LFC
Flat
Coils
.40" max
.35 ± .05"
.15 ± .03"
1.00" min
24 AWG/TCW
.31"± .02"
These are low-cost, high Q, radial lead inductors. This unique configuration mak them ideally suited for use in high density
es
printed circuit board assemblies. The flat coil configuration also offers twice the inductance and Q v
alues as axial lead
inductors. Epoxy coating and shrink tubing are available by special order.
INDUCTANCES 1.0µH to 10.000µH
CURRENT RATING Based on current flow and temperature rise
of 20°C maxim
um at 80°C ambient temperature.
OPERATING TEMPERATURE - 20°C to +100°C.
INDUCTANCE TOLERANCE ±10% over entire range
TERMINAL STRENGTH 5 lb. minimum
TESTING Inductance and Q measured on Q meter HP4342A
at specified frequency. SRF measured on Grid Dip Meter or
equivalent. DCR measured on Digital Milliohm meter
.
MARKING Inductance value (i.e. 1R0K)
PACKAGING Bulk only
TEST
FREQUENCY
(MHz)
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.25
.25
.25
.25
.25
.25
.25
.25
.25
.25
.25
.25
PART
NUMBER
LFC-1R0K
LFC-1R2K
LFC-1R5K
LFC-1R8K
LFC-2R2K
LFC-2R5K
LFC-2R7K
LFC-3R3K
LFC-3R9K
LFC-4R7K
LFC-5R0K
LFC-5R6K
LFC-6R8K
LFC-7R6K
LFC-8R2K
LFC-100K
LFC-120K
LFC-150K
LFC-180K
LFC-220K
LFC-250K
LFC-270K
LFC-330K
LFC-390K
LFC-470K
LFC-500K
LFC-560K
LFC-680K
LFC-750K
LFC-820K
LFC-101K
LFC-121K
LFC-151K
LFC-181K
LFC-221K
LFC-251K
LFC-271K
LFC-331K
LFC-391K
LFC-471K
LFC-501K
LFC-561K
LFC-681K
LFC-751K
LFC-821K
LFC-102K
LFC-122K
LFC-152K
LFC-182K
LFC-222K
LFC-252K
LFC-272K
LFC-332K
LFC-392K
LFC-472K
LFC-602K
LFC-752K
LFC-103K
INDUCTANCE
(µH)
1.0
1.2
1.5
1.8
2.2
2.5
2.7
3.3
3.9
4.7
5.0
5.6
6.8
7.6
8.2
10
12
15
18
22
25
27
33
39
47
50
56
68
75
82
100
120
150
180
220
250
270
330
390
470
500
560
680
750
820
1000
1200
1500
1800
2200
2500
2700
3300
3900
4700
6000
7500
10000
Q
MINIMUM
37
39
35
37
38
40
43
35
37
37
40
38
29
30
32
80
40
40
40
40
50
50
45
45
45
40
40
40
40
50
80
70
70
70
50
40
50
50
45
40
35
40
45
30
40
70
70
62
62
60
60
60
50
50
50
35
25
25
DC RESISTANCE
OHMS
MAXIMUM (Ω )
.015
.012
.014
.020
.025
.030
.028
.036
.050
.053
.080
.092
.113
.110
.116
.190
.140
.158
.180
.230
.285
.300
.346
.371
.502
.610
.687
.808
1.200
1.450
1.160
1.725
1.855
2.070
2.105
2.500
2.700
3.335
3.450
5.290
5.350
5.405
5.930
6.200
6.325
8.600
10.000
14.260
15.760
17.700
18.000
19.100
21.740
26.000
28.900
31.000
50.000
70.000
RATED DC
CURRENT MAX
(A)
7.0
6.0
5.0
4.8
4.4
4.1
4.0
3.7
3.4
3.2
2.9
2.8
2.6
2.5
2.2
2.1
2.0
1.6
1.6
1.4
1.3
1.3
1.2
1.1
1.03
1.00
.95
.90
.86
.86
.70
.65
.60
.58
.49
.49
.45
.41
.39
.35
.34
.32
.29
.28
.27
.21
.21
.19
.17
.15
.14
.14
.13
.12
.11
.10
.08
.07
