REVISION CD
DO NOT
SCALE FROM
THIS PRINT
NOTES:
1.
C
REPRESENTS A CRITICAL DIMENSION.
2. MINIMUM PUSHOUT FORCE: .5 LB.
No OF POSITIONS
C
3. COPLANARITY: .004[0.10] = POS 02 THRU 26
ALL POSITIONS AVAILABLE
.006[0.15] = POS 27 THRU 50
-02 THRU -50
4. TUBE PACKAGE ONLY POSITIONS -04 THRU -50;
(USE BODY: SFMC-50-D)
LAYER PACKAGE POSITIONS -02 THRU -03.
5. MAXIMUM CUT FLASH TO BE: .010 (NO FLASH EXTENDING BELOW
LEADS OR IN HOLES OF BODY.
LEAD STYLE
C
6. MAXIMUM PIN HEIGHT VARIATION: .003[0.08]
FROM PIN TO PIN AND ROW TO ROW, MUST BE
-01: THROUGH HOLE
MEASURED BETWEEN ADJACENT PINS.
(USE CONTACT: C-44-01-XXX)
7. PINS CAN BE ORIENTED IN ANY DIRECTION;
(SEE FIG 1, SHT 1)
BOTH ROWS MUST FACE SAME WAY.
-02: SURFACE MOUNT
8. DIMENSION TO BE MEASURED AT BEND.
(USE CONTACT: C-44-02-XXX)
9. MIXED PIN ORIENTATION ACCEPTABLE.
(SEE FIG 2, SHT 2)
-03: STRAIGHT MODIFIED
(USE CONTACT: C-44-03-XXX)
(NO. OF POS x .050[1.27])
C
(SEE FIG 1, SHT 1)
+ .015[0.38] .008[0.20]
-L1: THROUGH HOLE (LOW INSERTION)
(SEE NOTE 5)
(USE CONTACT: C-61-01-XXX)
(SEE FIG 1, SHT 1)
C
-L2: SURFACE MOUNT (LOW INSERTION)
(USE CONTACT: C-61-02-XXX)
.033±.003 0.83±0.08
(SEE FIG 2, SHT 2)
-L3: STRAIGHT MODIFIED (LOW INSERTION)
(USE CONTACT: C-61-03-XXX)
(SEE FIG 1, SHT 1)
.120 3.05
C
-T1: THROUGH HOLE (PHOS BRONZE)
.050 1.27 REF
L
(USE CONTACT: C-119-01-XXX)
REF
(SEE FIG 1, SHT 1)
-T2: SURFACE MOUNT (PHOS BRONZE)
(USE CONTACT: C-119-02-XXX)
.050 1.27 REF
(SEE FIG 2, SHT 2)
SFMC-1XX-XX-XX-D-XX
(LEAVE BLANK FOR STANDARD
-P: PICK AND PLACE PAD (SEE FIG 3, SHT 2)
(USE PPP-02) (5 POSITION MINIMUM)
-K: POLYIMIDE FILM PAD (.005[0.13] THICKNESS)
(SEE FIG 4, SHT 2) (USE K-DOT-.157-.250-.005)
(4 POSITION MINIMUM)
-TR: TAPE & REEL (SEE SHT 3)
BODY SPECIFICATION
-D: DOUBLE ROW
PLATING SPECIFICATION
-S: 30µ" SELECTIVE GOLD IN CONTACT AREA,
MATTE TIN ON TAIL
-F: 3µ" SELECTIVE GOLD IN CONTACT AREA,
MATTE TIN ON TAIL
-H: 30µ" GOLD IN CONTACT AREA, 3µ" GOLD ON TAIL
(ONLY AVAILABLE ON -02, -L2 & -T2 LEAD STYLE)
-L: 10µ" SELECTIVE GOLD IN CONTACT AREA,
MATTE TIN ON TAIL
-SM: 30µ" SELECTIVE GOLD IN CONTACT AREA,
MATTE TIN ON TAIL
-FM: 3µ" SELECTIVE GOLD IN CONTACT AREA,
MATTE TIN ON TAIL
OPTIONS
"A"
SFMC-50-D
.180 4.57 REF
C
L
.015 0.38 REF
C-XX-01-XXX
(SEE NOTE 7)
"A"
(SEE TABLE 1)
"B" REF
(SEE TABLE 1)
C
2 MAX SWAY (TYP)
.05 1.3
"A"
(NO OF POS x .050[1.27]) - .050[1.27]
1 MAX
SWAY (TYP)
C
SECTION "A"-"A"
-X1: THROUGH HOLE
FIG 1
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN INCHES.
TOLERANCES ARE:
DECIMALS
.XX: .01 [.3]
2
.XXX: .005 [.13]
.XXXX: .0020 [.051]
ANGLES
THIS DOCUMENT CONTAINS CONFIDENTIAL AND
PROPRIETARY INFORMATION AND ALL DESIGN,
MANUFACTURING, REPRODUCTION, USE, PATENT RIGHTS
AND SALES RIGHTS ARE EXPRESSLY RESERVED BY SAMTEC,
INC. THIS DOCUMENT SHALL NOT BE DISCLOSED, IN WHOLE
OR PART, TO ANY UNAUTHORIZED PERSON OR ENTITY NOR
REPRODUCED, TRANSFERRED OR INCORPORATED IN ANY
OTHER PROJECT IN ANY MANNER WITHOUT THE EXPRESS
WRITTEN CONSENT OF SAMTEC, INC.
*
PROPRIETARY NOTE
*
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
MATERIAL:
DO NOT SCALE DRAWING
SHEET SCALE: 4:1
BODY: LCP UL 94V-O, COLOR: BLACK
CONTACTS: C-44 & C-61: #25 BeCu, 1/2 HARD
C-119: PHOSPHOR BRONZE 521
c:\enterprisevault\DWG\MISC\MKTG\SFMC-1XX-XX-XX-D-XX-MKT.SLDDRW
.050 x .050 CUTTABLE SOCKET STRIP DOUBLE ROW ASSEMBLY
BY:
BRATCHER 10/5/94
SFMC-1XX-XX-XX-D-XX
SHEET
1
OF
3
REVISION CD
C
(NO. OF POS x .050[1.27])
+ .015[0.38] .008[0.20]
C
.190
+.005
4.83
+0.126
- .002
- 0.051
(SEE NOTE 8)
IN-PROCESS
-X2
NOTE: DIMENSION APPLIES PRIOR
TO RE-PRESS, SEE SECTION "B"-"B"
FOR FINISHED DIMENSION
.394 10.01 REF
C OF
L
PART
C-XX-02-XXX
3 MAX SWAY (TYP)
C
"B"
C
.185
+.002
4.70
+0.051
- .005
- 0.127
(SEE NOTE 6 & 8)
4°
.165 4.19 REF
SEE NOTE 3
2°
SEE NOTE 6
"B"
-X2: SURFACE MOUNT
(SAME AS FIG 1, DIFFERENT AS SHOWN)
PPP-02
(NO. OF POS x .050[1.27]) - .050[1.27]
FIG 2
SECTION "B"-"B"
"A"±.010[0.25] (SEE TABLE 2)
.225 5.72 REF
C OF
L
PART
"R"
(SEE NOTE)
.062 1.57
C
"S"
(SEE NOTE)
.019±.020 0.47±0.51
-P: PICK AND PLACE PAD
( 5 POSITION MINIMUM)
( PAD MAY BE ORIENTED IN EITHER DIRECTION)
(SAME AS FIG 1, DIFFERENT AS SHOWN)
.1575±.0050 4.001±0.127
.190 4.83
*
PROPRIETARY NOTE
*
FIG 3
-K: POLYIMIDE FILM PAD
(SAME AS FIG 1, DIFFERENT AS SHOWN)
NOTE: "R" = USED MEASURED DIMENSION REF
"S" = {("R" - .1575[4.000])/2}±.020[0.51]
FIG 4
THIS DOCUMENT CONTAINS CONFIDENTIAL AND
PROPRIETARY INFORMATION AND ALL DESIGN,
MANUFACTURING, REPRODUCTION, USE, PATENT RIGHTS
AND SALES RIGHTS ARE EXPRESSLY RESERVED BY SAMTEC,
INC. THIS DOCUMENT SHALL NOT BE DISCLOSED, IN WHOLE
OR PART, TO ANY UNAUTHORIZED PERSON OR ENTITY NOR
REPRODUCED, TRANSFERRED OR INCORPORATED IN ANY
OTHER PROJECT IN ANY MANNER WITHOUT THE EXPRESS
WRITTEN CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 4:1
.050 x .050 CUTTABLE SOCKET STRIP DOUBLE ROW ASSEMBLY
c:\enterprisevault\DWG\MISC\MKTG\SFMC-1XX-XX-XX-D-XX-MKT.SLDDRW
BY:
BRATCHER 10/5/94
SFMC-1XX-XX-XX-D-XX
SHEET
2
OF
3
REVISION CD
ROUND HOLES
PACKAGE PARTS IN TUBES AS SHOWN
PACKAGING VIEW
PT-1-24-15-09
ANTI-STATIC
OBLONG HOLES
PT-1-24-01-09
USER DIRECTION OF UN-REELING
POCKET NOT DETAILED
ANTI-STATIC
-TR: TAPE AND REEL THOUGH HOLE
ROUND HOLES
NOTES:
1.
MIXED PIN ORIENTATION ACCEPTABLE.
PACKAGING VIEW
OBLONG HOLES
USER DIRECTION OF UN-REELING
POCKET NOT DETAILED
*
c:\enterprisevault\DWG\MISC\MKTG\SFMC-1XX-XX-XX-D-XX-MKT.SLDDRW
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS CONFIDENTIAL AND
PROPRIETARY INFORMATION AND ALL DESIGN,
MANUFACTURING, REPRODUCTION, USE, PATENT RIGHTS
AND SALES RIGHTS ARE EXPRESSLY RESERVED BY SAMTEC,
INC. THIS DOCUMENT SHALL NOT BE DISCLOSED, IN WHOLE
OR PART, TO ANY UNAUTHORIZED PERSON OR ENTITY NOR
REPRODUCED, TRANSFERRED OR INCORPORATED IN ANY
OTHER PROJECT IN ANY MANNER WITHOUT THE EXPRESS
WRITTEN CONSENT OF SAMTEC, INC.
*
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
-TR: TAPE AND REEL SURFACE MOUNT
PACKAGING VIEW
DO NOT SCALE DRAWING
SHEET SCALE: 1.5:1
.050 x .050 CUTTABLE SOCKET STRIP DOUBLE ROW ASSEMBLY
DWG. NO.
SFMC-1XX-XX-XX-D-XX
BY:
BRATCHER 10/5/94
SHEET
3
OF
3
