Isolation Test Voltage
Leakage Current
I/O Isolation Resistance
I/O Isolation Capacitance
Safety Standards
Conditions
60 Seconds
Flash tested for 1 Second
240VAC, 60Hz
500 VDC
100KHz, 1V
Min.
4000
6000
---
10
---
Typ.
---
---
---
---
15
Max.
---
---
2
---
20
Unit
VACrms
V
PK
Ua
GΩ
Pf
Cul/UL60950-1, CSA C22.2 No. 60950-1-03
UL60601-1,CSA C22.2 No.601-1
IEC/EN 60950-1, IEC/EN 60601-1
Approvals
IEC60950-1 CB report, Cul/UL 60950-1 certificate
UL60601-1 UL certificate
General Characteristics
Parameter
Switching Frequency
MTBF (calculated)
MIL-HDBK-217F@25℃, Ground Benign
Conditions
Min.
50
2,000,000
Typ.
80
---
Max.
100
---
Unit
KHz
Hours
Recommended Input Fuse
5V Input Models
1000Ma Slow-Blow Type
12V Input Models
500Ma Slow-Blow Type
24V Input Models
200Ma Slow-Blow Type
Environmental Characteristics
Parameter
Operating Temperature Range (with Derating)
Case Temperature
Storage Temperature Range
Humidity (non condensing)
Cooling
Lead Temperature (1.5mm from case for 10Sec.)
Conditions
Ambient
Min.
Max.
-25
+80
---
+90
-50
+125
---
95
Free-Air convection
---
260
Unit
℃
℃
℃
% rel. H
℃
DS_DK02S/D_11052013
E-mail: DCDC@delta.com.tw
http://www.delta.com.tw/dcdc
P2
Power Derating Curve
100
80
Natural
convection
100LFM
Output Power (%)
60
200LFM
400LFM
40
20
0
-25
~
0
20
40
60
80
100 110
Ambient Temperature
Notes
1
2
3
4
5
6
Specifications typical at Ta=+25℃, resistive load, nominal input voltage and rated output current unless otherwise noted.
Ripple & Noise measurement bandwidth is 0-20MHz.
These power converters require a minimum output loading to maintain specified regulation, operation under no-load conditions will not
damage these modules; however they may not meet all specifications listed.
All DC/DC converters should be externally fused at the front end for protection.
That “natural convection” is about 20LFM but is not equal to still air (0 LFM).
Specifications subject to change without notice.
Mechancial Drawings
Mechanical Dimensions
0.5 [0.02]
3.8
8.6 [0.34]
[0.15]
Pin Connections
Pin
1
7
8
9
10
16
2.54
[0.10]
7
8
Single Output
-Vin
NC
NC
+Vout
-Vout
+Vin
Dual Output
-Vin
NC
Common
+Vout
-Vout
+Vin
0.50 [0.02]
23.8 [0.94]
3.0
[0.12]
1
15.24 [0.60]
NC: No Connection
10.16 [0.40]
Bottom View
16
10
9
13.4 [0.53]
►
All
dimensions in mm (inches)
X.X±0.25 (X.XX±0.01)
X.XX±0.13 ( X.XXX±0.005)
1.62
[0.06]
►
Tolerance:
►
Pin
diameter
0.5 ±0.05 (0.02±0.002)
Physical Outline
Case Size
Case Material
Weight
:
:
:
23.8x13.4x8.6mm (0.94x0.53x0.34 Inches)
Non-Conductive Black Plastic (flammability to UL 94V-0 rated)
5.1g
DS_DK02S/D_11052013
E-mail: DCDC@delta.com.tw
http://www.delta.com.tw/dcdc
P3
Part Numbering System
D
Form factor
D - DIP
P - SIP
S - SMD
K
Family series
A~Z
02
Watt
01 : 1W
02 : 2W
03 : 3W
04 : 4W
06 : 6W
S
Number of
Outputs
S - Single
D - Dual
05
Input Voltage
03 : 3.3V
05 : 5V
12 : 12V
15 : 15V
24 : 24V
05
Output Voltage
03 : 3.3V
05 : 5V
12 : 12V
15 : 15V
24 : 24V
A
Option Code
A - Std. Functions
WARRANTY
Delta offers a three(3) years limited warranty. Complete warranty information is listed on our web site or is available upon request from Delta.
Information furnished by Delta is believed to be accurate and reliable. However, no responsibility is assumed by Delta for its use, nor for any
infringements of patents or other rights of third parties, which may result from its use. No license is granted by implication or otherwise under
any patent or patent rights of Delta. Delta reserves the right to revise these specifications at any time, without notice.
DS_DK02S/D_11052013
E-mail: DCDC@delta.com.tw
http://www.delta.com.tw/dcdc
P4
