ZAG55W-03: DescriptionSingle Color LED, Green, Water Clear, 1.6mm,; CategoryLED optoelectronic/LED photoelectric; File Size71KB，4 Pages; ManufacturerSUNLED; Websitehttp://www.sunled.com/

Download Datasheet Parametric View All

ZAG55W-03 Overview

Single Color LED, Green, Water Clear, 1.6mm,

ZAG55W-03 Parametric

Parameter Name	Attribute value
Maker	SUNLED
Objectid	1518654067
Reach Compliance Code	compliant
ECCN code	EAR99
compound_id	8252092
color	GREEN
Configuration	SINGLE
Maximum forward current	0.03 A
Lens type	WATER CLEAR
Nominal luminous intensity	480.0 mcd
Installation features	SURFACE MOUNT
Number of functions	1
Number of terminals	2
Maximum operating temperature	80 °C
Minimum operating temperature	-20 °C
Optoelectronic device types	SINGLE COLOR LED
total height	1.8 mm
method of packing	TAPE
peak wavelength	502 nm
shape	ROUND
size	1.6 mm
surface mount	YES
Terminal pitch	3.75 mm
perspective	50 deg

Preview

Download Datasheet

View All

3.2x1.6mm SMD CHIP LED LAMP

ZAG55W-03

SUN LED

Notes:

1. All dimensions are in millimeters (inches).

2. Tolerance is

±0.2(0.0079")

unless otherwise noted.

Ab s o l u t e m a x i m u m r a t i n g s

C)

( T

A

=25

°

C)

Reverse voltage

Forward current

Forward current (peak)

1/10Duty cycle

0.1ms pulse width

Power dissipation

Operation temperature

Storage temperature

V

R

I

F

i

FS

P

T

A

Tstg

AG

( I n G a N)

5

30

100

135

-20 ~ +80

-30 ~ +85

Un i t

Op e r a t i n g Ch a r a c t e r i s t i c s

( T

A

=25

°

C)

Forward voltage (typ.)

(I F=20mA)

Forward voltage (max.)

(I F=20mA)

Reverse current

(VR=5V)

Wavelength at peak

emission

(I F=20mA)

Spectral Line half-width

(I F=20mA)

Capacitance

(VF=0, f=1MHz)

AG

( I n G a N)

Un i t

V

mA

mW

°+

V

F

V

F

I

R

3.5

4.0

10

V

uA

λ

peak

502

nm

∆λ

C

30

90

nm

pF

Part

Number

Emitting

Color

Emitting

Material

Lens-color

Luminous

I ntensity

(I F=20mA)

mcd

min.

typ.

300

480

Wavelength

nm

Viewing

Angle

ZAG55W-03

green

I nGaN

water clear

502

50°

1-1
