Solid State Devices, Inc.
14701 Firestone Blvd * La Mirada, Ca 90638
Phone: (562) 404-4474 * Fax: (562) 404-1773
ssdi@ssdi-power.com * www.ssdi-power.com
SSR2008CTM, SSR2008CTZ
SSR2009CTM, SSR2009CTZ
SSR2010CTM, SSR2010CTZ
20 AMPS
100 VOLTS
CENTER TAP
SCHOTTKY RECTIFIER
TO-254
TO-254Z
Designer’s Data Sheet
FEATURES:
•
•
•
•
•
•
•
•
•
PIV: 100 Volts
Low Reverse Leakage Current
Low Forward Voltage Drop
Guard Ring for Overvoltage Protection
Isolated Hermetically Sealed Package
Available in Glass or Ceramic Seal Packages
Custom Lead Forming Available
Eutectic Die Attach
175
°
C Operating Junction Temperature
TX, TXV, and Space Level Screening Available
•
Available in Given Voltage (2008, 2009, 2010) in the Following Configurations:
TO-254:
SSR2010CTM, SSR2010CTMUB, SSR2010CTMDB, SSR2010CAM, SSR2010CAMUB, SSR2010CAMDB
SSR1010DM, SSR1010DMUB, SSR1010DMDB
TO-254Z:
SSR2010CTZ, SSR2010CTZUB, SSR2010CTZDB, SSR2010CAZ, SSR2010CAZUB, SSR2010CAZDB
SSR1010DZ, SSR1010DZUB, SSR1010DZDB
MAXIMUM RATINGS
1/
Peak Repetitive Reverse Voltage and
DC Blocking Voltage
Average Rectified Forward Current
3/ 4/
(Resistive Load, 60 Hz, Sine Wave, T
C
= 25
°
C)
Peak Surge Current
3/ 4/
(8.3 ms Pulse, Half Sine Wave, T
A
= 25
°
C)
Operating and Storage Temperature
Maximum Thermal Resistance
NOTE:
SSR2008CTM & CTZ
SSR2090CTM & CTZ
SSR2010CTM & CTZ
Symbol
V
RRM
V
RWM
V
R
I
O
I
FSM
T
OP
& T
stg
Junction to Case
3/
Junction to Case
2/
R
θJC
Value
80
90
100
20
300
-65 to +175
1.0
1.7
Unit
Volts
Amps
Amps
°
C
°
C/W
1/
2/
3/
4/
All Electrical Characteristics @25
°
C, Unless Otherwise Specified.
Per Leg.
Pins 1 and 3 Connected Together.
Doubler: I
O
= 10A, I
FSM
= 200A.
NOTE:
All specifications are subject to change without notification.
SCD's for these devices should be reviewed by SSDI prior to release.
DATA SHEET #: RS0075F
DOC
Solid State Devices, Inc.
14701 Firestone Blvd * La Mirada, Ca 90638
Phone: (562) 404-4474 * Fax: (562) 404-1773
ssdi@ssdi-power.com * www.ssdi-power.com
SSR2008CTM, SSR2008CTZ
SSR2009CTM, SSR2009CTZ
SSR2010CTM, SSR2010CTZ
Symbol
I
F
= 1A
I
F
= 5A
I
F
= 10A
I
F
= 10A, T
A
= 100
°
C
I
F
= 10A, T
A
= -55
°
C,
V
R
= 100V, T
A
= 25
°
C
V
R
= 100V, T
C
= 100
°
C
V
F1
V
F2
V
F3
V
F4
V
F5
I
R1
I
R2
C
J
ELECTRICAL CHARACTERISTICS
1/, 2/
Instantaneous Forward Voltage Drop
(300 - 500µs Pulse)
Instantaneous Forward Voltage Drop
(300 - 500µs Pulse)
Reverse Leakage Current
(300µs pulse minimum)
Junction Capacitance
(V
R
= 10 V, f = 1MHz, T
A
= 25
°
C)
CASE OUTLINE: TO-254 (Suffix M)
Max
0.57
0.72
0.80
0.70
0.90
100
5
400
Unit
Volts
Volts
µA
mA
pF
CASE OUTLINE: TO-254Z (Suffix Z)
OPTIONAL LEAD BEND CONFIGURATION
CODE
CT
CA
D
DR
SUFFIX MDB & ZDB
NOTE:
SUFFUX MUB & ZUB
PIN ASSIGNMENT
FUNCTION
Common Cathode
Common Anode
Doubler
Reverse Doubler
PIN 1
Anode
Cathode
Anode
PIN 2
Cathode
Anode
PIN 3
Anode
Cathode
Anode
Cathode Common
Common Cathode
1/
All Electrical Characteristics @25
°
C, Unless Otherwise Specified.
2/
Per Leg.
NOTE:
All specifications are subject to change without notification.
SCD's for these devices should be reviewed by SSDI prior to release.
DATA SHEET #: RS0075F
DOC
