The EN60950 (intended for office automation equipment)
conforms with a 3mm
.118inch
gap.
When directly opening or closing the primary power supply side,
a contact gap of at least 3mm
.118inch
is required in order to
ensure safety.
19
J8(AJ8)
ORDERING INFORMATION
Ex.
AJ8
W
1
0
0
W
W
T
Type of
Size of handle
switch
AJ7: J8
Nil: Standard size
switch
(10 mm
.394inch)
W: Wide size
(19 mm
.748 inch)
Poles
Terminal shape
Actuator indication
0:
1:
2:
O
I
Actuator color*
W: White
B: Black
R: Red
Z: Dark gray
H: Light gray
L: Blue
G: Green
Y: Yellow
Flang color*
Nil: Black
(W: White)
(R: Red)
(Z: Dark gray)
(H: Light gray)
(L: Blue)
(G: Green)
(Y: Yellow)
Insulation guard
Nil: Short guard
type
T: Long guard
type (.250
Quick-connect
terminal and
soldering
terminal of
standard size
only)
1: Single pole 0: .250 Quick-
2: Double pole
connect terminal
1: Soldering
terminal
2: PC board
terminal
3: PC board right
andle terminal
4: PC board left
angle terminal
O
I
Remarks: 1. Please consult us for details concerning different flange colors.
2. “I
O”
is engraved on all flanges.
3. The color of
I O
indication on the actuator:
• White actuator: black
• Others: white
PRODUCT TYPES
1. Standard actuator type
(1) Without indication on actuators
Terminal shape
.250 Quick-connect terminal
Soldering terminal
PC board terminal
PC board right angle terminal
PC board left angle terminal
Poles
Single pole
Double pole
Single pole
Double pole
Single pole
Double pole
Single pole
Double pole
Single pole
Double pole
Poles
Single pole
Double pole
Single pole
Double pole
Single pole
Double pole
Single pole
Double pole
Single pole
Double pole
ON-OFF
Operating types
With
| O
indication
AJ8101*
AJ8201*
AJ8111*
AJ8211*
AJ8121*
AJ8221*
AJ8131*
AJ8231*
AJ8141*
AJ8241*
ON-OFF
Operating types
Without indication
AJ8100*
AJ8200*
AJ8110*
AJ8210*
AJ8120*
AJ8220*
AJ8130*
AJ8230*
AJ8140*
AJ8240*
With
— O
indication
AJ8102*
AJ8202*
AJ8112*
AJ8212*
AJ8122*
AJ8222*
AJ8132*
AJ8232*
AJ8142*
AJ8242*
(2) With
| O
indication on actuators
Terminal shape
.250 Quick-connect terminal
Soldering terminal
PC board terminal
PC board right angle terminal
PC board left angle terminal
(Standard flange color is black. For other colors type, they are custom ordered.)
Remarks: 1. A letter indicating the actuator color is entered in place of * symbol. (W: White B: Black R: Red Z: Dark gray H: Light gray L: Blue G: Green
Y: Yellow)
For requests of other flange color,please suffix following letter. (W: White R: Red Z: Dark gray H: Light gray L: Blue G: Green Y: Yellow)
2. Long guard type is available for .250 Quick-connect terminal and soldering terminal type.
When ordering, please suffix T.
3. The color of
| O
indication on the actuator:
White actuator: black Others: white
4. They come with a stamp indicating international standards without your request.
5. Note that the position of the
|
mark on the flange is used as a reference for left angle and right angle units as shown in the diagram below.
I
mark
I
mark
Right angle terminal
Left angle terminal
20
J8(AJ8)
2.Wide actuator type
(1) Without indication on actuators
Terminal shape
.250 Quick-connect terminal
Soldering terminal
PC board terminal
Poles
Single pole
Double pole
Single pole
Double pole
Single pole
Double pole
Poles
Single pole
Double pole
Single pole
Double pole
Single pole
Double pole
ON-OFF
Operating types
ON-OFF
Operating types
Without indication
AJ8W100*
AJ8W200*
AJ8W110*
AJ8W210*
AJ8W120*
AJ8W220*
With
| O
indication
AJ8W101*
AJ8W201*
AJ8W111*
AJ8W211*
AJ8W121*
AJ8W221*
With
— O
indication
AJ8W102*
AJ8W202*
AJ8W112*
AJ8W212*
AJ8W122*
AJ8W222*
(2) With
| O
indication on actuators
Terminal shape
.250 Quick-connect terminal
Soldering terminal
PC board terminal
(Standard flange color is black. For other colors type, they are custom ordered.)
Remarks: 1. A letter indicating the actuator color is entered in place of * symbol. (W: White B: Black R: Red Z: Dark gray H: Light gray L: Blue G: Green
Y: Yellow)
For requests of other flange color,please suffix following letter. (W: White R: Red Z: Dark gray H: Light gray L: Blue G: Green Y: Yellow)
2. The color of
| O
indication on the actuator:
White actuator: black Others: white
3. They come with a stamp indicating international standards without your request.
SPECIFICATIONS
1. Contact rating
Type
J8 switch
Voltage
AC 250V
Resistive load
(cos
φ
]
1.0)
16A
Motor load
(EN61058-1)
(cos
φ
]
0.6)
4A
Remark: The motor load is in accordance with EN61058-1. Inlush current can be switched up to the value of 6 times the indicated rating.
2. Characteristics
Expected life
(Min. operations)
Initial insulation resistance
(Between terminals)
Initial breakdown voltage
(Between terminals)
Initial contact resistance
(By voltage drop at 1A, 2 to 4V DC)
Temperature rise
Vibration resistance
Shock resistance
Actuator strength
Tensile terminal strength
Ambient temperature
Ambient humidity
Flame retardancy
Tracking resistance
Operating force
(reference characteristics)
Single pole
Double pole
at 6
×
10
3
ope. or less
from 6
×
10
3
ope. to 10
4
Mechanical
Electrical
Min. 5
×
10
4
(at 20 cpm.)
Min. 10
4
(at 7 cpm., at rated load)
Min. 100 MΩ
(at 500V DC measured by insulation resistive meter)
2,000 Vrms detection current: 10 mA
Max. 100mΩ
Max. 30°C (UL1054)
Max. 55°C (VDE0630)
10 to 55 Hz at double amplitude of 1.5mm
Min. 490m/s
2
{50 G}
40 N {4.08kgf} for 1 minute
(operating direction)
100 N {10.2kgf} for 1 minute or more
(Pull & push direction)
–25°C to +85°C
– 13
°
F to +185
°
F
(Not freezing below 0°C
32
°
F
)
Max. 85%R.H.
UL94V-0
Min. 175
2.45
±
1.47N {0.25
±0.15kgf}
4.5
±
2.5N {0.46
±0.25kgf}
Remark: Test conditions are in accordance with EN61058-1, UL1054 and JIS C 6571.
21
J8(AJ8)
DIMENSIONS
1) .250 Quick-connect terminal/Short guard type
Long guard type
.250 Quick-connect terminal
Double pole
15
.591
12.8
.504
10
.394
7.7
.303
ON
OFF
mm
inch
General tolerance
±0.5
±.020
Diagram of recommended
locations for panel
mounting holes
X
32 deg
7.7
.303
ON
OFF
−0
12.9
+0.1
−0
.508
+.004
±4
Single pole
30
1.181
30
1.181
32 deg
±4
2
.079
16
.630
4.4
.173
10.6 11
.417 .433
19.5
.768
2
.079
16
.630
4.4
.173
10.6
.417
Panel thickness
0.75 to 1.25
.030 to .049
1.25 to 2
.049 to .079
2 to 3
.079 to .118
X
28.2
+0
–0.1
1.110
+0
–.004
28.4
+0
–0.1
1.118
+0
–.004
28.8
+0
–0.1
1.134
+0
–.004
φ
1.75
φ
.069
15
.591
28
1.102
6.35
.250
φ
1.75
φ
.069
15
.591
28
1.102
6.35
.250
8.75
.344
12.5
.492
0.8
.031
4.375
.172
2) Soldering terminal
Long guard type
Soldering terminal
Double pole
15
.591
12.8
.504
10
.394
7.7
.303
ON
OFF
Single pole
30
1.181
32
±4
deg
7.7
.303
ON
OFF
Diagram of recommended
locations for panel
mounting holes
X
30
1.181
32
±4
deg
2
.079
16
.630
−0
12.9
+0.1
−0
.508
+.004
19.5
.768
2
.079
16
.630
2.5
.098
15
.591
28
1.102
4.375
.172
3.5
.138
10.6 11
.417 .433
Panel thickness
0.75 to 1.25
.030 to .049
1.25 to 2
.049 to .079
2 to 3
.079 to .118
X
28.2
+0
–0.1
1.110
+0
–.004
28.4
+0
–0.1
1.118
+0
–.004
28.8
+0
–0.1
1.134
+0
–.004
10.6
.417
2.5
.098
15
.591
28
1.102
3.5
.138
8.75
.344
12.5
.492
0.8
.031
3) PC board terminal
Double pole
15
.591
±.004
3
±0.2
.118
±.008
±0.1
PC board pattern
Single pole
1.2
±0.1
.047
±.004
8.75
±0.1
.344
±.004
15
.591
±.004
3
±0.2
.118
±.008
±0.1
Diagram of recommended locations for
panel mounting holes
X
1.2
±0.1
.047
±.004
4.375
±0.1
.172
±.004
−0
12.9
+0.1
−0
.508
+.004
Double pole
15
.591
12.8
.504
10
.394
7.7
.303
ON
OFF
Single pole
30
1.181
32
±4
deg
19.5
.768
2
.079
16
.630
(7.5)
(.295)
2
.079
15
.591
28
1.102
4
.157
8.75
.344
12.5
.492
0.8
.031
4.375
.172
Panel thickness
0.75 to 1.25
.030 to .049
1.25 to 2
.049 to .079
2 to 3
.079 to .118
X
28.2
+0
–0.1
1.110
+0
–.004
28.4
+0
–0.1
1.118
+0
–.004
28.8
+0
–0.1
1.134
+0
–.004
22
J8(AJ8)
4) PC board right angle terminal
PC board pattern
Double pole
15
±0.1
.591
±.004
3
±0.2
.118
±.008
1.2
±0.1
.047
±.004
8
±0.1
.315
±.004
mm
inch
General tolerance
±0.5
±.020
Diagram of recommended locations for
panel mounting holes
X
15
±0.1
.591
±.004
3
±0.2
.118
±.008
1.2
±0.1
.047
±.004
21.0
±0.3
.827
±.012
−0
12.9
+0.1
17.5
±0.3
−0
.508
+.004
.689
±.012
Single pole
Terminal side
4.375
.172
±.004
±0.1
Double pole
30
1.181
32°
±4
7.7
.303
ON
OFF
Single pole
15
.591
12.8
.504
10
.394
19.5
.768
2
.079
16
.630
Panel thickness
2
.079
X
28.2
+0
–0.1
1.110
+0
–.004
28.4
+0
–0.1
1.118
+0
–.004
28.8
+0
–0.1
1.134
+0
–.004
0.75 to 1.25
.030 to .049
1.25 to 2
.049 to .079
12.5
.492
8 0.8
.315 .031
28
1.102
4
.157
2 to 3
.079 to .118
Remark: Left angle terminals type is also available.
C8051F version digital hygrometer debugging 4---hardware SMbus and PCF8563 communication[[i]This post was last edited by sdjntl on 2010-8-19 15:20[/i]]...
Sincerely ask for advice, Kulit XLT-190M small pressure sensor, connected to DB9, the result is that the sensor output signal cannot be detected. The wiring definition is as follows:
Kulite XTL-190M W...
I'm a novice. I can't synchronize the BSL of MSP430F5171. The programming program I downloaded online doesn't support 5171. I don't know what's wrong now. . . . Help:surrender:...
Today is the Mid-Autumn Festival. Have you gone home for reunion? ? I wonder if those who went home for reunion were surrounded by gossiping women and urged to get married? :puzzle: It seems that when...
The contradictory code between class and interrupt in ADS c++ language is as follows: class time { public: friend void __irq timeUp(void); int timeCount; } void __irq timeUp() { timeCount=1;//There wi...
Images in science fiction movies often break through the limits of reality, such as in the movie "Minority Report." Tom Cruise uses a multi-touch screen to browse information. Capacitive sensing te...[Details]
1. Principle of displacement angle sensor
The angle sensor is used to detect angles. It has a hole in its body that fits the LEGO axle. When connected to the RCX, the angle sensor counts once ...[Details]
From the PIC16F946 datasheet, we know that there are two ways to write values to the LCD for display:
1. Directly write the value to LCDDATA1~LCDDATA23
2. Use disconnect t...[Details]
Xiaomi, a well-known Internet phone in mainland China, won a million-unit order contract from China Unicom on November 20 last year, which made Xiaomi famous in mainland China. In April this year...[Details]
With the advocacy and implementation of the government's Safe City Plan, the security market has increasingly higher requirements for the clarity of surveillance images. Imagine that after a case o...[Details]
Problems such as the depletion of natural resources, air pollution, traffic congestion, and rising fossil fuel prices have forced societies and individuals to seek alternative means of transportati...[Details]
Motors, especially those with brushes, generate a lot of noise. This noise must be dealt with if the appliance is to meet the requirements of EMC standards. The means to solve EMC are nothing more ...[Details]
Abstract: With the development and construction of BeiDou II system, China will shift from the situation dominated by GPS to the situation dominated by BeiDou II global navigation system independen...[Details]
Corelink Semiconductor has launched the CL1100-based 5-7W E27 LED lighting driver system solution DB2. This driver module meets the requirements of small size (L×W×H=5.1cm×2.1cm×1.8cm), low standby...[Details]
With the rapid development of wireless
digital communication
, more challenges have been raised for integrated circuit design and testing. In the product design stage, in order to ensure
t...[Details]
The launch of Shenzhou IX is imminent, and Tiangong is welcoming visitors again. Yesterday, Professor Fu Qiang, Vice President of the Institute of Science and Industrial Technology of Harbin Instit...[Details]
LED is the abbreviation of the English word. Its main meanings are: LED = Light Emitting Diode, a solid-state semiconductor device that can convert electrical energy into visible light. It can dire...[Details]
The overall operating performance of an electric car depends first on its battery system and motor drive system. The drive system of an electric car is generally composed of three main parts: a con...[Details]
1. Fully understand the design requirements of all parties and determine the appropriate solution.
When starting a hardware development project, the original driving force will come from many a...[Details]
1. Introduction
Stepper motor is a basic component that converts electrical energy into kinetic energy. It has been widely used in a variety of electromechanical equipment, such as various machine...[Details]
DIY/Open Source Hardware
京公网安备 11010802033920号
EEWORLD
