Microchip received ISO/TS-16949:2002 certification for its worldwide
headquarters, design and wafer fabrication facilities in Chandler and
Tempe, Arizona, Gresham, Oregon and Mountain View, California. The
Company’s quality system processes and procedures are for its PIC
®
MCUs and dsPIC DSCs, K
EE
L
OQ
®
code hopping devices, Serial
EEPROMs, microperipherals, nonvolatile memory and analog
products. In addition, Microchip’s quality system for the design and
manufacture of development systems is ISO 9001:2000 certified.
DS70135E-page ii
©
2007 Microchip Technology Inc.
dsPIC30F4011/4012
dsPIC30F4011/4012 Enhanced Flash
16-Bit Digital Signal Controller
Note:
This data sheet summarizes features of this group
of dsPIC30F devices and is not intended to be a complete
reference source. For more information on the CPU,
peripherals, register descriptions and general device
functionality, refer to the “dsPIC30F
Family Reference
Manual”
(DS70046). For more information on the device
instruction set and programming, refer to the “dsPIC30F/
33F Programmer’s Reference Manual”
(DS70157).
Peripheral Features:
• High-current sink/source I/O pins: 25 mA/25 mA
• Timer module with programmable prescaler:
- Five 16-bit timers/counters; optionally pair
16-bit timers into 32-bit timer modules
• 16-bit Capture input functions
• 16-bit Compare/PWM output functions
• 3-wire SPI modules (supports 4 Frame modes)
• I
2
C™ module supports Multi-Master/Slave mode
and 7-bit/10-bit addressing
• 2 UART modules with FIFO Buffers
• 1 CAN module, 2.0B compliant
High-Performance, Modified RISC CPU:
• Modified Harvard architecture
• C compiler optimized instruction set architecture
with flexible addressing modes
• 83 base instructions
• 24-bit wide instructions, 16-bit wide data path
• 48 Kbytes on-chip Flash program space
(16K instruction words)
• 2 Kbytes of on-chip data RAM
• 1 Kbyte of nonvolatile data EEPROM
• Up to 30 MIPS operation:
- DC to 40 MHz external clock input
- 4 MHz-10 MHz oscillator input with
PLL active (4x, 8x, 16x)
• 30 interrupt sources:
- 3 external interrupt sources
- 8 user-selectable priority levels for each
interrupt source
- 4 processor trap sources
• 16 x 16-bit working register array
Motor Control PWM Module Features:
• 6 PWM output channels:
- Complementary or Independent Output
modes
- Edge and Center-Aligned modes
• 3 duty cycle generators
• Dedicated time base
• Programmable output polarity
• Dead-time control for Complementary mode
• Manual output control
• Trigger for A/D conversions
Quadrature Encoder Interface Module
Features:
•
•
•
•
•
•
•
Phase A, Phase B and Index Pulse input
16-bit up/down position counter
Count direction status
Position Measurement (x2 and x4) mode
Programmable digital noise filters on inputs
Alternate 16-Bit Timer/Counter mode
Interrupt on position counter rollover/underflow
DSP Engine Features:
Dual data fetch
Accumulator write-back for DSP operations
Modulo and Bit-Reversed Addressing modes
Two, 40-bit wide accumulators with optional
saturation logic
• 17-bit x 17-bit single-cycle hardware
fractional/integer multiplier
• All DSP instructions are single cycle
• ±16-bit, single-cycle shift
•
•
•
•
©
2007 Microchip Technology Inc.
DS70135E-page 1
dsPIC30F4011/4012
Analog Features:
• 10-Bit Analog-to-Digital Converter (A/D) with
4 S/H inputs:
- 1 Msps conversion rate
- 9 input channels
- Conversion available during Sleep and Idle
• Programmable Brown-out Reset
Special Digital Signal Controller
Features (Cont.):
• Flexible Watchdog Timer (WDT) with on-chip,
low-power RC oscillator for reliable operation
• Fail-Safe Clock Monitor operation detects clock
failure and switches to on-chip, low-power
RC oscillator
• Programmable code protection
• In-Circuit Serial Programming™ (ICSP™)
• Selectable Power Management modes:
- Sleep, Idle and Alternate Clock modes
Special Digital Signal Controller
Features:
• Enhanced Flash program memory:
- 10,000 erase/write cycle (min.) for
industrial temperature range, 100K (typical)
• Data EEPROM memory:
- 100,000 erase/write cycle (min.) for
industrial temperature range, 1M (typical)
• Self-reprogrammable under software control
• Power-on Reset (POR), Power-up Timer (PWRT)
and Oscillator Start-up Timer (OST)
CMOS Technology:
•
•
•
•
Low-power, high-speed Flash technology
Wide operating voltage range (2.5V to 5.5V)
Industrial and Extended temperature ranges
Low-power consumption
dsPIC30F Motor Control and Power Conversion Family*
Device
dsPIC30F2010
dsPIC30F3010
dsPIC30F4012
Program
Output
Motor
SRAM EEPROM Timer Input
10-Bit A/D Quad
Pins Mem. Bytes/
Comp/Std Control
Bytes
Bytes
16-bit Cap
1 Msps
Enc
Instructions
PWM
PWM
28
28
28
12K/4K
24K/8K
48K/16K
24K/8K
48K/16K
66K/22K
144K/48K
512
1024
2048
1024
2048
2048
8192
1024
1024
1024
1024
1024
1024
4096
3
5
5
5
5
5
5
4
4
4
4
4
4
8
2
2
2
4
4
4
8
6 ch
6 ch
6 ch
6 ch
6 ch
8 ch
8 ch
6 ch
6 ch
6 ch
9 ch
9 ch
16 ch
16 ch
Yes
Yes
Yes
Yes
Yes
Yes
Yes
UART
I
2
C
™
1
1
1
2
2
1
2
1
1
1
1
1
2
2
1
1
1
1
1
1
1
dsPIC30F3011 40/44
dsPIC30F4011 40/44
dsPIC30F5015
dsPIC30F6010
64
80
* This table provides a summary of the dsPIC30F6010 peripheral features. Other available devices in the dsPIC30F Motor Control
and Power Conversion Family are shown for feature comparison.
