EMC Line Filters
SU16V/16H Types
Shape and Dimensions
qSU16V
23 max.
19 max.
13
27.5 max.
ø0.7
13
±
0.5
10
±
0.5
26 max.
qSU16H
23 max.
4 min.
13
22 max.
ø0.7
13
±
0.5
4 min.
10
±
0.5
[mm]
Specifications
Rated
Current
(A)
0.4
0.5
0.6
0.8
1.0
1.0
1.2
1.5
Inductance
(mH)
min.
30
20
10
8
6
4
3.5
1.5
DC Resistance
(Ω/line)
max.
2.8
1.6
1.2
0.8
0.5
0.4
0.3
0.15
Temp.
Rise
(K) max.
40
40
40
40
40
40
40
40
Weight
(g)
approx.
17.9
18.8
17.0
17.5
18.5
17.2
18.2
17.06
Model
SU16V/H-04300
SU16V/H-05200
SU16V/H-06100
SU16V/H-08080
SU16V/H-10060
SU16V/H-10040
SU16V/H-12035
SU16V/H-15015
•Rated voltage: 250 VAC/VDC •Withstanding voltage: 2000 VAC, one minute between lines •Insulation resistance: At 500 VDC, more than 100 MΩ (between lines)
•Thermal class: E (120˚C) •Temperature: – 25˚C to T˚C(T=120 – temp. rise) •Inductance measurement condition: 1 kHz,1 V,HP-4261A at 20˚C
Impedance vs. Frequency
1M
1M
100K
06100
04300
100K
Impedance (Ω)
10K
Impedance (Ω)
05200
10K
10060
10040
1K
1K
08080
100
12035
100
15015
10
10
1
1K
10K
100K
1M
10M
30M
1
1K
10K
100K
1M
10M
10
30M
Frequency (Hz)
Frequency (Hz)
48
10
