Part Number:
XPI-A8
www.SunLED.com
PHOTO-INTERRUPTER
Features
Compact and thin.
Visible light cut-off type.
High sensitivity.
RoHS compliant.
Applications
Cassette tape recorders,VCRs.
Floppy disk drives.
Various microcomputerized control equipment.
UNIT : MM[INCH]
TOLERANCE : ± 0.25[± 0.01] UNLESS OTHERWISE NOTED.
Absolute Maximum Ratings (
T
A
=25°C)
Parameter
Forward current
Reverse voltage
Input
Power dissipation
Peak Forward Current (Pulse Width
≤
100BS,Duty Cycle=1%)
Collector-emitter voltage
Emitter-collector voltage
Output
Collector current
Collector power dissipation
Operating temperature
Storage temperature
Soldering temperature (1/16 inch from body for 5 seconds)
Symbol
I
F
V
R
P
d
I
FP
V
CEO
V
ECO
I
C
P
C
Topr
Tstg
Tsol
Rating
50
6
75
1
35
6
20
75
-25~+85
-40~+100
260
Unit
mA
V
mW
A
V
V
mA
mW
°C
°C
°C
Published Date : AUG 06,2005
Drawing No : XDSA0584
V5
Checked : Tracy Deng
P.1/5
Part Number:
XPI-A8
www.SunLED.com
PHOTO-INTERRUPTER
Electrical / Optical Characteristics at T
A
=25°C
Parameter
Forward voltage
Input
Reverse current
Peak Wavelength
Output
Collector dark current
*1
Collector
Symbol
V
F
I
R
λ
p
I
CEO
I
C
I
LEAK
Rise time
tr
tf
Conditions
I
F
=20mA
V
R
=6V
I
F
=20mA
V
CE
=20V
V
CE
=2V
I
F
=4mA
V
CE
=2V
I
F
=4mA
V
CE
=2V
I
C
=100
µ
A
R
L
=1K
Ω,
d=1mm
Min.
1.0
-
-
-
10
-
-
-
Typ.
1.2
-
940
10
-9
-
-
20
20
Max.
1.5
10
-
10
-7
400
0.1
100
100
Unit
V
µ
A
nm
A
µ
A
µ
A
µ
Sec
µ
Sec
current
Transfer
Charac-
teristics
*2
Leak
current
Response time
Fall time
*1 The condition and arrangement of the reflective object are shown below.
*2 Without reflective object.
BIN CODE
E
F
G
I
C(
µ
A)
10-120
100-250
200-400
Published Date : AUG 06,2005
Drawing No : XDSA0584
V5
Checked : Tracy Deng
P.2/5
